- Page 1 Artistic Licence daliGate quad User Guide daliGate quad User Guide Version 1-1...
- Page 2 Do not allow liquid to penetrate the product. Please recycle all packaging. Copyright © Artistic Licence Engineering Ltd. All rights reserved. Download the user guide by scanning the following QR code: daliGate quad User Guide...
-
Page 3: Mounting Diagram
Description Network indicator Power / Identify indicator Power input 9-48 VDC Data Connection DALI ports DALI indicators Configuration Squawk (single press) OR Factory reset (hold down and cycle power) Data/PoE RJ45 Connection Mounting Diagram daliGate quad User Guide Page 3... -
Page 4: Product Overview
Power to control DALI fixtures, alongside DMX, by daliGate quad can be powered from either an mapping Art-Net to DALI ARC commands external PSU (9-48 VDC) or with PoE (Power- and DALI back channel to RDM parameters. -
Page 5: Factory Reset
Fig 1: daliGate quad internal web browser The indicator meanings are as follows: Online: Green = live connection between browser & product; Red = connection lost Power: Green = powered; Flashing green = Identify; Red = Fault Net: Yellow = Link; Green = Art-Net or sACN activity... - Page 6 You can mute turns off all the LEDs. download the free software from our website. ‘RDM Devices’ offers options for device When daliGate quad is connected to a discovery and configuration. computer running DMX-Workshop, it should ‘Advanced’ leads to ‘Programme Upload’...
- Page 7 Expanding a sub-device shows all commands and back channel parameters that are valid (see Fig. 6). daliGate quad continuously polls all DALI short addresses using the Query Device Type command. The display shows which DALI devices have been found. In order to actively manage bandwidth, channel commands are not transmitted to non-existent devices.
-
Page 8: Operation
Use daliGate quad with an Art-Net Merging capable lighting desk to directly control daliGate quad is able to merge two streams of DALI gear alongside DMX fixtures. data to a DALI output. The method of merging All DALI back channel data (such as will be either HTP or LTP. -
Page 9: Led Indication
LED indication daliGate quad features various LED indicators, which give different informational signals depending on whether the product is booting up or in operational mode. The meanings are explained below. During boot-up Power LED - Slow flashing green (1Hz) = booting normally... -
Page 10: Application Diagram
Application Diagram In this example, 3 Artistic Licence products (daliGate quad, artLynx quad and Art-Switch POE4) are used in combination to allow any Art-Net enabled lighting desk to control DALI ballasts alongside DMX fixtures. The Art-Switch POE4 optionally enables the gatways to be powered via the ethernet cable using Power-Over-Ethernet. - Page 11 Output isolation: optical Overall Dimensions: 88mm (W) x 90mm ESD protection: 15 kV (H) x 62mm (D) Ordering Information Mass: 0.2 kg Product code: daliGate quad Country of manufacture: UK Package contents: daliGate quad Environmental Accessories Operating temperature: 0°C to 40°C PSU-9-1.5-FER...
-
Page 12: Warranty
Returns will not be accepted without prior (WEEE) authorisation. In order to discuss a request to return goods, please email: Artistic Licence is a member of a WEEE compliance scheme and will happily recycle Sales@ArtisticLicence.com any of our products that you, at your expense, return to us.
