Summary of Contents for SCOOP SC100
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION PAGE 2 THIS OWNER’S MANUAL CONTAINS ASSEMBLY, OPERATION, MAINTENANCE AND SAFETY INFORMATION. IN THE INTEREST OF SAFETY, PLEASE MAKE CERTAIN THAT YOU READ AND UNDERSTAND ALL THE INFORMATION BELOW. IMPORTANT SAFETY PRECAUTIONS Read the OWNER’S OPERATING MANUAL and all accompanying literature and follow it carefully before using your machine. -
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE 3 1/ IMPORTANT SAFETY INFORMATIO IMPORTANT SAFETY INFORMATION PAGE 2 TABLE OF CONTENTS PAGE THIS OWNER’S MANUAL CONTAINS A INFORMATION. IN THE INTEREST OF S BEFORE YOU BEGIN PAGE 4 UNDERSTAND ALL THE INFORMATION UNPACKING PAGE 6 ASSEMBLY PAGE 8 IMPORTANT SAFETY PRECAUTIONS... -
Page 4: Before You Begin
BEFORE YOU BEGIN PAGE 4 PART NO PART DESCRIPTION MAIN BODY DOME-SHAPED C-CLIPS PEDAL FRAMES AND COVERS BASE TUBE WASHERS BOLTS... - Page 5 BEFORE YOU BEGIN PAGE 5 IMPORTANT: Read all instructions carefully. Assemble the SCOOP in accordance with the steps in the manual. All tools required for assembly are included with your SCOOP. Lay out all parts on the floor. Make sure that you have all the parts listed below before beginning assembly. In case of discrepancy, please contact SCOOP at 844-GOSCOOP (467-2667) or service@scoopfit.com. PRE-ASSEMBLY CHECK LIST...
-
Page 6: Unpacking
UNPACKING PAGE 6 Step 1: Lift top flap Step 2: Cut box as shown on outside of box and open towards you... - Page 7 UNPACKING PAGE 7 Step 1: Remove entire contents of the box as one unit as shown. Place the unit on the floor with box positioned as shown. Step 2: Remove the foam top, the pedals, hardware pack and the base tube, leaving just the main body in the lower foam packaging.
-
Page 8: Assembly
ASSEMBLY PAGE 8 Step 3: Note that there is a decal on the base tube that says ‘This side down.’ Place the base tube on the main body so the decal remains visible during this assembly step and will face the floor after being fully assembled and ready for use. Step 4: Find the two bolts and the two washers, and first install the washers onto the bolts... - Page 9 ASSEMBLY PAGE 9 Step 5: Once the base tube has been fully secured, lift the main body from the foam packaging and place it on the floor as shown. Step 6: Taking one pedal at a time, slide the pedal onto the shaft as shown in Fig 6 below. After sliding the pedal onto the shaft, press the dome-shaped C-clip as shown onto the end of the shaft until it is secure. When the C-clip is fully secured, there will be a click sound. Test the pedal by pulling on it to determine whether it is locked in place by the C-clip. Dome-shaped C-clips...
-
Page 10: Console Operation
CONSOLE OPERATION PAGE 10 The console has three main modes of operation (time, calories, strides/minute), along with a scan mode. Use this mode to view workout time. Workout time TIME COUNT automatically accumulates as you exercise. Use this mode to view an estimate of calories burnt CALORIE through exercise. These numbers accumulate through COUNT the workout. STRIDES/ Use this mode to view rotations per minute. This MINUTE figure increases and decreases to reflect the speed at COUNT which you are exercising. Push the MODE/RESET key to select the mode that MODE/RESET you intend to view. To clear the setting, hold this key down for two seconds. - Page 11 CONSOLE OPERATION PAGE 11 NOTE: 1. If the display is faint or shows no figures, please replace the batteries. The console will power up when movement is detected. 3. If no movement is detected for four minutes, the console will shut off. If no movement is detected for four seconds, the word STOP will appear in the upper left corner of the console. This message will disappear when movement resumes. 5. The console will start calculating when you start exercising and stop calculating after no movement is detected for four seconds. Other Specs: Battery type: 1 pc LR44 (1.5V) Operating temperature: 0°C to +40°C...
- Page 12 Please contact SCOOP directly for any issues or concerns regarding your SCOOP. 844-GOSCOOP(467-2667) or service@scoopfit.com This product is patented in the US and other International Patents and patents pending. US Patent Number 7,108,638...
