  • Page 2 5 pcs M8 x 120mm 4 pcs M8 x 50mm 2 pcs 2 pcs M12 x 90mm 6 pcs M8 x 30mm 8 pcs 1 pcs M10 x 50mm 8 pcs M6 x 10mm 1 pcs 8 pcs M12 x 20mm 2 pcs 4 pcs M8 x 40mm 4 pcs M8 x 30mm...
  • Page 3 1 pcs 1 pcs 2 pcs 2 pcs 1 pcs 2 pcs 2 pcs 4 pcs (4,2 x 9,5) 2 pcs 1 pcs...
  • Page 4 8pcs (M12x20mm) Mount them in to the holes as shown • 12pcs for M8 6pcs (M8x30mm) 6pcs M8 2pcs 2pcs...
  • Page 5 Mount 6 screws (M8x30mm), 6 nuts M8 and • 12 washers M8 in to the holes as shown...
  • Page 6 • Before you tighten screws, align vertical axis from the EAST- WEST side and the NORTH-SOUTH as shown in the figure...
  • Page 7 12pcs for M8 2pcs M8x14mm 6pcs M8 1pcs 1pcs 4pcs M8x50mm • Mount 6 screws, 6 nuts and 12 washers in to the holes as shown...
  • Page 8 5pcs M8 5pcs M8x120mm 10pcs for M8...
  • Page 9 5pcs M8x120mm 5pcs M8 10pcs for M8...
  • Page 10 4pcs M8 4pcs (D=40mm) 4pcs for M8 2pcs M8 Ø40.5 x 67mm 1pcs 1pcs M10x50mm...
  • Page 11 2nuts 2nuts 4pcs for M8...
  • Page 13 Make sure that the two arms are perfectly parallel •...
  • Page 14 1pcs D10x36mm 2pcs 3pcs Ø7mm 2pcs M12 2pcs M12x90mm 4pcs for M12 2pcs (2motors) 1pcs D10x36mm Ø7mm...
  • Page 15 M12x90mm...
  • Page 16 motor A...
  • Page 18 motor A motor B...
  • Page 20 At the end of a panel 8pcs & 8pcs M6x10mm...
  • Page 22 How to set the Motor Box! Followed pictures includes Solar Tracker panels instead of heliostats, dont be confused, setting the Motor Box is the same for Heliostats and Solar Tracker Panels!!! 2 screws are already inside the connector...
  • Page 24 Tight screws like it’s shown...
  • Page 25 Use cable ties as it‘s shown.
  • Page 26 Make a big radius.
  • Page 27 This two cables you already get connected. How to connect other two will be shown later!
  • Page 28 4 PCS: 4,2 x 9,5mm...
  • Page 29 Before you connect power system be aware of plus and minus in a right terminal. Connect one wire into the plus and the other one into the minus!
  • Page 30 It should look like on the picture! Wind sensor cable connect into the wind connector terminal.
  • Page 31 White wire connect into the wind connector terminal. Brown wire connect into the plus pole like it’s shown on the picture!
  • Page 33 FIRST CONNECTION OF TRACKER TO A PC OVER AN USB CONNECTION DRIVER INSTALLING • Before connecting USB cable, run VCPDriver_V1.1_Setup.exe, which is included in the archieve package. Click »Next« and than »Finish«. Note, that you have to be an administrator to install a driver.
  • Page 34 • Connect your PC to the tracker using the enclosed communication cable. Use the USB port on your computer. • Computer will require its driver installation. • When the next window appear, click on »No, not this time« and than »Install the software automatically«.
  • Page 36 • When Windows Logo testing, click on »Continue Anyway«. At the end click on »Finish«.
  • Page 37 • When Windows Logo testing, click on »Continue Anyway«. At the end click on »Finish«. • Remember the number of COM port. You will need to connect to the right COM port by Helios Analytics.
  • Page 38 HOW TO SET UP HELIOS ANALYTICS Run Helios Analytics.exe in Helios Analytics folder 1. Select proper COM port and press “Open” button. Note: you need to have USB (VCP) driver installed. Drivers are included in the archieve file.
  • Page 39 2. Now you can see “Communication Mode” and “Link number - which increases” 3. Disable Tracker control and press “OK” button. 4. Click “Setting Wizard” button and click “OK” button.
  • Page 40 5. Click “H/V aligment” button and click “OK” button. 6. Click “Configuration” button and click “SEND” button.
  • Page 41 Note: If nothing happens press “Clear” button. H/V aligment: Adjust motor “A&B” to total horizontal position. Motor A Motor B Motor A...
  • Page 42 7. Enable Automatic tracking and press “OK” button. In the Mode field you will see “tracking ok”. 8. Press “Close” button.

  • Page 43: Declaration Of Conformity

    Want to get more? DECLARATION OF CONFORMITY according to ISO/IEC Guide 22 and EN 45014 Company/Manufacturer’s Name: Sat Control d.o.o. Address: Poženik 10, SI-4207 Cerklje, Slovenia / EU declares under its sole responsibility, that the product Product name: Solar Tracker...
  • Page 44 Sat Control d.o.o., Poženik 10, 4207 Cerklje, SLOVENIA Phone: +386 4 281 62 00, Fax. +386 4 281 62 13, www.solar-motors.com, info@solar-motors.com...
