WARNING:
Adult assembly required.
Item #
9382
9382 Wooden Doll High Chair
Assembly Instructions
We care about your comments. Please call us!
1-800-284-3948
www.MelissaAndDoug.com
c
2013 Melissa & Doug, LLC, P.O. Box 590, Westport, CT 06881
This doll chair is not
intended for child seating.
Use only for toy dolls.
!
WARNING:
CHOKING HAZARD- Small parts.
Not for children under 3 years.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wooden Doll High Chair 9382 and is the answer not in the manual?

Questions and answers

Related Manuals for Melissa & Doug Wooden Doll High Chair 9382

Summary of Contents for Melissa & Doug Wooden Doll High Chair 9382

  • Page 1 9382 Wooden Doll High Chair Assembly Instructions This doll chair is not intended for child seating. Use only for toy dolls. We care about your comments. Please call us! WARNING: WARNING: 1-800-284-3948 Adult assembly required. CHOKING HAZARD- Small parts. Not for children under 3 years. www.MelissaAndDoug.com 2013 Melissa &...
  • Page 2 9382 Wooden Doll High Chair PARTS (B) 1 piece (A) 1 piece (C) 1 piece (D) 1 piece (E) 2 pieces (H) 1 piece (F) 1 piece (G) 1 piece HARDWARE (Shown Actual Size) Hex Key Hex Head Screw 12 pieces 1 piece Barrel Nut 6 pieces...
  • Page 3 9382 Wooden Doll High Chair How to correctly install Barrel Nuts (Images on this page are for example only.) Press a Barrel Nut into the hole in the part making sure that the "+" pattern is facing out. "+" pattern Using a standard screwdriver, turn the Barrel Nut until the threaded hole is facing outward to accept the screw shown below.
  • Page 4 9382 Wooden Doll High Chair STEP 1 Attach seat(A) to front legs(B) with 2 Hex Head Screws. Hex Head Screws Make sure the legs are facing the correct direction, noted below. NOTE: The longer side of the foot support should be facing out.
  • Page 5 9382 Wooden Doll High Chair STEP 3 Hex Head Screws Attach 2 spindles(E) as shown using 2 Hex Head Screws. Assembled Step STEP 4 Attach the Back(F) to the Seat and Armrests as shown using 2 Barrel Nuts first, then 2 Hex Head Screws as shown.
  • Page 6 9382 Wooden Doll High Chair STEP 5 Attach the Rear Legs(G) as shown using 2 Barrel Nuts first then 4 Hex Head Screws. Note: The Spindles already have Hex Head Screws threaded inserts. 4 pieces needed NOTE: The slanted edge on the Rear Legs(G) should match the slanted edge of the Back(F).
