ANTUMBRA

6MIX

BUILDING INSTRUCTIONS

PCB V1.0

Need help?

Do you have a question about the 6MIX and is the answer not in the manual?

Questions and answers

Summary of Contents for ANTUMBRA 6MIX

Page 1 ANTUMBRA 6MIX BUILDING INSTRUCTIONS PCB V1.0...
Page 2 01. BUILD NOTES Before you start building look through the build manual so that you’ll be familiar with the building process and you won’t run into any surprises!
Page 3 02. BUILD 00. Orient the PCB as seen on the left TL072 TL072 TL072 01. Solder the three TL072s TL072 TL072 TL072 (Check their orientation) 02. Solder the two 1n5819 diodes (Check their orientation) TL072 TL072 TL072 03. Solder the 18x 100k resistors...
Page 4 02. BUILD 04. Solder the two 180R resistors TL072 TL072 TL072 TL072 05. Solder the two 470R resistors TL072 TL072 TL072 TL072 06. Solder the two 1k resistors 07. Solder the two 10R resistors TL072 TL072 TL072 TL072...
Page 5 02. BUILD 08. Solder the three 100nF capacitors TL072 TL072 09. Solder the two 10uF capacitors TL072 TL072 (Make sure to match up it’s orientation with the silk- screen drawing) 10. Turn the PCB around TL072 TL072 11. Solder the eight SMD LEDs (this is optional) (The marker on the LED should point to the line on the PCB)
Page 6 02. BUILD 12. Solder the 2x5 pin power header TL072 13. Solder 1x3 pin header (this is optional) TL072 14. Solder 2x3 pin header 15. Turn the PCB back around TL072...
Page 7 02. BUILD DO NOT SOLDER YET! TL072 TL072 TL072 TL072 16. Place the eight jacks TL072 TL072 TL072 TL072 17. Place the two buttons (Their orientation is important, there are two notch- es on one side, they should align up with the notches TL072 TL072 TL072...
Page 8 02. BUILD 20. Now place the front panel on top, put the nuts on the jacks, align everything nicely, and screw in a screw from the front in the spacer as well. If you like how it looks, solder everything on the other side! You are done with building! Congratulations!
