Opalum FLOW Series Pairing Manual

Opalum® FLOW series
Opalum® STREAM series
Remote control pairing guide
The Opalum FLOW and STREAM series systems uses radio frequency (RF) remote controls. To not
interfere with other Opalum systems or similar RF equipment each control hub and remote control
is manufactured and sold as a unique pair. However, if the remote control or control hub is
replaced it is easy to re-pair the new couple to enable communication.
Step 1: Disconnect the power supply from the control hub and from the wall socket.
Open up the remote control using the provided remote control opener pin (or a similar
Step 2:
thin sturdy object). Insert pin in the hole on the back of the remote control marked
"Push here to open". Push firmly inwards until front panel and housing is separated.
Fig 1: Remote
control opener
pin
Step 3: Remove both batteries from the battery holder.
Step 4: Next to the battery holder is a three pin connector with a jumper installed over two of
the pins. Figure 3 shows the normal operating position of the jumper.
Fig 3: Jumper in normal operating position
Fig 2: Push to open
the remote control
Jumper in NORMAL mode
Remote control pairing guide v1.01
w w w . o p a l u m . c o m
1/2
