Page 1: Table Of Contents
MA-101fet Solid State Condenser Microphone Please visit www.mojaveaudio.com for more information including: • Recording Tips • FAQ’s • Customer Service • Warranty Registration CONTENTS INTRODUCTION UNPACKING AND INSPECTION SAFETY INSTRUCTIONS OPERATION CARE OF YOUR MICROPHONE OPERATION OF INTERNAL –15dB PAD... -
Page 2: Introduction
Microphone! Your MA-101fet was carefully designed and constructed using only the finest materials. The MA-101fet microphone is capable of delivering superb performance and, with minimal care, will do so for many years. Your MA-101fet was thoroughly tested and given a factory burn-in prior to shipment. -
Page 3: Safety Instructions
To avoid tripping over the microphone cable, make certain that the cable is not in the way of foot traffic, or suspended in an unsafe manner. Make sure that the microphone stand is secure and not likely to fall. If you have any questions or concerns about operation of your MA-101fet please contact the factory. OPERATION When plugging the microphone in, the three-pin XLR connectors between the microphone and the mic preamp should be inserted gently into their corresponding sockets. -
Page 4: Operation Of Internal -15Db Pad
5. Do not expose the microphone to dusty, smoky or humid environments. 6. Do not attempt repairs unless you are a qualified technician. There are no user serviceable parts in the MA-101fet. 7. Use a soft, lint free cloth to remove fingerprints and other blemishes on the microphone body. -
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS CAPSULES: Interchangeable Cardioid and Omni-directional DIAPHRAGM: .8" (20.5 mm) diameter DIAPHRAM THINKNESS: 3-micron POLAR PATTERN: Cardioid FREQUENCY RESPONSE: 20 Hz-28kHz, +/- 3dB SENSITIVITY: -39 dB re. 1V/pa MAXIMUM SPL: 120 dB pad off, 140dN pad on DISTORTION: <1% @120dB SPL pad off, <1% @135dB SPL pad on SELF NOISE: 14dB nominal, not to exceed 16dB (A weighted) IMPEDANCE:... -
Page 6: Polar Response
POLAR RESPONSE cardioid omni FREQUENCY RESPONSE cardioid omni... -
Page 7: Warranty
WARRANTY Your Mojave Audio product is warranted to the original owner for a period of two years. Mojave Audio guarantees this product to be free from electrical and mechanical defects and will repair or replace defective components, or replace the microphone at Mojave Audio's option. Should service be required for your Mojave Audio product, please contact the manufacturer.
