  • Page 1 Semen Quality Analyzer User Manual X1 PRO Rev.29-0X10002 20200629X1E001...
  • Page 2 Please read this user manual carefully first, to ensure proper use of the product. This user manual is also available at www.LENSHOOKE.com. Symbols The following icons may appear in the content of this user manual. Symbol for “NOTICE” Symbol for “CAUTION”...

  • Page 3: Table Of Contents

    Table of Contents ............................Introduction Intended Use ......................................................III. Product Overview ............................Consumables ............................. Major Function ............................Accessories ............................. Getting Started VII........................Cleaning & Maintenance VIII............................Error Message ........................Analyzer Specifications .............................. Reference ............................. Statement XII........................XIII.

  • Page 4: Introduction

    I. Introduction LensHooke X1 PRO Semen Quality Analyzer is for in vitro diagnostic only. The user should read this User ® Manual first, to get familiar with the device and its proper operation procedure prior to use the analyzer. LensHooke Semen Test Cassette”...

  • Page 5: Product Overview

    III. Product Overview LensHooke X1 PRO Semen Quality Analyzer ® Top View 140.00mm Front View Rear View Touch Screen USB Port Test Cassette Insert Slot USB Port Power Button HDMI Port Reset Button Power Adaptor Port NOTE USB Port : USB 2.0 Reset Button : If the analyzer crashes, please use a pin to press the reset button.
  • Page 6 Touch Screen Icon 1 2 3 4 5 2019/11/01 21:42 HDMI connection icon: This analyzer is connected to monitor by a HDMI port. USB connection icon: This analyzer is connected to a USB Drive. Thermal Receipt Printer connection icon: This analyzer is connected to a Thermal Receipt Printer. Power Adaptor connection icon: This analyzer is connected to a power adaptor.

  • Page 7: Consumables

    ® Cleaning Wipe X QC Beads (For Semen) X QC Reticle (For Semen) The result will be inaccurate, if you DO NOT use a LensHooke Semen Test Cassette. ® NOTE Product pictures are schematic diagrams only. Please refer to the actual products.

  • Page 8: Major Function

    V. Major Function LensHooke X1 PRO Semen Quality Analyzer ® Turn on / off Turning on the analyzer: Push the power button down for 2 seconds to turn on the analyzer (as Image 1). When the touch screen lights up (as Image 2), the analyzer is ready to operate.
  • Page 9 2. Check if the analyzer is under the normal operating environment. 3. Check battery status. If the battery is low, connect the power adaptor before testing. Prepare the Sample Refer to the LensHooke Semen Test Cassette user manual to prepare the sample. ®...
  • Page 10 Test the Sample New Test Step 1. Select the “New Test” icon. Step 2. Please input the patient ID number and select the “ ” icon to go to the next step. 2019/11/01 21:42 2019/11/01 21:42 NOTE DO NOT exceed 20 characters and symbols for the patient ID#. If you want to input a letter, please hold the icon for around 1 second and select the letter.
  • Page 11 2019/11/01 21:42 2019/11/01 21:42 NOTE Please select to adjust the semen volume. DO NOT move the cassette or analyzer during the results calculation. Step 4. Insert the test cassette (with sample) into the slot and push it to the end. 2019/11/01 21:42 Review the Test Result Recent Tests...
  • Page 12 Quality Control (1) Select “Utilities” and then select the “Quality Control” icon. 2019/11/01 21:42 2019/11/01 21:42 (2) Please input the LOT number on the label of the LensHooke X QC Beads (For Semen) or ® LensHooke X QC Reticle (For Semen). Please confirm the LOT number and then select “...
  • Page 13 (12)240626 Reticle (10)19062725082 X QC CON. 25±3M/ml (4) Please follow up the instructions of LensHooke X QC Beads (For Semen) or LensHooke X QC ® ® Reticle (For Semen) to operate and then insert the cassette into the “Insert Slot”.
  • Page 14 LensHooke 2018/11/01 21:42 2019/11/01 21:42 If N/A shows on the result screen, it means that the LensHooke X QC Beads (For Semen) or ® LensHooke X QC Reticle (For Semen) is expired. Please use another new one or contact customer ®...
  • Page 15 Backup All Records (1) Prepare a USB Drive in advance. (Capacity : 1GB or more) (2) Select “Utilities” and then select “Backup All Records”. 2019/11/01 21:42 2019/11/01 21:42 (3) Insert the USB Drive. When the “Backup” icon turns blue, select it to backup the records. 2019/11/01 21:42 2019/11/01 21:42 When the records have been backed up to your USB Drive successfully, select the “OK”...
  • Page 16 System Update (1) Prepare the a USB Drive with system update software. (Capacity : 1GB or more) (Please contact with your local distributor for the system update software). (2) Select “Utilities” and then select the “System Update” icon. 2019/11/01 21:42 2019/11/01 21:42 Please connect the device with the power adaptor, and plug the USB Drive with the update file into the analyzer.
  • Page 17 NOTE If the ‘‘Update File is Corrupted’’ warning message appears on the screen, it means you did not download the complete file. Please download the system update file again to the USB Drive and redo the system update. If the ‘‘Update Failed’’ warning message appears on the screen, it means the USB Drive for system update has been removed, please insert the USB Drive with system update file again to redo the system update.
  • Page 18 (2) Select the yellow ‘‘Delete’’ icon to confirm and delete all the records. 2019/11/01 21:42 2019/11/01 21:42 (3) Select the ‘‘OK’’ icon to return to the previous page. 2019/11/01 21:42 2019/11/01 21:42 NOTE The records cannot be recovered after you delete them. Make sure you want to delete them perma- nently before selecting the ‘‘Delete’’...
  • Page 19 (5) Select the “Insert” icon and wait until the message of “Insert successfully!” appears on the screen. 2019/11/01 21:42 2019/11/01 21:42 2019/11/01 21:42 NOTE The LOGO image must be in PNG format by 2040x168 pixels, and file has to be named “lenshooke_X1_pdf_logo.png”.
  • Page 20 Date & Time (1) Select “Settings” and then select the “Date & Time” icon. 2019/11/01 21:42 2019/11/01 21:42 (2) You can select the format of the date by selecting the icon “ ” or “ ”, and adjust date & time by selecting “...
  • Page 21 The default setting is “Automatic”. When you choose this icon, the device use dynamic IP address, which is assigned when the network is connected and changes over time. 2019/11/01 21:42 (4) If you want to change to the static IP address, please select “Manual” and then select “IP address”, “Subnet Mask”, “Gateway”...
  • Page 22 Access Password (1) Select “Settings” and then select the “Access Password” icon. 2019/11/01 21:42 2019/11/01 21:42 (2) Select “Admin Password” icon. Switch on “ ” of Admin Password to secure your access. 2019/11/01 21:42 2019/11/01 21:42 Input any six characters as your new Admin Password, and then select the “ ”...
  • Page 23 LAN Password (1) Select “Settings” and then select the “Access Password” icon. 2019/11/01 21:42 2019/11/01 21:42 Select the “LAN Password” icon, and the password will appear on the screen. If you want to change this LAN Password, you can select “Change”. 2019/11/01 21:42 2019/11/01 21:42 Input any six-digit numeric code to set up the new password.
  • Page 24 Brightness (1) Select “Settings” and then select the “Brightness” icon. 2019/11/01 21:42 2019/11/01 21:42 (2) Adjust the brightness of the screen by selecting “ ” or “ ”, and then select the “ ” icon to return to the previous page. 2019/11/01 21:42 2019/11/01 21:42...

  • Page 25: Accessories

    VI . Accessories License Dongle To Refill the License When you unpack the LensHooke Semen Test Cassette box, you will find the license dongle on ® the top. (2) Please check if the test cassette type is correct before you insert the dongle to refill the license.
  • Page 26 Once the license dongle has been used with the analyzer, it cannot be used again. If you insert this dongle again, the dongle error message will appear on the screen. 2019/11/01 21:42 Please insert the dongle to refill the license immediately after unpacking the box of the LensHooke ® Semen Test Cassette.
  • Page 27 Please use one of the following browers to access the login page. - Firefox (Ver: 62 or more), Chrome (Ver: 69 or more), Microsoft Edge for Window 10, and Safari...etc. (Please refer to www.LensHooke.com for more details.) Only support iPad, PC or laptop.
  • Page 28 To connect the Barcode Scanner to the Analyzer Please connect the barcode scanner to the the analyzer using the USB Port. The barcode scanner to input the patient's ID or the LOT of LensHooke X QC Beads (For Semen) ®...

  • Page 29: Getting Started

    Cleaning Wipe is single-use only. DO NOT reuse. ® Keep LensHooke X1 PRO Semen Quality Analyzer away from dust, water or any liquids, and ® extreme environment (which is beyond the operation or storage environment stated in the specifi- cation).
  • Page 30 I. Test Cassette Insert Slot: Turn off the analyzer before cleaning. Prepare 2 pcs of LensHooke Cleaning Wipe. ® Please drop 4 drops of the 75% alcohol for each 2 sides of a LensHooke Cleaning Wipe. ® FLIP DROPS DROPS...
  • Page 31 Allow surface to remain wet for 2 minute. Allow to air dry. Your LensHooke X1 PRO Semen Quality Analyzer has been tested to ensure that there is no change ® in performance or external materials of the analyzer after 10,950 cleaning cycles and 10,950 disinfecting cycles.

  • Page 32: Error Message

    Please remove the test cassette and select the “OK” icon to return to home page. Please insert another new test cassette redo the action. If this message still appears, contact our customer service. *Make sure you're using correct LensHooke Semen ® Test Cassette. Error 4: 2019/11/01 21:42 Software Error.

  • Page 33: Analyzer Specifications

    X. Analyzer Specifications Analyzer name Power adaptor: LensHooke X1 PRO Semen Quality Analyzer Input: 100~240 Vac, 50~60 Hz,0.5 A ® Output: 5 Vdc, 2 A Max Control panel Operation environment 3.5-in resistive touch screen Temperature 15°C ~ 38°C (59°F ~ 100°F) External power input Humidity <70%...

  • Page 34: Statement

    Avoid strangulation resulting from baby or child entanglement in monitoring cables. Avoid choking resulting from a child swallowing a small part. The test result is followed WHO Laboratory Manual for the Examination and Processing of Human Semen. Please refer to the user manual of LensHooke Semen Test Cassette. ®...

  • Page 35: Warranty

    XIV. Warranty Bonraybio offers a one-year warranty from the day you purchase the LensHooke X1 PRO Semen ® Quality Analyzer. During the warranty period, we will repair or replace the analyzer free of charge. The warranty only applies to the original LensHooke X1 PRO Semen Quality Analyzer from Bonraybio.
