Instruction Manual
Battery crimping tool HL-400B
Instruction Manual
Battery crimping tool HL-400B
Due to continuing improvements, actual product may differ slightly from
the product described here in.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL
Advertisement
Table of Contents
Related Manuals for Hewlee HL-400B
Summary of Contents for Hewlee HL-400B
- Page 1 Instruction Manual Battery crimping tool HL-400B Instruction Manual Battery crimping tool HL-400B Due to continuing improvements, actual product may differ slightly from the product described here in. Read this material before using this product. Failure to do so can result in serious injury.
-
Page 2: Limited 1 Year Warranty
SAVE THIS MANUAL LIMITED 1 YEAR WARRANTY Keep this manual for the safety warnings and precautions, assembly, operating, We make every effort to assure that its products meet high quality and durability inspection, maintenance and cleaning procedures. Write the month and year of standards, and warrants to the original purchaser that this product is free from purchase. -
Page 3: General Safety Rules
PLEASE READ THE FOLLOWING CAREFULLY GENERAL SAFETY RULES THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A TO WORK IN SAFE CONDITIONS WITH THIS TOOLING, IT IS IMPERATIVE TO REFERENCE TOOL ONLY. NEITHER MANUFACTURER READ CARFULLY THE DIRECTIONS FOR USE AND TO FOLLOW THE DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY... -
Page 4: Personal Safety
The best temperature for charging is between 10℃ - 40℃. Make sure MAINTENANCE AND SERVICING the air hole of the battery and charger are uncovered during charging. Please pull out the plug when meet a bad weather. The tool earns a high precise design, please use it properly and do not disassemble Please do not burn the battery or make it being short-circuited, it may it by unprofessional person, otherwise we will not responsible for the problems cause cause explosion. -
Page 5: Specification
UNDERSTAND YOUR TOOL HL-400B is a tool for crimping Cu/Al lugs with cables from 16-400mm It is powered by Li-ion, actuated by motor and controlled by M C U. With a high pressure hydraulic system, it is a perfect tool to be used in electrical construction site. -
Page 6: Description Of Components
2. Description of components: Parts No. Description Function For locking/unlocking the upper die For crimping, interchangeable die Retaining clips For locking/unlocking the down die Limited screw For prevent head from dropping or popping For indicating the operating condition and LED indicator battery discharging situation A white Led light To illuminate the working area... -
Page 7: Function Description
3. Function description 3. Usage of the tool First you have to check the LED indicator is light or not. If the indicator is light on MCU - automatically detect the pressure during operation and for more than 5 seconds, it means no power of the battery and should change provide security protect, shut off the motor and reset automatically after the full powered battery to settle on the tool operation. - Page 8 In addition we see a lower power weight ratio with 50% more capacity and OPERATING INSTRUCTION shorter charging cycles compare to Ni-MH batteries. A Temperature sensor makes the tool stop working automatically Please check carefully before operating. Make sure the tool is complete and has no when the temperature over 60°C under long time working, the fault signal damage part.
