Coopers of Stortford 9255 Instructions For Use Manual

3 in 1 garden vacuum leaf blower-vac/patio cleaner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3 in 1 Garden Vacuum
Please read and retain these instructions for future reference
Leaf Blower-Vac/Patio Cleaner

Technical Specifications

Model
Rated voltage
Rated frequency
Rated power consumption
Mains fuse(delayed action)
Speed
Max air speed
Max.air volume
Bag volume
Weight
Measured LpA at operator's position
Measured LwA of the machine:
Vibration
9255
GY 8113
230V-240V
50Hz
3000W
13A
15000 rpm
270km/h
13.2m³/min
35L
7.3kg (net)
88.3dB(A), uncertainty K=3dB(A)
max 99.8dB(A), K=2.0dB (A), guaranteed LwA: 102dB(A)
2
max. 1.29m/s
, K = 1.5m/s
Instructions for Use
2
v005: 17/04/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9255 and is the answer not in the manual?

Questions and answers

Related Manuals for Coopers of Stortford 9255

Summary of Contents for Coopers of Stortford 9255

  • Page 1: Technical Specifications

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 Leaf Blower-Vac/Patio Cleaner Technical Specifications Model GY 8113 Rated voltage 230V-240V Rated frequency 50Hz Rated power consumption 3000W Mains fuse(delayed action)

  • Page 2: Table Of Contents

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 Contents Technical Specifications ............................1 List of components ...............................3 Operative range ..............................3 Start assembly ..............................3 Mounting the handle ............................4 Before starting ..............................4 WORKING IN VACUUM MODE ..........................6...

  • Page 3: List Of Components

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 List of components Ergonomic handle ON/OFF switch Collecting bag Electric motor Impeller Function switch Wheel Blower outlet Vacuum inlet 10 Handle release button...

  • Page 4: Mounting The Handle

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 Mounting the handle Fig. 1 To mount the handle press the button at the rear top of the vacuum/blower unit, pull the upper handle arm upwards until it locks in position.
  • Page 5 3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 5. Always direct the cable backwards, away from the device. 6. If a cable should be damaged during operation, switch the device off and disconnect the mains cable from the mains supply.

  • Page 6: Working In Vacuum Mode

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 WORKING IN VACUUM MODE(Fig.3) Make sure that the unit is switched off (on/off switch in Off position). Turn the function switch (6) clockwise until the arrow of the switch is aligned with the arrow of the vacuum mode(VAC).

  • Page 7: Emptying The Bag

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 Fig. 5 Fig. 6 EMPTYING THE BAG(Fig.5-6-7) If the bag is full, switch off the vacuum at the handle and pull the plug.

  • Page 8: Attaching The Collecting Bag (Fig. 6)

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 ATTACHING THE COLLECTING BAG (Fig. 6) Insert the lower two feet of the bag’s frame into the supports at the rear end of the chassis.

  • Page 9: Proper Use

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 SYMBOL DESCRIPTION Disconnect mains plug before carrying out any repairs! If the cable is damaged, disconnect from the mains immediately and replace cable!

  • Page 10: Safety Instructions

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 SAFETY INSTRUCTIONS 1 NEVER ALLOW PERSONS, WHO ARE NOT FAMILIAR WITH THESE INSTRUCTIONS, TO USE THE DEVICE. 2 DO NOT OPERATE THE GARDEN VAC WITHOUT THE COLLECTION BAG PROPERLY ATTACHED. IF THE COLLECTION BAG IS NOT PROPERLY ATTACHED, THE MACHINE MAY UNINTENTIONALLY MOVE FORWARDS AND THROW OUT OBJECTS THROUGH THE BLOWOUT OPENING.

  • Page 11: Maintenance And Storge

    3 in 1 Garden Vacuum Instructions for Use 9255 Please read and retain these instructions for future reference v005: 17/04/19 (10) IT IS RECOMMENDED TO CONNECT THE MACHINE TO THE MAINS SUPPLY OVER A RESIDUAL CURRENT OPERATED DEVICE WITH A MAXIMUM BREAKING CURRENT OF 30MA.

  • Page 12: Vacuum And Blower Function Switch

    At the end of the product’s lifespan please dispose of it at an authorised household WEEE waste recycling centre. DECLARATION OF CONFORMITY Coopers of Stortford that the 3 in 1 Garden Vacuum 9255, (Model No. GY 8113) Conforms to the following European Directives and standards Machinery Directive 2006/42/EC...
