(VNFs) on a single device. The NFX350 is suited for large and extra-large deployments. The NFX350 is a high-end resilient uCPE platform that can be used in secure SD-WAN and secure router deployments.
Page 2
Register product serial numbers on the Juniper Networks website and update the installation base data if there is any addition or change to the installation base or if the installation base is moved. Juniper Networks will not be held accountable for not meeting the hardware replacement service-level agreement for products that do not have registered serial numbers or accurate installation base data.
Mounting an NFX350 Device on Four Posts in a Rack or Cabinet To mount an NFX350 device on a rack, you require the parts that are shipped with the device along with the following additional parts and equipment. These are not shipped with the device.
Page 4
Electrostatic discharge (ESD) grounding strap Four screws to secure the chassis and mounting bracket to the rack Phillips (+) screwdriver, number 2 Management host, such as a PC or laptop, with a serial port Two 10-32 x .25 inch screws with #10 split-lock washer Two #10 flat washers Grounding cable (minimum 14 AWG (2 mm²), minimum 90°C wire), grounding lug (Panduit LCC10-14BWL or equivalent), a pair of 10-32x.25-in.
Page 5
For information about installing the grounding cable, see the NFX350 Hardware Guide available at: https://www.juniper.net/documentation/en_US/release-independent/junos/information-products/pathway-pages/nfx-series/product/ You can mount the device a four-post rack by using the mounting brackets provided with the device. NOTE: The device weighs approximately 9.4 lb (4.3 kg). Two persons are required for mounting the device.
4. Slide the rear mounting-blades into the front-mounting brackets. 5. Attach the rear mounting-blades to the rear post by using the appropriate screws for your rack. Tighten the screws. 6. Ensure that the device chassis is level by verifying that all the screws on the front of the rack are aligned with the screws at the back of the rack.
(logical) untrust ISP assigned The NFX350 device is shipped with the following services enabled by default: DHCP, HTTPS, and TFTP. To provide secure traffic, a basic set of screens are configured on the untrust zone. Access the NFX350 Device 1.
Page 8
USB driver from the following page and install it on the management device: https://www.juniper.net/support/downloads/junos.html 3. Use any terminal emulation program, such as HyperTerminal, to connect to the device console. The CLI displays a login prompt.
The LTE expansion module must be purchased separately. Optionally, you can obtain a SIM card from the ISP and connect the device through LTE. For more information about SIM card activation, see the How to Configure NFX350 available at: https://www.juniper.net/documentation/en_US/release-independent/junos/information-products/pathway-pages/nfx-series/product/ 2.
For information on downloading the image, provisioning virtual network functions (VNFs), and performing initial configuration using the CLI, see the How to Configure NFX350 available at: https://www.juniper.net/documentation/en_US/release-independent/junos/information-products/pathway-pages/nfx-series/product/ Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the NFX350 documentation https://www.juniper.net/documentation/en_US/release-independent/junos/information-products/pathway-pages/nfx-series/product/.
Before connecting the device to a power source, read the installation instructions in the NFX350 documentation. The NFX350 device weighs approximately 13 lb (5.9 kg). Manually installing the device in a rack at a height above 60 in. (152.4 cm) requires two persons; one to lift the device and the second to install the mounting screws.
