Summary of Contents for Hobie 72020074
- Page 1 Adjustable Rod Extender...
- Page 3 Parts | 3 hobiecat.com 1. Adjustable Rod Extender Assembly 2. Security Straps (2) 3. Padeyes (2) 4. #10 Sheet Metal Screws (4) 5. XL Screw in Padeyes (2) Adjustable Reel Holder Reel Holder Knob Leash Attachments Rod Tube Gimble Pin Angle Adjustment Lever Plug-In Insert...
- Page 4 4 | Rod Holder Features Gimble Pin The adjustable rod holder assembly comes with a gimble pin installed at the base. You can remove the pin with a flat head screwdriver if you do not want to use this feature. Reel Holder The reel holder at the top can be removed to allow for different styles of...
- Page 5 Rod Holder Features | 5 hobiecat.com Rod Tube Angle Adjustment The rod tube can be adjusted for optimal trolling angle or storage position. To adjust the rod tube: Open the latch. Rotate the rod tube to your desired angle. Close the latch.
- Page 6 6 | Anchor Strap Installation Anchor Straps The provided anchor straps not only keep the rod holders tethered to the boat, but also prevent them from rotating if you are trolling. To install the anchor straps: 8” Screw the padeyes into the gunnels of your kayaks approximately 8”...
- Page 7 Insert the rod holder into the molded-in rod holder on your boat and position it as desired. Snap the straps to the rod holder and to the padeye and tighten into position.
- Page 8 Hobie Cat Company Holding Company Oceanside, California, USA 1-800-HOBIE-49 hobiecat.com Hobie Cat Australasia Subsidiary Huskisson, New South Wales, Australia 1-800-4-HOBIE hobiecat.com.au Hobie Cat Europe Subsidiary Toulon, France +33 (0) 494 08 78 78 hobie-cat.net Hobie Kayak Europe Independent Distributor Stellendam, The Netherlands +31 (0) 187 499 440 hobie-kayak.com...
