Incra Ultra Lite Owner's Manual

OWNER'S MANUAL
Please read this Ownerʼs Manual before
use and keep it at hand for reference.
In the few years since its first appearance in
woodworking shops around the globe, Incra
Jig has quickly established itself as the finest
and most versatile woodworking system
available. At the top of its list of features has always
been its unparalleled positioning accuracy. As a fence
system, Incra Jigʼs amazing precision allows precise fence
placement to within a few thousandths of an inch, regardless of
your skill level. As a joint making machine, these same positioning
capabilities permit an endless variety of box joints and half blind, through
and sliding dovetails to be created. And with decorative joints like the exquisite
Incra Double Dovetail (described in the optional Incra Master Reference Guide
and Template Library ), Incra Jig makes the impossible quite possible.
Introducing the newest member of the Incra family: The Incra Jig Ultra Lite . With built-in micro
adjusting, velvet smooth tracking, and the Incra heritage of precision, your new Incra Jig Ultra Lite
combines some of the best features of its big brother, the Incra Jig Ultra, in a refined, more compact
unit perfect for the router table or drill press. The Ultra Lite carries on the tradition of performance and
accuracy youʼve come to expect from the Incra line of precision tools.
SAFETY
I Important safety instructions for using the Incra Jig Ultra Lite:
before using the Incra Jig Ultra Lite, read and follow all of the
instructions and safety information in this manual.
I When using Incra Jig Ultra Lite in conjunction with any other
tool, first read and follow all instructions and safety
information in that toolʼs ownerʼs manual.
I When Incra Jig Ultra Lite is mounted to a wooden base or
table surface, make sure that all six mounting screws are
securely tightened and the Incra Jig Ultra Lite is firmly held in
place.
I When using the Incra Jig Ultra Lite with a wooden base,
always make sure that the base is securely clamped,
screwed, or otherwise fastened to the work surface before
making a cut.
I Always turn off the power and make sure that the bit or blade
is fully stationary before moving the Incra Jig Ultra Lite to any
new setting.
CONTENTS
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Applications/General Purpose Fence . . . . . . . . . . . . 5
Zeroing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Applications/Joint Maker . . . . . . . . . . . . . . . . . . . . . 6
Setting the router bit depth of cut . . . . . . . . . . . . . . 6
Centering the bit and installing the template . . . . . . 7
®
I Always keep both hands behind the fence when moving the
I Before making a cut, always make sure that the carriage
I When using the Incra Jig Ultra Lite with other tools, make sure
I Use appropriate safety devices. Keep hands clear of the bit
I Wear safety glasses, hearing protection, and a dust mask,
I Do not alter or modify the Incra Jig Ultra Lite in an attempt to
Variations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Parts and Optional Accessories . . . . . . . . . . . . . . . .16
TM
Precision
Woodworking System
Incra Jig Ultra Lite to any new setting.
clamp is fully engaged and the jig is securely locked in place.
that all safety guards and other safety equipment supplied by
the manufacturer of that tool are securely in place and
functional. Never let the Incra Jig Ultra Lite interfere with
another toolʼs safety equipment.
or blade. Always use a push stick, rubber soled push block,
or other safety devices to keep your hands safely away from
the cutting tool.
and follow all normal shop safety practices.
use it with non-Incra accessories.
Box joints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Half blind dovetails . . . . . . . . . . . . . . . . . . . . . . . . .11
From the
makers of
Incra Jig!
