INSTRUCTIONS
LIST OF PARTS & HARDWARE
White-painted metal parts:
1 Side Left (SL) - includes hinged shelf
1 Side Right (SR)
1 Upper Frame (UF)
1 Shelf Grid (SG)
3 Cross Bars (CB) - one with
printed Evergreen name
1 Windsock Pole (WP)
4
Wheel
1 "T" Shape Support
Additional Hardware:
12 small bolts (each with
washer)
1 medium bolt (each with
washer)
2 large bolts (each with
wingnut and 2 washers)
1 small screwdriver
Merchandising hooks
and brackets:
30 garden flag hooks
30 regular flag hooks
20 6" hooks
2
E-brackets
3
C-brackets
4
D-brackets
1
Windsock Attachment
"T" SHAPE SUPPORT
WINDSOCK ATTACHMENT
SIDE LEFT (SL)
WINDSOCK
UPPER FRAME (UF)
POLE
(WP)
WHEEL
SHELF GRID (SG)
C-BRACKET
"Great Grand Daddy"
Metal Flag Display (05096)
REGULAR
FLAG HOOK
E-BRACKET
D-BRACKET
SIDE RIGHT (SR)
CROSS BAR (CB)
GARDEN
FLAG HOOK
6" HOOK
Rev. 04/07
Advertisement
Table of Contents
Related Manuals for Evergreen Great Grand Daddy
Summary of Contents for Evergreen Great Grand Daddy
- Page 1 INSTRUCTIONS “Great Grand Daddy” Metal Flag Display (05096) LIST OF PARTS & HARDWARE White-painted metal parts: 1 Side Left (SL) - includes hinged shelf 1 Side Right (SR) 1 Upper Frame (UF) 1 Shelf Grid (SG) 3 Cross Bars (CB) - one with...
- Page 2 Instructions for “Great Grand Daddy” metal flag display (05096) Page 2 ASSEMBLY INSTRUCTIONS 1. Remove everything from packaging and verify Fig. D that all parts are present. Fig. C Install wheels Fig. A at the bottom of side left and side right.
- Page 3 Instructions for “Great Grand Daddy” metal flag display (05096) Page 3 ASSEMBLY INSTRUCTIONS (CONT’D). 7. Slide 6” Hooks onto the front cross bar of 9. Slide the windsock attachment on windsock the display (Fig. G). pole (WP) over the bop of the bar in the side frame.
