DOSKO 2000LS-H Operating Instructions

OPERATING INSTRUCTIONS
Model 2000LS-H
Log Splitter On/Off Switch
Engine Guard
Engine Throttle
& Choke
Recoil Rope
Engine On/Off
Switch
Hydraulic Tank
Know Your Dosko:

BEFORE SPLITTING WOOD

• Read and understand your Dosko owner's manual.
• Lock and block the log splitter to prevent unintended
movement.

STARTING LOG SPLITTER

• Flip switch (located on log splitter) to "On" position.
• Turn switch (located on engine) to "On" position.
• Rotate fuel on-off lever (located on engine) to "On" position.
• Rotate choke lever (located on engine) to choking position.
If engine is warm this step may not be necessary.
• Set throttle (located on engine) about ¼ open.
• Pull recoil rope (located on engine) to start engine.
• When engine starts — rotate choke lever to "Off" or
"Open" position.
• Allow engine to warm up prior to splitting wood. Increase
engine speed by moving throttle lever to full open position.
20195 South Diamond Lake Road, Suite 100 • Rogers, MN 55374 • USA (Toll-Free): 866-298-3659 • International: + 1-763-428-0302 • www.dosko.com 20195 South Diamond Lake Road, Suite 100 • Rogers, MN 55374 • USA (Toll-Free): 866-298-3659 • International: + 1-763-428-0302 • www.dosko.com
Split Control Lever
2-Way Wedge
Log Tray
Jack Stand
Owner's Manual
Storage Tube
BEFORE STARTING OR USING THIS MACHINE, READ AND REVIEW THIS SAFETY SHEET! BE AWARE OF ALL POTENTIAL DANGERS,
PROTECT WINDOWS AND VEHICLES FROM POSSIBLE FLYING DEBRIS AND BE AWARE OF ALL NECESSARY SAFETY PRECAUTIONS!

SPLITTING WOOD

• Load log onto beam between the wedge and endplate.
This log splitter is equipped with a unique double-edged
splitting wedge, which is capable of splitting wood on
either the extension or retraction stroke of the wedge.
Use a chainsaw to cut logs square on each end before
splitting. Logs not cut square can slide out while splitting
and become a safety hazard.
Hold the bark side of the logs when loading or
positioning, never the ends.
• With log placed appropriately, pull split control lever
to move splitting wedge in towards log.
• After completion of splitting, turn off unit.
Flip switch (located on log splitter control panel) to "Off"
position.
Turn on-off switch (located on engine) to "Off" position.
Rotate fuel on-off lever (located on engine) to "Off"
position.
• After use, with unit turned off and exercising extreme
caution near HOT components, clean debris from around
engine area as a hot engine can be a fire hazard.
Transport
Handlebars
Tow Coupler
with Locking Pin
Safety Chains
ALWAYS
THINK
SAFETY
Item # E788459
