Pinout Table 1 ECAN01 4 pin socket pinout Pin number Pin name Description (Blue) Connect to CAN L input of CAN L CAN BUS converter (White/Blue) Connect to CAN H CAN H input of CAN BUS converter (Red) Power supply (+6-30 V DC)
Set up your device How to insert CAN wires into contactless reader ECAN01 1. Gently open ECAN01 cover using plastic pry tool from both sides. 2. Insert CAN wires as shown in figure 5. Please make sure that correct slots are used (CAN High/CAN Low).
Characteristics Table 2 technical features Value Characteristic description Min. Typ. Max. Unit Supply Voltage Supply voltage (recommended operating conditions) CURRENT CONSUMPTION Working mode Stand-by mode OPERATING TEMPERATURE Operating temperature °C PROTECTION Internal resettable fuse (max 33 V) Dimensions Figure 8 Dimensions Dimensions 39,8 x 18 x 16,7 mm •...
CAN bus wires location. It will are fixed to the frame. be provided on request by Teltonika technical support. ▬ If the wire is fixed with the bolt, the loop must be connected to ▬ In order to locate CAN bus wires, any twisted pair in the vehicle the end of the wire.
Safety information The programming must be performed using a PC with autonomic power supply. This message contains information on how to operate ECAN01 safely. By Installation and/or handling during a lightning storm following these requirements and recommendations, you will avoid is prohibited.
• Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. Warranty Disclaimer ECAN | Wiki...
