  • Page 2 Version 1.0 Published May 2020 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 AUSTRALIA ONLY Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage caused by our goods. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (SO-DIMM) Jumpers Setup Onboard Headers and Connectors M.2 WiFi/BT Module Installation Guide M.2_SSD (NGFF) Module Installation Guide Chapter 3 Software and Utilities Operation Installing Drivers Chapter 4 UEFI SETUP UTILITY...
  • Page 5 OC Tweaker Screen Advanced Screen 4.6.1 CPU Configuration 4.6.2 Chipset Configuration 4.6.3 Storage Configuration 4.6.4 Super IO Configuration 4.6.5 ACPI Configuration 4.6.6 USB Configuration 4.6.7 Trusted Computing Tools Hardware Health Event Monitoring Screen Security Screen 4.10 Boot Screen 4.11 Exit Screen...

  • Page 6: Chapter 1 Introduction

    H410TM-ITX Chapter 1 Introduction Thank you for purchasing H410TM-ITX motherboard. In this documentation, Chapter 1 and 2 contains the introduction of the motherboard and step-by-step installation guides. Chapter 3 contains the operation guide of the software and utilities. Chapter 4 contains the configuration guide of the BIOS setup.

  • Page 7: Specifications

    • Dual Channel DDR4 Memory Technology Memory • 2 x DDR4 SO-DIMM Slots • Supports DDR4 2933/2800/2666/2400/2133 non-ECC, un- buffered memory * Please refer to Memory Support List on ASRock’s website for more information. (http://www.asrock.com/) • Core (i9/i7) support DDR4 up to 2933; Core (i5/i3), Pentium®...
  • Page 8 H410TM-ITX • Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1 • Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, Intel® SGX Content Protection, UHD/HDR Blu-ray Disc • Three graphics output options: 2 x HDMI, 1 x LVDS ports...
  • Page 9 Storage • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug • 1 x Ultra M.2 Socket, supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) * Supports NVMe SSD as boot disks Connector • 1 x Chassis Intrusion Header...
  • Page 10 H410TM-ITX Certifica- • FCC, CE tions • ErP/EuP ready (ErP/EuP ready power supply is required) Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    BLT_VOL1 SATA_1 SATA_2 USB2_1_2 USB2_3_4 CLR_MOS1 SATAPWR1 M.2 SSD RoHS M.2 WiFi SATAPWR2 DDR4_A2 DDR4_A1 CPU_FAN1 H410TM-ITX USB 3.2 Gen1 M2_1_CT2 T: USB3_3 B: USB3_4 RJ-45 M2_1_CT1 USB 3.2 Gen1 T: USB3_1 B: USB3_2 Intel Mic In H410 Headphone Audio...
  • Page 12 H410TM-ITX No. Description 4 pin 19V Power Connector (ATX_PWR1) SATA Power Connector (SATAPWR2) SATA3 Connector (SATA_1) SATA Power Connector (SATAPWR1) Clear CMOS Jumper (CLRCMOS1) SATA3 Connector (SATA_2) USB 2.0 Header (USB2_1_2) USB 2.0 Header (USB2_3_4) FPD Brightness Header (BLT_VOL1) Panel Voltage Selection Header (PNL_PWR1)

  • Page 13: I/O Panel

    1.4 I/O Panel No. Description No. Description DC Jack** LAN RJ-45 Port* HDMI Port (HDMI1) USB 3.2 Gen1 Port (USB3_12) COM Port Microphone (Pink) USB 3.2 Gen1 Port (USB3_34) Line out (Lime) *There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port...

  • Page 14: Chapter 2 Installation

    H410TM-ITX Chapter 2 Installation This is a Thin Mini-ITX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 15: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1200-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 16 H410TM-ITX...
  • Page 17 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 18: Installing The Cpu Fan And Heatsink

    H410TM-ITX 2.2 Installing the CPU Fan and Heatsink...

  • Page 19: Installing Memory Modules (So-Dimm)

    2.3 Installing Memory Modules (SO-DIMM) This motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot; otherwise, this motherboard and SO-DIMM may be damaged. The SO-DIMM only fits in one correct orientation.

  • Page 20: Jumpers Setup

    H410TM-ITX 2.4 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRCMOS1) (see p.6, No.
  • Page 21 Backlight Inverter Voltage 1-2 : +19V Selection Header 2-3 : +12V (3-pin BKT_PWR1) (see p.6, No. 11) Panel Voltage Selection 1-2 : +3V Header 2-3 : +5V (3-pin PNL_PWR1) (see p.6, No. 10) Warning: If selected Backlight Power or Panel Power is higher than panel's spec, it may damage the panel.

  • Page 22: Onboard Headers And Connectors

    H410TM-ITX 2.5 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Page 23 Internal Speaker Header Please connect the chassis speaker to this header. (4-pin SPK_OUT1) (see p.6, No. 18) Serial ATA3 Connectors These two SATA3 (SATA_1: connectors support SATA SATA_1 SATA_2 see p.6, No. 3) data cable for internal (SATA_2: storage devices with up to see p.6, No.
  • Page 24 H410TM-ITX 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly. Please follow the instructions in our manual and chassis manual to install your system. 2. If you use an AC’97 audio panel, please install it to the front panel audio header by the steps below: A.
  • Page 25 LVDS Panel Connector Signal Name Signal Name (30-pin LVDS1) LCD_VDD CLK1P (see p.6, No. 12) LCD_VDD LCD_VDD CLK2N CLK2P CLK1N Chassis Intrusion Header This motherboard (2-pin CI1) supports CASE OPEN (see p.6, No. 15) detection feature that Signal detects if the chassis cove has been removed.

  • Page 26: Wifi/Bt Module Installation Guide

    H410TM-ITX 2.6 M.2 WiFi/BT Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT module.
  • Page 27 Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.

  • Page 28: M.2_Ssd (Ngff) Module Installation Guide

    H410TM-ITX 2.7 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s).
  • Page 29 Step 4 Move the standoff based on the module type and length. The standoff is placed at the nut location A by default. Skip Step 4 and 5 and go straight to Step 6 if you are going to use the default nut. Otherwise, release the standoff by hand.
  • Page 30 H410TM-ITX M.2_SSD (NGFF) Module Support List M2_SATA: Vendor Capacity ADATA 512GB ADATA ASU800NS38-512GT-C Crucial 240GB Crucial-CT240M500SSD4-240GB Crucial 250GB Crucial-CT250MX500SSD4-250G ezlink 120GB ezlink P51B-80-120GB LITEON 256GB LITEON LJH-256V2G-256GB (2260) SanDisk 128GB SanDisk X400-SD8SN8U-128G SanDisk 128GB Sandisk Z400s-SD8SNAT-128G-1122 Transcend 64GB Transcend TS64GMTS400-64GB (2242)
  • Page 31 Vendor Capacity Samsung 128GB Samsung MZ-VLW1280-128GB (PM961) Samsung 512GB Samsung MZ-V7P512-512G (970PRO) Samsung 250GB Samsung MZ-V7E250-250G (970EVO) Samsung 250GB Samsung MZ-V6E250-250G (960 EVO) Team 240GB Team CARDEA-240G TOSHIBA 256GB TOSHIBA OCZ RD400-256G TOSHIBA 128GB TOSHIBA XG3-128G 512GB WD SDAPNUW-512G-1006 (SN520) (Gen3 x2) WD Black SN750-1TB (WDS100T3X0C-00SJG0) 512GB WD WDS512G1X0C-00ENX0-512GB...
  • Page 32 H410TM-ITX Vendor Capacity INTEL 128GB 545S SERIES-SSDSC2KW128G8X1-128G SANDISK 128GB SANDISK-X300-SD7SB6S-128G SANDISK 240GB SANDISK-EXTREME PRO-SDSSDXPS-240G PLEXTOR 256GB PLEXTOR-M6V-PX-256M6V-256G PLEXTOR 256GB PLEXTOR-M6 PRO-PX-256M6PRO-256G CRUCIAL 250GB CRUCIAL-MX500-CT250MX500SSD1-250G-5Y CRUCIAL 120GB CRUCIAL-BX500-CT120BX500SSD1-120G-3Y 120GB OCZ-VECTOR180-VTR180-25SAT3-120G-120G 120GB OCZ-TRION100-TRN100-25SAT3-120G 120GB WD-GREEN-WDS120G2G0A-00JH30-120G-3Y 250GB WD-BLUE-WDS250G2B0A-00SM50-250G-5Y UMAX 240GB UMAX-S330-HDUM330SSD240G-240G-3Y PIONEER 120GB...

  • Page 33: Chapter 3 Software And Utilities Operation

    Chapter 3 Software and Utilities Operation 3.1 Installing Drivers The Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. The CD automatically displays the Main Menu if “AUTORUN”...

  • Page 34: Chapter 4 Uefi Setup Utility

    H410TM-ITX Chapter 4 UEFI SETUP UTILITY 4.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 35: Ez Mode

    4.2 EZ Mode The EZ Mode screen appears when you enter the BIOS setup program by default. EZ mode is a dashboard which contains multiple readings of the system’s current status. You can check the most crucial information of your system, such as CPU speed, DRAM frequency, SATA information, fan speed, etc.

  • Page 36: Advanced Mode

    H410TM-ITX 4.3 Advanced Mode The Advanced Mode provides more options to configure the BIOS settings. Refer to the following sections for the detailed configurations. To access the EZ Mode, press <F6> or click the "EZ Mode" button at the upper right corner of the screen.

  • Page 37: Navigation Keys

    4.3.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 38: Main Screen

    H410TM-ITX 4.4 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The availability and location of BIOS settings can be different for different models and BIOS versions. My Favorite Display your collection of BIOS items. Press F5 to add/remove your favorite items.

  • Page 39: Oc Tweaker Screen

    4.5 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
  • Page 40 H410TM-ITX Boot Performance Mode Select the performance state that the BIOS will set before OS handoff. FCLK Frequency Configure the FCLK Frequency. Ring to Core Ratio Offset Disable Ring to Core Ratio Offset so the ring and core can run at the same fre- quency.
  • Page 41 Short Duration Power Limit Configure Package Power Limit 2 in watts. When the limit is exceeded, the CPU ratio will be lowered immediately. A lower limit can protect the CPU and save power, while a higher limit may improve performance. CPU Core Current Limit Configure the current limit of the CPU core.
  • Page 42 H410TM-ITX RAS# Active Time (tRAS) The number of clock cycles required between a bank active command and issuing the precharge command. Command Rate (CR) The delay between when a memory chip is selected and when the first active command can be issued.
  • Page 43 CAS Write Latency (tCWL) Configure CAS Write Latency. Third Timing tREFI Configure refresh cycles at an average periodic interval. tCKE Configure the period of time the DDR4 initiates a minimum of one refresh command internally once it enters Self-Refresh mode. Turn Around Timing tRDRD_sg Configure between module read to read delay.
  • Page 44 H410TM-ITX tWRRD_dg Configure between module write to read delay. tWRRD_dr Configure between module write to read delay. tWRRD_dd Configure between module write to read delay. tWRWR_sg Configure between module write to write delay. tWRWR_dg Configure between module write to write delay.
  • Page 45 Configure the memory on die termination resistors' PARK for channel A. ODT PARK (B1) Configure the memory on die termination resistors' PARK for channel B. Advanced Setting ASRock Timing Optimization Configure the fast path through the MRC. Realtime Memory Timing Configure the realtime memory timings.
  • Page 46 H410TM-ITX Command Tristate Configure the Command Tristate Support. Exit On Failure Configure the Exit On Failure for MRC training steps. Reset On Training Fail Reset system if the MRC training fails. MRC Fast Boot Enable Memory Fast Boot to skip DRAM memory training for booting faster.

  • Page 47: Advanced Screen

    4.6 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, Super IO Configura- tion, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. UEFI Configuration UEFI Setup Style Select the default mode when entering the UEFI setup utility.

  • Page 48: Cpu Configuration

    H410TM-ITX 4.6.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Active Processor Cores Select the number of cores to enable in each processor package.
  • Page 49 Package C State Support Enable CPU, PCIe, Memory, Graphics C State Support for power saving. CFG Lock This item allows you to disable or enable the CFG Lock. C6DRAM Enable/Disable moving of DRAM contents to PRM memory when CPU is in C6 state.

  • Page 50: Chipset Configuration

    H410TM-ITX 4.6.2 Chipset Configuration VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance. DMI Link Speed Configure DMI Slot Link Speed. Auto mode is optimizing for overclocking.
  • Page 51 PCH DMI ASPM Support This option enables/disables the ASPM support for all PCH DMI devices. Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. Onboard LAN Controller Enable or disable the onboard network interface controller. Onboard HD Audio Enable/disable onboard HD audio.

  • Page 52: Storage Configuration

    H410TM-ITX 4.6.3 Storage Configuration SATA Controller(s) Enable/disable the SATA controllers. SATA Aggressive Link Power Management SATA Aggressive Link Power Management allows SATA devices to enter a low power state during periods of inactivity to save power. It is only supported by AHCI mode.

  • Page 53: Super Io Configuration

    4.6.4 Super IO Configuration Serial Port Enable or disable the Serial port. Serial Port Address Select the address of the Serial port.

  • Page 54: Acpi Configuration

    H410TM-ITX 4.6.5 ACPI Configuration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. Onboard LAN Power On Allow the system to be waked up by onboard LAN. Ring-In Power On Allow the system to be waked up by onboard COM port modem Ring-In signals.

  • Page 55: Usb Configuration

    4.6.6 USB Configuration Legacy USB Support Enable or disable Legacy OS Support for USB 2.0 devices. If you encounter USB compatibility issues it is recommended to disable legacy USB support. Select UEFI Setup Only to support USB devices under the UEFI setup and Windows/Linux operating systems only.

  • Page 56: Trusted Computing

    H410TM-ITX 4.6.7 Trusted Computing NOTE: Options vary depending on the version of your connected TPM module. Security Device Support Use this item to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 57 TPM2.0 UEFI Spec Version Use this item to select the TCG2 spec. version supported. The optional settings: [TCG_1_2]; [TCG_2]. [TCG_1_2]: compatible mode for Win8/Win10. [TCG_2]: for TCG2 newer spec. compatible mode for Win10 Physical Presence Spec version Select this item to tell OS to support PPI spec version 1.2 or 1.3. Please note that some HCK tests might not support version 1.3.

  • Page 58: Tools

    Save UEFI files in your USB storage device and run Instant Flash to update your UEFI. Internet Flash - DHCP (Auto IP), Auto ASRock Internet Flash downloads and updates the latest UEFI firmware version from our servers for you. Please setup network configuration before using Internet Flash.
  • Page 59 Network Configuration Use this to configure internet connection settings for Internet Flash. Internet Setting Enable or disable sound effects in the setup utility. UEFI Download Server Select a server to download the UEFI firmware.

  • Page 60: Hardware Health Event Monitoring Screen

    H410TM-ITX 4.8 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. Fan Tuning Measure Fan Min Duty Cycle.
  • Page 61 CPU Fan 2 Setting Select a fan mode for CPU Fan 2, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature. CPU Fan 2 Step Up Set the value of CPU Fan 2 Step Up. CPU Fan 2 Step Down Set the value of CPU Fan 2 Step Down.

  • Page 62: Security Screen

    H410TM-ITX 4.9 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 63: Boot Screen

    4.10 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device. The VBIOS must support UEFI GOP if you are using an external graphics card.
  • Page 64 H410TM-ITX Full Screen Logo Enable to display the boot logo or disable to show normal POST messages. Boot Failure Guard Message If the computer fails to boot for a number of times the system automatically restores the default settings.

  • Page 65: Exit Screen

    4.11 Exit Screen Save Changes and Exit When you select this option the following message, “Save configuration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...
  • Page 66 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard H410TM-ITX Model Number : Conforms to the following speci cations:...
  • Page 67 EU Declaration of Conformity For the following equipment: Motherboard (Product Name) H410TM-ITX (Model Designation / Trade Name) EMC —Directive 2014/30/EU (from April 20th, 2016) EN 55022:2010/AC:2011 Class B EN 55024:2010/A1:2015 EN 55032:2012+AC:2013 Class B EN 61000-3-3:2013 EN 61000-3-2:2014 LVD —Directive 2014/35/EU (from April 20th, 2016)
