P2110-EVAL-02
®
Lifetime Power
Energy Harvesting Development Kit for Battery Charging
User's Manual
- featuring THINERGY
Overview
®
The Lifetime Power
Energy Harvesting Development Kit for Battery Charging is a complete
demonstration and development platform for wireless battery-charging over distance powered by RF
energy (radio waves). This kit features a THINERGY
Solutions (IPS) which has an ultra-thin form factor and extremely low leakage.
Batteries are charged by the P2110CSR Powerharvester
energy, stores it into an intermediate capacitor, and then provides a pulsed, regulated voltage output
which provides charge current to the attached storage. In this kit, the TX91501 transmitter is the source
of RF energy at 915MHz, but other sources from 850-950 MHz can also be used for power.
A regulated load voltage is provided to power an application device, and the Texas Instruments eZ430-
RF2500 wireless development tool is included for demonstration purposes.
Note:
This kit is based on the P2110CSR Powerharvester. Powercast's P1110 Powerharvester component also
charges batteries and the main differences are as follows:
Parameter
Charging Method
Output Voltage Range
Output Voltage
Usage
Operating / Charging Range
(with identical antennas)
* P1110 is NOT to be used with thin-film batteries like THINERGY that require a fixed charging voltage.
The P1110 Evaluation Board kit (P1110-EVB) is also available to charge batteries using the P1110. The
P1110-EVB will receive power from the transmitter included with the P2110-EVAL-01 or P2110-EVAL-02
development kits.
Rev A.3 – 2013/02
®
Micro-Energy Cell
P1110
Continuous
1.8V - 4.2V
Output voltage floats with the
battery voltage until the
configured maximum output
voltage is reached
Direct power OR
Battery-charging (direct
connection to typical battery)*
Shorter – roughly half as far as
the P2110.
P2110-EVAL-02: Lifetime Power
Energy Harvesting Development Kit for Battery Charging
www.powercastco.com
®
Micro-Energy Cell (MEC) from Infinite Power
®
Chipset Reference Design, which converts RF
P2110CSR
Pulsed / Intermittent
2V – 5.5V
Fixed, regulated output voltage
Pulsed power OR
Battery-charging (additional
circuitry typically required)
Longer – roughly twice as far as
the P1110.
®
Page 1
Advertisement
Table of Contents
Related Manuals for Powercast P2110-EVAL-02
Summary of Contents for Powercast P2110-EVAL-02
- Page 1 * P1110 is NOT to be used with thin-film batteries like THINERGY that require a fixed charging voltage. The P1110 Evaluation Board kit (P1110-EVB) is also available to charge batteries using the P1110. The P1110-EVB will receive power from the transmitter included with the P2110-EVAL-01 or P2110-EVAL-02 development kits.
- Page 2 8-wire cable for connecting the Charging Board to the IPS Application Development Platform (ADP). eZ430-RF2500 Texas Instruments eZ430-RF2500 Development Tool – used to demonstrate a low-power wireless application. ® Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power Page 2 Energy Harvesting Development Kit for Battery Charging www.powercastco.com...
-
Page 3: Setup And Operation
The LED will blink when sufficient power is available. The blinking rate is faster when closer to the transmitter and slower when further from the transmitter. ® Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power Page 3 Energy Harvesting Development Kit for Battery Charging www.powercastco.com... - Page 4 To charge a different battery than the included MEC card, set S1 switch to EXT and connect the external battery across XBATT and GND, or use the through-hole solder connection, BT1. ® Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power Page 4 Energy Harvesting Development Kit for Battery Charging www.powercastco.com...
- Page 5 4. Plug in the transmitter and point toward the receiving unit. Plug in the TX91501 Powercaster Transmitter and point it toward the receiving unit. The front of the transmitter has the Powercast logo and status LED. Please see the TX91501 User’s Manual for detailed operating instructions.
- Page 6 Please see the documentation from Texas Instruments for software installation and operation. TI provides a free sensor demo PC application and the source code. Powercast does not provide support for the eZ430-RF2500 kit. To use the eZ430-RF2500 with the charging board: Install the Sensor Monitor software that comes with the eZ430-RF2500 kit •...
- Page 7 “Gated” mode for MEC charging. Gated mode is recommended to see the pulsed charging voltage and current. The J5 header pins on the ADP pins are used as follows: 1. VIN-H not used 2. VIN-L charge from Powercast Charging Board 3. I/O-1 not used 4. I/O-2 not used 5. ENABLE tied to ground for enabling the ADP EH interface 6.
-
Page 8: Documentation And Software
P2110CSR Powerharvester Chipset reference Design – datasheet http://www.powercastco.com/PDF/P2110CSR-datasheet.pdf P2110CSR Evaluation Board – instructions http://www.powercastco.com/PDF/P2110CSR-EVB.pdf TX91501 Powercaster Transmitter – user’s manual http://www.powercastco.com/PDF/TX91501-manual.pdf The P2110-EVAL-02 is subject to Powercast’s Limited Warranty for Development Systems Infinite Power Solutions THINERGY Micro-Energy Cells http://www.infinitepowersolutions.com/product/thinergy THINERGY Application Development Platform http://www.infinitepowersolutions.com/product/thinergyadp Technical support for THINERGY products is provided by Infinite Power Solutions. -
Page 9: Appendix A - Charging Board Component Description
It is recommended to remove the THINERGY MEC Evaluation Card from the connector slot when not in use to avoid unnecessary energy leakage. ® Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power Page 9 Energy Harvesting Development Kit for Battery Charging www.powercastco.com... - Page 10 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Powercast P2110-EVAL-02...
