- Page 1 ML510Dx Managed Industrial Ethernet Switch Quick Installation Guide Release R1.0 Revision No. A05 Document No. 520R69684E...
- Page 2 Actelis Networks reserves the right to revise this publication from time to time and to make changes in the content hereof without obligation to notify any person of such revisions or changes.
- Page 3 Internet: Visit the Actelis Networks World Wide Web site at http://www.actelis.com Email: techsupport@actelis.com • for technical support. Customer support: Contact Actelis Networks Customer Support directly at one of the following numbers: • o Belgium: (0) 800 71180 o Denmark: 80 887 771...
- Page 4 The authority to operate this equipment is conditioned by the requirement that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Actelis Networks, Inc. CE Mark ML510Dx were tested and conforms to the Council Directive LVD 2006/95/EC and EMC 204/108/EC.
- Page 5 10. Many of the cables for this product are supplied by Actelis Networks. Cables that are supplied by the customer must comply with the regulatory inspection authorities and are the responsibility of the customer. To reduce the risk of fire, make sure all cables are UL Listed or CSA Certified.
-
Page 6: Table Of Contents
Preface Contents Overview ..........................1 Package Checklist ........................1 Safety Instructions ........................1 Technical Specifications ......................2 Wall Mounting ........................4 Ethernet Interface (RJ45 Ethernet) ..................4 Ethernet Interface (Fiber, SFP) ....................5 Connecting Power Terminal Block ................... 5 Alarm Relay and Ground ......................6 Craft Connection ........................ -
Page 7: Overview
Installation Guide Overview The ML510Dx Managed Ethernet Switches are designed for supporting standard industrial applications. Managed switches are easier to prioritize, partition, and organize user’s network, providing more reliable and better-quality services. The ML510Dx series has 2 variants – The ML510D Managed Ethernet switch, and the ML510DP which also supports PoE. -
Page 8: Technical Specifications
Installation Guide Technical Specifications Ethernet 10/100/1000 Mbps speed auto-negotiation MDI/MDIX Auto-crossover Copper RJ45 Ports SFP (pluggable Ports) 100/1000Base SFP slot Fiber port connector LC typically for fiber (depends on SFP module) Power Managed series PoE managed series Power input Redundant Input Terminals; Reverse power protection 12-58 VDC Input voltage range 12-58 VDC... - Page 9 Installation Guide DIN-Rail Mounting Mounting steps: 1. Screw the din-clip with screws in the accessory kit (M3). M3 SCREW 2. Hook the unit onto the din-rail. 3. Push the bottom of the unit towards the din-rail until it locks in place. ML510Dx Installation Guide...
-
Page 10: Wall Mounting
Installation Guide Wall Mounting Mounting steps: 1. Screw the wall-mount brackets with screws in the accessory kit (M3). M3 SCREW Ethernet Interface (RJ45 Ethernet) The ML510Dx switch provides two types of Ethernet interfaces: electrical (RJ45) and optical (SFP) interfaces. Connecting the Ethernet interface via RJ45: ●... -
Page 11: Ethernet Interface (Fiber, Sfp)
Installation Guide Ethernet Interface (Fiber, SFP) For both 100/1000 Mbps fiber speed connections, the SFP slots are available. The SFP slot accepts the fiber transceivers that typically have an LC connector. The fiber transceivers have options of multimode, single mode, long-haul or special- application transceivers. -
Page 12: Alarm Relay And Ground
Installation Guide Alarm Relay and Ground The alarm relay output contacts are in the middle of the DC terminal block connector as shown in the figure below. The alarm relay out is “Normal Open”, and it will be closed when detected any predefined failure such as power failures or Ethernet link failures. -
Page 13: Craft Connection
Installation Guide Craft Connection The craft port is for local management by using a terminal emulator or a computer with terminal emulation software. ● DB9 connector connect to computer COM port ● Baud rate: 9600bps ● 8 data bits, 1 stop bit ●... -
Page 14: System Reset
Installation Guide To connect the host PC to the craft port, a RJ45 (male) connector-to-RS232 DB9 (female) connector cable is required. The RJ45 connector of the cable is connected to the CID port of ML510Dx; the DB9 connector of the cable is connected to the PC COM port. -
Page 15: Connect, Login To, And Configure The Ml510Dx
Installation Guide Connect, Login to, and Configure the ML510Dx Connecting to the Ethernet port (RJ45 Ethernet port) of the ML510Dx. Factory default IP: 192.168.1.1 Login with default account and password. Username: admin Password: (none) Change the IP via web Step.1 Go to Configuration → System → IP → IP Interfaces Step.2 Specify IPv4 Address and IPv4 Mask Length Step.3 Go to Configuration →... - Page 16 Installation Guide CLI Initialization & Configuration (Optional) Connecting to the Ethernet port (RJ45 Ethernet port) of the ML510Dx Key-in the command under Telnet: telnet 192.168.1.1 Login with default account and password Username: admin Password: (none) Change the IP with commands listed below: CLI Commands: enable configure terminal...
-
Page 17: Led Status Indications
Installation Guide LED Status Indications LED Name Indicator /color Condition On Green Power A / B power line has power Power A / Power A / B power line disconnect or does not have power Power B supplied On Red Ethernet link fails, alarm or power failure alarm occurs Alarm No Ethernet link fails and no power failure alarm...
