Network Security
Step 1 – Fasten Bracket
1. Fix the USB bracket over the front panel of the NSA 240 appliance.
2. On the bottom of the appliance, use the torx wrench and screws to mount the bracket.
Step 2 – Loosen Security Screws
3. Using the torx wrench, loosen the screws on the top of the bracket.
4. Insert the USB device.
USB Bracket Assembly for SonicWALL TZ 210 / NSA 240 – Installation Guide
Installation Guide
USB Bracket Assembly for SonicWALL TZ 210 / NSA 240
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SonicWALL TZ 210
Summary of Contents for SonicWALL TZ 210
- Page 1 2. On the bottom of the appliance, use the torx wrench and screws to mount the bracket. Step 2 – Loosen Security Screws 3. Using the torx wrench, loosen the screws on the top of the bracket. 4. Insert the USB device. USB Bracket Assembly for SonicWALL TZ 210 / NSA 240 – Installation Guide...
- Page 2 6. Verify that the USB device is securely in place and cannot be removed. NOTE: The minimum and maximum opening sizes for a USB device are 6mm and 12.5mm, respectively. ______________________ Last updated: 9/7/2009 Prepared by: PLydon USB Bracket Assembly for SonicWALL TZ 210 / NSA 240 – Installation Guide...
