TO REVERSE THE DOORS (OPTION)
Your fridge-freezer is designed with reversible doors,so that they may open from either the left of right
hand side to suit your kitchen design.
Precaution
1. Before reversing the door,first of all,you should take out food and accessories like shelves or trays
which are not fixed the fridge-freezer.
2. Use Torque Wrench or Spanner to fix or remove the bolt.
3. Do not lay the fridge-freezer down. This will cause problem.
4. Be careful not to drop the doors in disassembling or assembling.
5. To avoid the two doors dropping and result in physical injure,at least two persons are require to
change the door opening type.
How to Reverse the Doors
First please operate as the following steps (Figure A):
1. Disassemble the Hinge Middle (1);
2. Remove the Refrigerator Door (2) and the Freezer Door (3) (cooperate with another person);
3. Remove the Top Cover (4);
4. Remove the pin of Hinge Upper Right and assemble it on Hinge Upper Left (5);
5. Remove the Cap Hinge and install it on the corresponding on the right side(6),install the Top Cover(7);
6. Remove the pin of Hinge Lower Right and assemble it on Hinge Lower Left (8);
7. Remove the Cap on the left of the Hinge Middle and install it on the corresponding position(9) on
the right side ;
8. Remove the Cap of door and install it on the corresponding position (10) on the right side ;
9. Remove the right limit on the Refrigerator Door and the Freezer Door (11).Take out the spare left
limit from the bag with user manual included and install it on the corresponding position of the
Refrigerator Door and the Freezer Door;
10. Remove the bush (12) on the corresponding position of the Refrigerator Door and Freezer Door;
11. Install the Refrigerator Door (13) and the Freezer Door (14) (cooperate with another person), fix
the Hinge Middle on the left(15);
Then please operate as the following steps (Figure B):
12. Remove the caps on the handle of the Refrigerator Door and the Freezer Door , disassemble the
handle;
13. Remove the caps on the Refrigerator Door and the Freezer Door(5);
14. Fix the handles on the other side (7),install the caps on the corresponding locations(8,9);
15. For a Refrigerator with a vertical handle ,please replace the handle to the opposite position.
Note
Reversing the doors is not covered by the warranty.
14
