Cotech HK-LB644A-HSV(UK) Instruction Manual

30 W LED Work Light with
2 x 230 V Power Take-Off Sockets
Art.no 18-1326 Model HK-LB644A-HSV(UK)
36-6501 HK-LB644A-HSV
Please read the entire instruction manual before using the product and then
save it for future reference. We reserve the right for any errors in text or images
and any necessary changes made to technical data. If you have any questions
concerning technical problems please contact our Customer Services.
Safety
• Make sure that the electrical socket that the product is plugged into is
easily accessible in case it and the connected product need to be quickly
disconnected from the mains electricity.
• Do not connect products of this type to each other.
• Do not cover the product.
• The LEDs in this work light have a very intensive light output. Do not let
children play with the work light. Do not look directly into the light or direct
the light into another person's eyes, doing so could cause eye damage.
• Do not touch the housing or glass of the work light when it is switched on
– risk of burn injury.
• Do not install the work light near flammable materials or surfaces.
• Do not cover the work light.
• Do not dismantle or modify the work light.
• The mains lead should be checked regularly. Never use the work light if
the mains lead or plug is damaged.
• Always unplug the work light from the power point when it is not in use.
Pull the plug, not the lead.
• The mains lead must be changed if damaged. This is to prevent the risk of
electric shock or fire and should only be carried out by the manufacturer,
authorised service facility or a qualified tradesman.
• The work light is suitable for use in temperatures between −20 and +40 °C.
• The work light should be connected to an earthed 230 V power point.
• Check before use that the housing, glass, power switch, mains lead and
plug are all undamaged. Any fault or damage must be repaired immediately
by a qualified electrician before the work light is used.
• Do not use the work light near combustible or explosive liquids, solids or gases.
• The work light must only be used when it is mounted on the included base
and bracket assembly. The work light must not be mounted on a wall or ceiling.
• Treat the work light with care and do not subject it to shocks or impacts.
• The work light must not be immersed in water or other liquid.
• If the mains lead is damaged in any way it must be replaced by
a qualified electrician.
The light source contained in this luminaire shall only
be replaced by a qualified electrician.
UNITED KINGDOM • CUSTOMER SERVICE tel 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
Care and maintenance
Unplug the work light and allow it to cool before cleaning.
Clean the light using a soft, damp cloth. Use a mild detergent.
Never use solvents or strong, abrasive cleaning agents.
Product description
3
6
5
4
2
1
1. Base
2. Bracket
3. Handle
4. Locking screws (star knob)
5. Lamp housing
6. Power switch
7. 2 × 230 V power socket, max 10 A
Assembly instructions
Attach the bracket and the handle (3)
to the base (1) using two locking screws (4).
Operating instructions
1. Connect the mains lead to a 230 V power point.
2. Adjust the lamp housing to the desired angle.
3. Switch the work light on using the power switch (6).
4. Switch off and unplug the work light after use.
7
Power take-off sockets
Power tools with a combined total power load of 2300 W can be connected to
the two power sockets on the rear of the work light. Note: The power switch (6)
only controls the work light, not the power take-off sockets.
Responsible disposal
This symbol indicates that this product should not be disposed
of with general household waste. This applies throughout
the entire EU. In order to prevent any harm to the environment
or health hazards caused by incorrect waste disposal,
the product must be handed in for recycling so that the material
can be disposed of in a responsible manner. When recycling
your product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Specifications
Voltage 230 V, 50/60 Hz
Power 30 W
Light source COB/Bridgelux LED
Luminous flux 3000 lm
Colour temperature 4000 K
Colour rendition > 80 Ra
Beam angle 120°
Ingress protection IP54
Power sockets Max 2300 W (10 A) total load
Protection class Class 1 (this light fitting must be earthed)
1.8 m rubber clad cable with earthed plug
Cable
(H07RN-F 3 × 1.0 mm²)
Size 220 × 185 × 210 mm
1 m
