Exibel 38-4768 Quick Start Manual

Wireless headset
Art.no. 38-4768 Model H18
Please read the entire instruction manual before using and save it for
future use. We apologise for any text or photo errors and any changes
of technical data. If you have any questions concerning technical
problems please contact our Customer Service Department.
Safety
•
Check your local regulations regarding mobile phone use in
combination with driving.
• Shut off both the headset and mobile phone in areas where
you are requested to do so, such as hospitals, aircraft or
explosive environments.
only the included USB lead to charge the headset.
• Use
Product description
Bluetooth wireless communication. Keep both hands free when
talking, whether your phone is in your pocket, bag or on a desk.
Ear hook reversible for right side or left side use.
Built-in rechargeable battery. USB charger lead included.
Buttons and functions
Getting started
Recharging the headset
1. Connect the headset to a power source using the included
USB charger lead.
2. When the headset is fully charged the red indicator will turn off.
3. It takes approx. three hours to fully charge the battery for the first
time, and approx 1–2 hours thereafter. When the battery is fully
charged, the indicator light changes to blue.
GREAT BRITAIN - CUSTOMER SERVICE contact number: 08545 300 9799
English
Operation
On/off
• Press and hold the multifunctional button for three seconds.
The indicator light will then flash three times.
• Press and hold the multifunctional button for about five seconds.
The indicator light will again flash three times before turning off.
• The headset gives off short protracted alarm signals when
the battery is weak. Charge the battery if this is the case.
Pairing
Before the headset can be used it must be synchronised with your
mobile phone.
1. Make sure that the headset is off before starting this procedure.
2. Press and hold the multifunctional button for about 4–7 seconds
until the indicator light shines a constant blue. If the headset
looses the connection with the mobile phone the indicator light
will alternate between blue and red.
3. Search for the Bluetooth connection for function in your mobile
and then look for the headset device named "H18".
4. Synchronise the headset using your mobile phone. Enter "0000"
for the password if required.
Answering a call
•
Press the multifunctional button to answer calls.
• If you wish to answer using your phone instead, you
can disconnect the headset by pressing and holding
the multifunctional button for five seconds.
Last-call return
Push and hold in the multifunctional button for about 2–3 seconds.
Call blocking
You can reject a call by pressing and holding the multifunctional button
for 2–3 seconds.
Voice dialling
•
Voice dialling is only possible if your mobile phone supports
this feature.
• Press and hold the multifunctional button until a short beep is
heard, then say the name of the person you wish to ring.
When this function is active the indicator light will display a triple
flash pattern for 10 seconds.
Care and maintenance
• Avoid exposing the product to moisture, damp, high temperatures
and humidity.
•
Clean the product using a soft, lightly moistened cloth.
Never use solvents or strong detergents.
e-mail: customerservice@clasohlson.co.uk
Troubleshooting guide
Indicator flashes red
The headset needs charging. Connect the charge lead to a power
source until the red indicator shines blue or shifts between blue and red.
The headset cannot connect to the mobile phone
Make sure that both the headset and the phone are fully charged and
try to connect again later. Make sure that the distance between units
is no more than 10 metres and that there are no electrical or other
devices that might cause interference between them.
If none of the above solves the problem, refer to the mobile phone's
operating instructions.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local authority.
Specifications
Talk time
Standby time
Weight
Range
Declaration of Conformity
is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
Article 3.1a (Safety): EN 60950-1
Article 3.1b (EMC):
Article 3.2 (Radio):
internet: www.clasohlson.com/uk
Up to 2 hours
Up to 60 hours
6,5 g
Up to 10 m
Hereby, Clas Ohlson AB, declares
that following product(s):
38-4768 / H18 EXIBEL
Bluetooth Hands Free
EN 62479
EN 301489-1
EN 301489-17
EN 300328
Insjön, Sweden, February 2012
Klas Balkow
President
Clas Ohlson, 793 85 Insjön, Sweden
