VRF
1
INSTALLATION
INSTRUCTIONS
VSCA Floor Standing Cased /
VSEA Floor Standing Exposed
VRF SYSTEMS -- Floor Standing Indoor Units
508061-01
03/2020
General
The VSC Floor Standing Cased / VSE Floor Standing Ex-
posed non-ducted indoor units are matched with an outdoor
heat recovery or heat pump unit to create a VRF (variable
refrigerant flow) system that uses HFC-410A refrigerant.
Refer to the Product Specification bulletin (EHB) for the
proper use of these indoor units with specific heat pumps,
heat recovery units, mode switching devices, branch pipes,
line sets and controls.
These instructions are intended as a general guide and do
not supersede local codes in any way. Consult authorities
having jurisdiction before installation.
Shipping and Packing List
Check the components for shipping damage. If you find
any damage, immediately contact the last carrier.
Package 1 of 1 contains the following:
1 - Assembled indoor unit
4 - Foot bolts
1 - Receiver/Display panel
2 - Refrigerant piping insulation sleeves
1 - Resistor
2 - Brass flare nut
1 - Controller Wiring harness
1 - Water level switch cable
1 - Installation manual
Optional accessories, purchased separately:
1 - Wired controller V0STAT55P-3 (19X69)
2 - Base (VSEA only)
2 - Support feet V8VSA001-3P (19X68)
