マルチパーカッションラック
MULTI-FRAME PARTS
MULTIPLER BEFESTIGUNGSRAHMEN
CHÂSSIS MULTI SUPPORT
SOPORTE BASTIDOR MULTIPERCUSIÓN
组合支架 ( 配件 )
멀티 프레임 부품
RD500
『安全へのこころがけ』および『ガススプリング取り扱いに関する注意事項』を必ずお読みください。
Carefully read the contents of this manual, especially all precautions.
Lesen Sie unbedingt die „Vorsichtshinweise für die Handhabung der Gasfeder" und die „Vorsichtsmaßregeln".
Lire attentivement les paragraphes « Précautions de manipulation du ressort à gaz » et « Précautions à observer ».
Lea sin falta las "Precauciones para la manipulación del muelle de gas" y las "Precauciones".
务请阅读"气弹簧支架操作注意事项"和"注意事项" 。
"가스 스프링 취급상의 주의사항" 및 "주의사항" 을 반드시 읽어 주십시오 .
取扱説明書
Mode d'emploi / Manual de instrucciones /
/ Owner's Manual / Bedienungsanleitung /
シロフォン
XYLOPHONE
XYLOPHON
XYLOPHONE
XILÓFONO
木琴
실로폰
YX500FT
使用手册
/
사용설명서
Advertisement
Related Manuals for Yamaha RD500
Summary of Contents for Yamaha RD500
- Page 1 XILÓFONO 组合支架 ( 配件 ) 木琴 멀티 프레임 부품 실로폰 RD500 YX500FT 『安全へのこころがけ』および『ガススプリング取り扱いに関する注意事項』を必ずお読みください。 Carefully read the contents of this manual, especially all precautions. Lesen Sie unbedingt die „Vorsichtshinweise für die Handhabung der Gasfeder“ und die „Vorsichtsmaßregeln“. Lire attentivement les paragraphes « Précautions de manipulation du ressort à gaz » et « Précautions à observer ».
-
Page 2: Preventing Injuries
RD500. instruments such as marching bells, chimes, etc., re- The RD500 rack is specially designed for use with the move the instruments first and then adjust. Adjusting YX335 and YX500FT. Do not modify any instrument the instruments while attached to the rack can result in for installing on the rack. - Page 3 ● In the event of a failure, stop using the instrument and contact the shop where you purchased it. If your dealer is unable to assist you, * Drill two holes, as shown above, to release please contact Yamaha directly as per enclosure. the gas before discarding the gas spring.
- Page 4 Before assembling the frame, please take a look at the parts list and make sure that all of the required parts are accounted for. * If any parts are missing, please contact the dealer where the frame was purchased. ● RD500 (Frame Parts only) A Leg Base Unit (Bass side) ........1 B Leg Base Unit (Treble side) ........1 C Stay .................
- Page 5 Assembly First, assemble the Multi-Frame (RD500) then attach the xylophone set (YX500FT) onto the frame. For safety reasons, make sure that assembly of the Multi-Frame and attaching of the instrument is carried out with two or more persons, and that you assemble the product in an area with adequate space.
- Page 6 Next, attach the instrument to the rack. * Do not let the resonators hit against the legs or other part of the frame during their installation. Align the bolt holes on the underside of the sideboard with the holes Mounting frame on the L-shaped bracket attached to the rack frame and set the in- L bracket...
-
Page 7: Specifications
3. Loosen the two slide guide fi xing bolts and slide the slide guide sections out of the leg column. 4. Loosen the gas spring attached to the bottom of the slide guide and remove. * The two parts are threaded and screw together. Specifi cations RD500 YX500FT ● Height Adjustment: ● Range: F45 – C88 (3-1/2 octave) Gas spring type ●... - Page 8 WV49220 1007 R0 Printed in Japan...
