INSTRUCTIONS
NECESSARY TOOLS
•
Screwdriver
•
Small step ladder or step stool (useful
to reach the top of the display)
LIST OF PARTS & HARDWARE
White-painted metal parts:
1 Side Left (SL) - includes hinged shelf
1 Side Right (SR)
1 Upper Frame (UF)
1 Shelf Grid (SG)
3 Cross Bars (CB) - one with
printed Evergreen name
4
Wheel
1 "T" Shape Support
Additional Hardware:
18 small bolts
18 washers
2 large bolts (each with a wingnut
and 2 washers)
Merchandising hooks and brackets:
20 garden flag hooks
20 regular flag hooks
20 6" hooks
2 E-brackets
2 C-brackets
4 D-brackets
"T" SHAPE SUPPORT
SIDE LEFT (SL)
UPPER FRAME (UF)
WHEEL
SHELF GRID (SG)
C-BRACKET
"Junior" Metal Flag Display (05092)
REGULAR
FLAG HOOK
E-BRACKET
D-BRACKET
SIDE RIGHT (SR)
CROSS BAR (CB)
GARDEN
FLAG HOOK
6" HOOK
Rev. 04/07
