- Page 1 Rea Bellis assembly instructions accessories English...
- Page 2 REA BELLIS...
-
Page 3: Table Of Contents
Fitting heel straps to the foot plate extension Fitting the foot plate extension Reflectors on the rear and sides of chairs with 20”-24” wheels Reflectors on the rear and sides of chairs with 16” wheels Pommel Table tray Crutch holder Incontinence cover REA BELLIS... -
Page 4: 16"-Transportwheel
Adjust the braking effect when necessary by tightening/ loosening the wire (C). Attach the wire to a suitable point on the underside of the chair using cable ties to keep it out of the way. Tools: 5 mm Allen Key REA BELLIS... -
Page 5: Foot Brake (Only For 16" Wheels, Seat Height 47 Cm)
8. If additional adjustment is necessary, repeat steps 1-5. 3. Press down the foot brake tube with your foot to apply the brake. 4. Push the foot brake tube upwards with your foot to release the brake. REA BELLIS... -
Page 6: Fit An Adjustable Backrest
Tools: 5 mm Allen Key 2. Fit the new adjustable backrest and tighten the screws (A). Tools: 5 mm Allen Key 3. The height of the backrest can be adjusted using the four screws (B). Tools: 5 mm Allen Key REA BELLIS... - Page 7 The cover can be folded upwards at the bottom if necessary (see the enlarged detail in the diagram), depending on how low the backrest is placed on the wheelchair. REA BELLIS...
-
Page 8: Adapt To Electrically Operated Seat Tilt And Backrest Tilt Adjustments
Loosen this piston from its attachment under the seat by removing the circlips (A) and the dowel (B). Tools: Ciclip pliers 3. Then remove the protective casing of the seat tilt piston by loosening the clips on both sides. REA BELLIS... - Page 9 6. Fit the electrically operated backrest tilt piston into its attachment under the seat with the circlips (A) and the dowel (B). Attach the piston to the backrest arch using the pin at the back. Ensure that it "clicks" into the attachment securely. REA BELLIS...
-
Page 10: Fitting The Battery
(B) and the control box (C) according to the diagram. Fix hanging cables at suitable points under the chair using cable ties, to keep them out of the way A = Seat B = Backrest REA BELLIS... -
Page 11: Neckrest/Headrest
(E) and the screw (D), take out the attachment and turn around to required position. Re-tighten the screws (E) and the screw (D). If the neckrest/headrest has been taken away, The centre rod mustn't be left on the chair. REA BELLIS... -
Page 12: Fitting Detachable Trunk Supports
NB! Ensure that the lock button (C) on the insert bracket is in its correct position on the sleeve tube of the trunk support. 3. You can use the screw (D) to adjust the depth of the trunk support pad. Tools: 5 mm Allen Key REA BELLIS... -
Page 13: Fitting Trunk Supports
2. You can open the trunk support pad using the zip. You can then adjust the trunk support by loosening the two screws using a Phillips screwdriver and moving the trunk support forwards or backwards. Retighten the screws and close the zip. Tools: screwdriver REA BELLIS... -
Page 14: Safety Belt
Undo the belt by pressing button (A). Armrest height adjustment Adjust the height of the armrest using screw (A). Tools: 5 mm Allen Key HEIGHT ADJUSTMENT FLIP-UP- OR HEMIPLEGICARMREST Adjust the height of the armrest using screw (A). Tools: 5 mm Allen Key REA BELLIS... -
Page 15: Remove The Push Bar And Fit A Push Handle Bar
Then retighten the levers. The push handles brace must not be pulled up so that it protrudes more than 19 cm over the top edge of the attachment. REA BELLIS... -
Page 16: Comfort Backrest Pad "Laguna
Do not forget that the spacers (E) must be placed between the plastic backrest and the mounting plate (F) on each backrest tube. Finally fi t the comfort backrest pad into the plastic shell. REA BELLIS... -
Page 17: Central Legrest
fi t the central legrest, set the required seat depth and tighten the screws (A). 2. Adjust the legrest to a central position by loosening both Allen screws (B) as shown in the picture. When you have found the desired position, retighten the screws. REA BELLIS... -
Page 18: Fitting Heel Straps To The Foot Plate
(B) as shown in the diagram. Note that only two of the holes are used. Fit the heel straps around each guiding pin and adjust the shape and depth, etc. using the Velcro straps. Tools: 10 mm fixed spanner screwdriver REA BELLIS... -
Page 19: Fitting The Foot Plate Extension
If the wheelchair is equipped with 16” wheels the orange reflector must be attached to the side of the wheelchair using the screw (D) and the square nut (E). Tools: 4 mm Allen Key 10 mm fixed spanner REA BELLIS... -
Page 20: Pommel
2. Lock the pommel into the attachment by tighte- ning the knob (C) underneath. 3. Adjust the height of the pommel using the screw (D). Tools: 5 mm Allen Key 4. Adjust the depth of the pommel using the screw (E). Tools: 4 mm Allen Key REA BELLIS... - Page 21 (C) between the armrest pad and its attachment plate. Attach the armrest pad with the new screws (D). 2. The table tray is attached by putting the pins (E) into the attachment casings (F) and pushing them down into place. REA BELLIS...
-
Page 22: Crutch Holder
(D). Adjust the Velcro strap around the crutch or walking stick as necessary. Incontinence cover Remove the seat pad, pull the incontinence cover (A) over the pad and put the pad back into the chair. REA BELLIS... - Page 24 They are careful to ensure that all knobs, screws and nuts are properly tightened. • They are careful to ensure that the drive wheels are properly fixed to the wheelchair. Manufacturer: Invacare Rea AB Växjövägen 303 S-343 71 DIÖ SWEDEN Sales companies: Belgium: Denmark: Finland: France: Invacare n.v.
