Dyegoo GT06 User Manual

Vehicle tracker (gps+gsm+sms/gprs)
Hide thumbs Also See for GT06:

Advertisement

Table of Contents

GPS Vehicle tracker
(GPS+GSM+SMS/GPRS)
GT06 User Manual
(Version 3.2)
Thank you for purchasing the tracker. This manual shows how to operate the device
smoothly and correctly. Make sure to read this manual carefully before using this
product. Please note that specification and information are subject to changes without
prior notice in this manual. Any change will be integrated in the latest release. The
manufacturer assumes no responsibility for any errors or omissions in this document.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT06 and is the answer not in the manual?

Questions and answers

Related Manuals for Dyegoo GT06

Summary of Contents for Dyegoo GT06

  • Page 1 GPS Vehicle tracker (GPS+GSM+SMS/GPRS) GT06 User Manual (Version 3.2) Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.
  • Page 2 1. Summary Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. Overview of the characteristics: 1.GSM 850/900/1800/1900MHZ. 2.GPS position. 3.Auto set APN. 4.200Mah Battery inside, Power-Cut alarm. 5.Motion detect, save GPRS flow and power.
  • Page 3 Power line: Relay: Microphone: SOS line: Manual...

  • Page 5: Device Status Indicators

    4. Wire defined 5.Device status indicators 5.1 Connect DC 9-40V power supply,push the switch(switch beside the sim card holder), the red LED will light continuously. 5.2 The blue LED light continuously when searching the GPS signals. When GPS position,the blue LED flashing. 5.3 The intermediate green LED (GSM signal state) GSM signal is normal, green LED flashing.
  • Page 6 6.12 Choose SIM card. Please insert a SIM card which support GSM 2G network to the device. Please take dealer’s advice as reference. 6.13 SIM card installation. Discharge the cover of the device and uncover the SIM card holder. Then insert the SIM card and cover SIM card holder (as follows). 6.14 Open the cover, Push the switch.

  • Page 7: User Settings

    receiving side of the device is face up and without metal cover. Note: The metal cover will lessen the receiving of GPS signals. 7. Device wiring requirements 7.1 The device power supply is DC 9-40V. The red line is positive pole while the black line is negative pole.
  • Page 8 1)Center Number Text Parameter Sample command CENTER 710#number# 710#13500135000# 711#number# 711#13800138000# CENTER D01# D01# D02# D02# 1)Center number can control the oil and power and resume factory settings 2) Center number can receive the call and text of vibration alarm and over speeding alarm. Command 3) SIM must display the income call number to control Description...
  • Page 9 Text Parameter Sample command View 901# 901# Command This directive is used to view Device Manager number. Description Successful Setting：Admin1: Command Feedback Admin2: 3)Authorized Number Set Text Parameter Sample command 1：101#13800138000# Authorized 101# number # 2：102#12345678912# 102# number # 3：103#12345678912# 103# number # Authorized D11#...
  • Page 10 Add Authorization account 1 Command Successful Setting： Feedback View Authorized Number Text Parameter Sample command View C10# C10# authorized Command This directive is used to view the equipment Description authorization number Command Successful Setting： Authorization 1： Feedback Authorization 2： Authorization 3： 5)APN Setting Text Parameter...
  • Page 11 Description 1，and Sample 2 for no password. Command Successful Setting：SET APN OK！ Feedback Server Text Parameter Sample command 1：803#gps.dyegoo.net#6100# SERVER 803#SERVER # Parameter port# 2: 803#47.90.39.27#6100# View 1）CIP# CIP# SERVER Change the IP and port when move to a new server Command port：10~65535...
  • Page 12 TIMEER Parameter 730#uploading interval# 730#20# setting Time scope：0，10~60 seconds； 0,no data uploading； Command 10~60,means time interval；the default value is 15 Description seconds！ Command Successful Setting：SET TIMER OK！ Feedback 8)Static Time Interval Text Parameter Sample command STATIC SUP#time interval# SUP#5# Timescope：1~60 minutes；The device has Command 3D transmission and the default time interval are 5 Description...
  • Page 13 command NUP# NUP# This command is used to cancel sending data to the Command platform Description If need again to restore the upload , you need to send TIMEER Parameter setting. Command SET OK！ Feedback 10)Oil-Cut Text Parameter Sample command RELAY 222# 222#...

  • Page 14: Vibration Alarm

    20KM/H, the device will cut off the oil or the power when the speed below 20KM/H. Successful Setting：Fuel cut has already been completed Feedback 11)GMT Text Parameter Sample command 801#location, 801#E8# time# Command The default time zone is Beijing time. If time zone need Description revised, please operate according to the above command.

  • Page 15: Speed Alarm

    VIBRATION 123#sensitivity#alarming way# 1) 123#2#3# Parameter Set into 1) V123#2# vibration V123#2# 2) V123#1# alarm time Cancel vibration 456# 456# alarm the sensitivity value of the vibration is from 1 to Command 5，1is the most sensitive and o is close. Alarming Description ways: 1, calling 2, texting, 3 calling and texting.

  • Page 16: Acc Alarm

    The speed scope is form 60-220, if the speed is no this Command cope, the alarm is off. Alarming ：1, calling 2, texting, 3 calling and texting. Description Must set the center number and receiving number. Command Successful Setting：set speeding alarm，OK! Feedback 14)ACC Alarm Text...

  • Page 17: Language Setting

    Feedback Successful Setting：Reset system, ok! 16)Factory Text Parameter Sample command Parameter 940# 940# Restore the factory setting Description Only center number can initial this function Factory setting will recover to the original setting Successful Setting：FACTORY OK！ Feedback 17)Language Setting command Parameter Sample LANG1# 1:CHINESE，...

  • Page 18: Geo-Fence Setting

    URL link when in English language setting. Successful Setting：SET LANG OK！ Feedback GEO-fence Setting Text Parameter Sample command Setting 920#radius#way# 920#1#2# Cancel 921# 921# Setting Geo-fence alarm, radius from 1-100, Unit:100M. Command Alarming ：1, calling 2, texting Description Out Geo-fence 1 time, the Geo-fence canceled. Set Enclosure-2 OK / Cancel Enclosure OK Feedback 18)Position...
  • Page 19 19)Google Link Text Parameter Sample command command 666# 666# Command Check the location link of Google map Description Command <Datetime:12-07-05 13:21:30> Feedback http://maps.google.com/maps?q=N22.540885,E113.95265 20)Version Text Parameter Sample command VERSION V00# V00# Command The command is to check the software version Description Command VERSION:Xxxx...

  • Page 20: Status Check

    command PARAM 886# 886# Command The command is to check the settings and the default Description parameter. IMEI:351190012535936 APN : cmnet IP:IP and port Command TIMER: moving uploading interval Feedback STATIC: static uploading interval CENTER: center number LANG: language(CN/EN) GMT: time zone (E/W8) 22)Status Check Text Parameter...

  • Page 21: Troubleshooting

    GPS:FIXED/UNFIXED RELAYER:DISABLE/ENABLE Vibrate Warning:ON/OFF Pause:ON/OFF Monitor (Voice Surveillance)-CALL BACK(default) command Parameter Sample SSS# SSS# SSS# Using Command Send this command to the tracker’s number, the tracker will call back to Description admin number. Monitor (Voice Surveillance)-CALL command Parameter Sample Open Calling mode SS1# SS1# Return to Call back...
  • Page 22 cannot reach your location, please drive to the open sky.  If reminding the device SIM card is out of deposit, please make deposit by the telecom operator. ● If you can connect to the device when calling, the SIM card has deposited and please check with your operator for GPRS function.
