  • Page 1 ACTIVE SUBWOOFER XLb 250 XLb 300 XLb 250 XLb 300 Operating and Installation Instructions...
  • Page 2 Listen for any audible distortion. of the device. Blaupunkt is not liable for any loss If any audible distortion is detected, reduce or damaged caused or resulting from...
  • Page 3 This manual may be updated from time to time without any prior notice. DISCLAIMER In no event shall Blaupunkt be liable for any direct, indirect, punitive, incidental, special consequential damages to property or life and whatsoever arising out of or connected with the use or misuse of our products.
  • Page 4 FUNCTION CONTROL Remote (REM) : Connect Remote to the electrical aerial output / remote output of your radio with remote cable +12V : Connect +12V power supply to the car battery with power cable (power connection) Power (GND) : Ensure the chassis of the vehicle is connected to the Ground correctly (remove paint to reveal bare metal if needed) with ground cable FUSE : Protects device from voltage supply damage.
  • Page 5 SPECIFICATIONS XLb 250 A XLb 300 A Subwoofer Subwoofer • Speaker Size : 10” • Speaker Size : 12” • Cone Composition : • Cone Composition : Paper Cone, Rubber Surround Paper Cone, Rubber Surround Ampli er Ampli er • Ampli er Technology : Class A/B •...
  • Page 6 WIRING DIAGRAM CAR RADIO CONNECTION RCA CABLE (SIGNAL INPUT) REMOTE CABLE GROUND CABLE POWER CABLE BATTERY POWER SUPPLY CONNECTION +12V Fuse Ignition switch Connect to vehicle chasis Connect to accessory terminal On/O Remote BATTERY *Place the fuse in the power supply lead as close as possible to the car battery...
  • Page 7 Examine if your wiring diagram is correct by referring to Diagram 1 & Diagram 2 in case of device operation or performance failure. The following table indicate other possible problems and solutions. Refer an authorized Blaupunkt dealer if problem persist. Problem...
  • Page 8 XLb 250 A 1 113 17 002 09 01 Designed and engineered by Blaupunkt Competence Center XLb 300 A 1 113 17 003 09 01...
