Ignite, Inspire, Indulge
Questions, problems, missing parts?
Before returning to your retailer, our exceptional customer service is available.
Call toll-free
(866)
866) 985-7877
Email
cservice@primepelletgrills.com
Live chat
www.primepelletgrills.com
9 a.m. – 9 p.m., EST
9 a.m. - 4 p.m., EST, Monday - Friday
Prime Pellet Grill - KC King 600
This product can expose you to chemicals
including Carbon Monoxide, Lead, Chromium
(hexavalent compounds), Di(2-ethylhexyl)
phthalate (DEHP) and Diisononyl phthalate (DINP),
which are known to the State of California to cause
cancer and birth defects or other reproductive
harm. For more information, go to
www.P65Warnings.ca.gov.
Item#: 81221
WARNING
FOR YOUR SAFETY
1. Please read this entire manual before
installation and use of this pellet fuel-
burning appliance. Failure to follow these
instructions could result in property
damage, bodily injury, or even death.
2. Contact local building or fire officials
about restrictions and installation
inspection requirements in your area.
3. Save these instructions for future
reference.
WARNING
For Outdoor Use Only
WARNING
ATTACH YOUR
RECEIPT HERE
Keep a copy of your proof of
purchase or order confirmation
which will be needed if you
need to contact us about
warranty coverage.
Purchase Date:
12032019
Advertisement
Table of Contents
Related Manuals for Prime Grill KC King 600
Summary of Contents for Prime Grill KC King 600
- Page 1 Prime Pellet Grill - KC King 600 Item#: 81221 WARNING FOR YOUR SAFETY Ignite, Inspire, Indulge 1. Please read this entire manual before installation and use of this pellet fuel- burning appliance. Failure to follow these instructions could result in property damage, bodily injury, or even death.
-
Page 2: Table Of Contents
TABLE OF CONTENTS / BEFORE YOU BEGIN TABLE OF CONTENTS BEFORE YOU BEGIN Please read and understand this entire manual before Table of Contents Page 2 attempting to assemble, operate or install this appliance. If you have any questions regarding the product, Before You Begin Page 2 please contact Customer Service. -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION & Grill Body Wheeled Leg (A & B) Support Leg (A & B) Leg Brace (x2) Haul Handle Grill Door Handle Chimney Chimney Gasket Prep Shelf Drip Pail Heat Baffle Drip Pan Main Cooking Grate & Upper Cooking Grate Contact us for assistance: (866) 985-7877 | www.primepelletgrills.com COMPONENTS | 3... -
Page 4: Hardware Contents & Tools Included
HARDWARE CONTENTS & TOOLS INCLUDED HARDWARE CONTENTS TOOLS INCLUDED Hex Bolt Bolt Bolt Bolt 1/4x20mm 1/4x20mm 5/16 5/16-18x85mm 5/16-18x65mm Wrench Hex Key Hex Bolt Hex Bolt Hex Bolt Hex Bolt Hex Bolt Hex Bolt Bolt Bolt Bolt Bolt Bolt Bolt Bolt Bolt Bolt... -
Page 5: Safety Information
SAFETY INFORMATION SAFETY INFORMATION DANGER WARNING WARNING WARNING • By-products of the combustion fuel used EXPLOSION—FIRE HAZARD • Installation and repair should be done by BURN HAZARD by this product contain chemicals known to a qualified service person. The grill should •... -
Page 6: Assembly Pages
ASSEMBLY A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS. PREPARATION Before beginning assembly, be sure to empty contents of carton and make sure all parts are present. READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE APPLIANCE. Place all parts on a soft, level surface for assembly. - Page 7 ASSEMBLY Attach the Leg Brace between the Support Legs using 4 Bolts D. Repeat to install the Leg Brace between the Wheeled Legs Once all 8 Bolts are seated, fully tighten all hardware installed to this point. With assistance, carefully turn the grill back upright. Hardware Used: D Bolt (1/4x20) x8 Install the Chimney...
- Page 8 ASSEMBLY Attach the Grill Door Handle : Select two Hex Bolts A and Washers G. Place the Washers on the Hex Bolts and insert one through each eyelet in the grill door into either end of the Grill Door Handle. Fully tighten both Hex Bolts. Hardware Used: A Hex Bolt (1/4x20) x2 G Washer (1/4) x2...
- Page 9 ASSEMBLY Install the Prep Shelf using 4 Shelf Axles J as shown. Fully tighten after all Shelf Axles are inserted finger-tight. Hardware Used: J Shelf Axles x 4 NOTE: The Prep Shelf folds for transportation and storage. Simply lift up near the Axles and hinge the Shelf down flat.
- Page 10 ASSEMBLY Place the interior components: First insert the Heat Baffle , ensuring that it is properly seated over the fire pot. Position the Drip Pan & aligned with the grease drain tube. Finally, add the Main Cooking Grate & and the Upper Cooking Grate Hang the Drip Pail below the drain.
-
Page 11: First Start-Up Pages
FIRST START-UP FIRST START-UP auger tube to be “charged” with pellets. WARNING: Before use, place your Prime Pellet Grill on a non-combustible surface in accordance with local fire safety ordinances. Do not use under a combustible ceiling or overhang. You must follow these steps before first use (prior to adding pellets), or whenever the grill runs completely out of pellets. Take out the interior components including cooking grates, grease Take out the interior components including cooking grates, drip pan, Smoke... - Page 12 FIRST START-UP Check the pellet hopper and the auger for foreign objects, which can jam the auger. Turn the switch to ON (I) and rotate the dial to IGNITE. Verify that the auger is rotating inside the hopper. ats up. CAUTION! Do not touch the heating rod. Carefully extend your hand over the fire pot to confirm air movement from the draft fan.
- Page 13 FIRST START-UP FIRST START-UP Pour Prime Pellet Grill Hardwood Pellets into the hopper and set Pour Prime Pellet Grill Hardwood Pellets into the hopper and set the temperature dial to MAX. the temperature dial to HIGH. CALL SERVICE ait a moment, then with pellets still in the CALL SERVICE Pellets will begin to be deposited into the fire pot.
- Page 14 CALL SERVICE FIRST START-UP FIRST START-UP Smoke Shut D own High Cycle Smoke Smoke Smoke Power Wait until the first flames are visible in the fire pot. Then set the Shut D own High Shut D own High dial to BURN OFF and turn the switch to OFF (O). Let the grill cool. Shut D own High dial to BURN OFF and turn the switch to OFF (O).
- Page 15 INITIAL FIRING INSTRUC INITIAL FIRING INSTRUC FIRST START-UP FIRST START-UP FIRST START-UP Leaving the grill door up, turn the switch to ON (I) and the dial to Leaving the grill door up, turn the switch to ON (I) and the dial to Leaving the grill door up, turn the switch to ON (I) and the dial to IGNITE.
-
Page 16: Grill Functions
GRILL FUNCTIONS WARNING! Shutting Down the Grill: Burn Off Setting Always start the grill with the door open and the dial set to IGNITE. After pellets ignite and produce smoke, close the lid and adjust the dial to your This grill features an automatic shut down cycle. When you’re done cooking, preferred cooking temperature. -
Page 17: Everyday Grilling
INITIAL FIRING INSTRUC INITIAL FIRING INSTRU EVERYDAY GRILLING INITIAL FIRING INSTRUC INITIAL FIRING INSTRU EVERYDAY GRILLING EVERYDAY GRILLING Open the door and turn the grill power to ON (I). Set the Open the door and turn the grill power to ON (I). Set the Open the door and turn the grill power to ON (I). - Page 18 REIGNITING YOUR G REIGNITING YOUR G REIGNITING YOUR GRILL REIGNITING YOUR GRILL WARNING! REIGNITING YOUR GRILL WARNING! WARNING! If your grill fails to light, or if the fire in the fire pot goes out while cooking (and there are still pellets in the hopper), take the following action to avoid “over-firing” your grill with excess unburned pellets in the fire pot.
-
Page 19: Reigniting Your Grill Pages
NING! You must remove all unburned pellets and ash REIGNITING YOUR GRILL REIGNITING YOUR GRILL DANGER! If the grill failed to light or Open the door and remove all food, on on ash removal. the porcelain-coated grill grates, the (O) and disconnect the power cord. grease drain pan, and the upper and WARNING! You must remove all unburned pellets and ash WARNING! You must remove all unburned pellets and ash... - Page 20 REIGNITING YOUR GRILL REIGNITING YOUR GRILL REIGNITING YOUR GRILL to OFF (O) and let the grill cool. After the grill is cool you can After verifying that there are flames in the fire pot, turn the switch to OFF (O) and let the grill cool. After the grill is cool you can to OFF (O) and let the grill cool.
-
Page 21: Getting To Know Your Prime Pellet Grill Pages
GETTING TO KNOW YOUR PRIME PELLET GRILL 1. During grilling, adjust the dial at any time to grill hotter or cooler, or to adjust smokiness. The HIGH setting is for grilling, while the IGNITE setting is for smoking or adding smoke flavor to foods during cooking. - Page 22 GETTING TO KNOW YOUR PRIME PELLET GRILL DIGITAL READOUT The digital display on your grill shows the current interior temperature of the grill by default. Immediately after adjusting the temperature dial, the desired temperature setting will flash five times before reverting to the current interior temperature. For more precise monitoring of your food items, use the included probe thermometers.
-
Page 23: Care Of Your Prime Pellet Grill Pages
CARE OF YOUR PRIME PELLET GRILL MAINTAINING YOUR PRIME PELLET GRILL Removing Grease 1. CREOSOTE/GREASE ACCUMULATION DANGER! Turn the switch to OFF (O) and unplug the grill before cleaning. AND REMOVAL CAUTION! Accumulated grease is easier to clean off when the grill is still warm, NOT HOT. - Page 24 CARE OF YOUR PRIME PELLET GRILL Storage When the grill is cold, you can use a shop-vac or other vacuum to clean ash from in and around the fire pot. A utility-type vacuum cleaner with metal collection CAUTION! If the grill is stored outside during rainy season, be sure that water can receptacle is best, but other types of vacuums can be used.
-
Page 25: Troubleshooting Pages
TROUBLESHOOTING From time to time in every griller’s life, a problem arises. Here’s how to address the most common issues you may encounter. HELP! My grill won’t ignite. HELP! There are no pellets in the fire pot. • Scenario A: The grill is getting power, but no pellets are moving into the fire pot: STEP 1 Check the hopper. - Page 26 TROUBLESHOOTING HELP! I need to remove the auger. HELP! My problem isn’t listed, or I need to order a part. • Contact Prime Pellet Grills Customer Service at 866-985-7877 or via email DANGER! Turn the grill switch OFF (O) and UNPLUG THE POWER CORD. cservice@primepelletgrills.com.
-
Page 27: Warranty | 27
3 YEAR LIMITED WARRANTY Customers in the Contiguous US All components are warranted for a period of 3 years after date of purchase by the original owner against defects • THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED ABOVE in materials and workmanship under normal use. This warranty does NOT cover normal wear and weathering, •...
