V. CUSTOMER RESPONSIBILITIES
• Read and observe the safety regulations contained in this Owner's Manual. This manual gives instructions
on the correct assembly and safe use of your machine. It is important that you read these instructions
carefully.
• Follow a regular schedule for maintaining, caring for and using your lawnmower.
• Follow the instructions in the Storage sections of this Owner's Manual.
• Remember that the operator is responsible for accidents with other persons or their property.
• When fully assembled the machine weighs approximately 382lbs. If necessary, obtain assistance to remove
from packaging.
• This riding mower is a HEAVY machine. The net weight is 173kgs/382Lbs.
DO NOT ATTEMPT TO MANUALLY LIFT IT WITH ONLY ONE OR TWO PEOPLE!
CAUTION: The above use and safety instructions must be strictly adhered to. The manufacturer
assumes no liability for any damage caused by improper operation, improper use, misuse,
unauthorised repairs or alterations performed.
Residual risks
Even when the unit is used as prescribed it is not possible to eliminate all residual risk factors.
The following hazard may arise in connection with the unit's construction and design:
a. Damage to hearing if effective hearing protection is not worn.
b. Damage to health resulting from vibration emssion if the unit is being used over longer periods of time or
not adequately managed and properly maintained.
PRODUCT NAME
COMMERCIAL NAME
TYPE
MODEL
Warranty
Battery Warranty
Drive Motor
Drive system
Battery Capacity- Volts & Amp hour Rating
Ground Speed (approx.)
DECK
Deck Material
Deck Construction
Number of Spindles
Blade Tip Speed
Spindle Material
Deck Drive
Deck Engagement
Deck Lift Svstem
Cutting width
10
SPECIFICATIONS:
Rechargeable Ride-on Lawnmower
iON BATTERY RIDER
BATTERY POWERED
81RC ERIDER
5 year domestic use, subject to annual service
2 year limited non commercial
Forward-Neutral--Reverse
Electric
72V/31 Ah battery
Forward Max. 3.7 mph / 6 kmh
Reverse Max. 3.1 mph / 5 kmh
Steel
Steel
2
2800 min-1
Steel motor shaft
Cutting motors: DC72V/800W Qty: 2
Electric-Blade mounted directly to motor shaft
Spring Assisted - Hand operated
32" (81 cm)
WG/WB81EC-B/FEB20/V1.1
