IDEAL Exalt Series Replacement Manual

Burner Mounting Plate Replacement
Kit Part Number
EXRKIT14
EXRKIT15
EXRKIT16
Each Kit Includes:
• Burner Mounting Plate
• Combustion Chamber Insulation / Gasket
• Igniter Gasket
• Blower Gaskets
WARNING
!
Indicates a potentially hazardous situation which,
if ignored, can result in serious injury or substan-
tial property damage.
WARNING
!
For your safety, turn off electrical power supply
at service panel and allow unit to cool before pro-
ceeding to avoid possible electrical shock and
scald hazard. Failure to do so can cause severe
personal injury or death.
2019-77 Exalt Burner Mounting Plate Replacement
Revised 11/26/2019
Exalt
Description
Burner Plate Replacement
Burner Plate Replacement
Burner Plate Replacement
Model
Exalt 110
Exalt 155 Models
Exalt 199 Models
Recommended Tools:
• Adjustable Wrenches
• Phillips Head Screwdriver
• Torx Screwdrivers, T-10, T-20, T-25
• 10 mm Socket and/or 10 mm Open Ended Wrench
NOTICE
Indicates special instructions on installation, operation
or maintenance, which are important to equipment
but not related to personal injury hazards.
WARNING
!
Failure to follow instructions below can result in
severe personal injury or damage if ignored.
• Instructions are for a qualified installer/ ser-
vice technician only.
• Read all instructions before proceeding.
• Follow instructions in proper order.
