  • Page 1 Enduro 0307™ Installation & Startup Guide 67020Rev3...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS! SAVE THESE INSTRUCTIONS This manual contains important instructions for the Enduro BESS Home Energy Storage System. The components described by this manual are intended to be used as part of an Energy Storage system. CAUTION: Hazardous Voltages! This inverter contains hazardous voltage that may be lethal. It may only be installed by qualified personnel who have read this manual and are familiar with its operation and hazards.

  • Page 3: Table Of Contents

    Contents 1 SAFETY ............................................... 1 1.1 I ........................................1 N CASE OF EMERGENCY 1.2 B ..................................1 ATTERY MODULE SAFETY PRECAUTIONS 1.3 G ....................................... 1 ENERAL SAFETY PRECAUTIONS 1.4 E ......................................2 NVIRONMENTAL PROTECTION 1.5 T ....................................... 2 RANSPORT AND STORAGE 2 INTRODUCTION ............................................

  • Page 4: Safety

    1 Safety Throughout this manual, the following symbols will be used to highlight important information and procedures: Symbol Definition Symbol Definition WARNING! A dangerous voltage or other Login to the remote monitoring condition exists. Use extreme caution system for operating status when performing these tasks.

  • Page 5: Environmental Protection

    Risks of Fire Do not expose the system to temperatures exceeding 60 degrees Celsius. Avoid installation in direct sunlight. Do not store objects on top of the cabinet. Do not obstruct the intake or exhaust of the forced airflow system. Do not store combustible objects and corrosive chemicals directly adjacent to the system.

  • Page 6: Introduction

    2 INTRODUCTION 2.1 About this Manual – Target Audience This manual is intended to be used by qualified service and installation personnel for the purposes of product installation. This manual contains instructions for the installation and start up sequence of the Enduro BESS home energy storage system;...

  • Page 7: Initial Inspection Of Material List

    2.4 Initial Inspection of Material List The system components supplied with the energy storage system are shown below. Each component should be inspected visually for any damage that may have been caused by shipment. If damage is present, please contact your local distributor. 2.4.1 Energy Storage System (ESS) contents CAUTION! Handle and remove the ESS cover with care to prevent damage to the display and power outlet.

  • Page 8: Installation Instructions

    4 Installation Instructions 4.1 Unpacking the ESS. Carefully remove the entire ESS from its packaging. Raise the ESS into its upright position. Remove the cover (it is not secured to the base). Lift the ESS base from the top side and remove from the packaging.

  • Page 9: Battery Installation

    5 Battery Installation Note: The battery installation and connection instructions are applicable only if the battery is supplied separately from the ESS. Proceed to section 6 if the battery is pre-installed from the factory. 5.1 Mounting the battery module Remove the battery module mounting brackets from the ESS frame.

  • Page 10: System Electrical Wiring

    6 System Electrical Wiring Note: This product is capable of providing utility interactive and islanded back up power. Wiring methods must be in accordance with local electrical codes. IMPORTANT! Drilling holes in the ESS cabinet renders the warranty null and void. Use the cable entry ports provided. Note: The PCS provides galvanic separation between AC and DC cable entry port Sources.

  • Page 11: Operation

    11 Operation The ESS is fully automated, and will connect the system to the grid after AC and DC sources are applied. Refer to the EMS Commissioning Guide for system setup and operation status. The operating states can also be viewed on the display panel. 12 Display Panel Battery 12.1 LED Display Indicators...

  • Page 12: Maintenance

    14 Maintenance The ESS is a maintenance free product. Regularly scheduled inspection of the airflow path for the active cooling fans on the bottom side of the cabinet is all that is required. This inspection should occur on an annual basis, or coincide with PV inspection.

  • Page 13: Technical Data

    17 Technical Data PCS electrical data Grid voltage, L-N 240 Vac, single phase Grid frequency 50 Hz Maximum continuous operating current, A 12.5 Amps Maximum continuous operating power, VA 3000 VA Power factor, nominal (range) > 0.99 (0.8 lead to 0.8 lag) Maximum AC fault current and duration (short 248 Apk, 7.97 Arms for 0 to 50 ms circuit)

  • Page 14: Appendix A: Ess Configuration With Eastron Direct Connect Energy Meters

    Appendix A: ESS configuration with Eastron direct connect energy meters A.1 EMS kit contents Figure 13: EMS kit contents: direct connect home energy meter option. Description Din rail Din rail end stop RS485 adapter Energy meter – Direct Connect DIN rail ground terminal block. Power adapter (EMS) # 3424 EMS USB cable (0.3m) # 3414 Energy meter communication cable (2m)

  • Page 15: Optional Pv Meter Kit Contents

    A.2 Optional PV meter kit contents Note: The PV meter kit is only required if the EMS does not integrate directly with the PV manufacturer’s communication interface. Consult your dealer at the time of order regarding the latest list of compatible PV inverters with direct software integration to the EMS.

  • Page 16: Ess System Planning And Cable Routing Identification

    Reference Title Notes 801003424 EMS USB patch cable Eguana EMS to 485 adapter 801003414 kWh meter patch cable 10 meter, shielded Cat 5, RJ-45 to pigtail 801003516 Ethernet cable 10 meter, shielded Cat 5, RJ-45 to RJ-45...

  • Page 17: Ems Kit Installation Procedure

    A.4 EMS kit installation procedure #3424 The EMS kit must be installed inside the main electrical panel for metering of the home loads. The energy meter supplied as part of the EMS kit must be installed and configured according to the electrical service; supporting both single phase or three phase installations.

  • Page 18: Pv Meter Kit Installation With Direct Connect Energy Meter

    A.6 PV meter kit installation with direct connect energy meter. Note: Refer to the electrical single line diagram in section A.3 for a complete signal wiring diagram of the EMS, ESS, #3424 and energy meter connections. The instructions below assume the EMS kit is already installed and wired.

  • Page 19: Eastron Sdm630 Direct Connect 3-Phase Meter To Main Electrical Service

    A.7 Eastron SDM630 Direct Connect 3-phase meter to Main Electrical Service Figure 20: Eastron direct connect meter wiring diagram - main electrical service. A.8 Eastron SDM630 Direct Connect 1-phase / 3-phase meter to PV Inverter Figure 21: Eastron SDM630 direct connect meter wiring diagram - PV inverter.

  • Page 20: Appendix B: Ess Configuration With Accu-Rev Ct Type Energy Meters

    Appendix B: ESS configuration with ACCU-REV CT type energy meters B.1 EMS kit contents Figure 22: EMS & home meter kit contents. Description Din rail Din rail end stop RS485 adapter Energy meter DIN rail ground terminal block. CTs (3-ph mains metering – use only 1 CT for single phase installs) # 3414 Energy meter communication cable (2m) # 3424 USB Adapter to EMS USB cables (0.3m) # 3516 EMS to ESS communication cable (10m)

  • Page 21: Optional Pv Meter Kit Contents

    B.2 Optional PV meter kit contents Note: The PV meter kit is only required if the EMS does not integrate directly with the PV manufacturer’s communication interface. Consult your dealer at the time of order regarding the latest list of compatible PV inverters with direct software integration to the EMS.

  • Page 22: Ess System Planning And Cable Routing Identification

    Reference Title Notes 801003424 EMS USB patch cable Eguana EMS to 485 adapter 801003414 kWh meter patch cable 10 meter, shielded Cat 5, RJ-45 to pigtail 801003516 Ethernet cable 10 meter, shielded Cat 5, RJ-45 to RJ-45 DRED* Figure 24: Single line diagram of ESS with CT type energy meters and EMS.

  • Page 23: Ems Kit Installation Procedure

    B.4 EMS kit installation procedure The EMS kit must be installed inside the main electrical panel for metering of the home loads. The energy meter supplied as part of the EMS kit must be installed and configured according to the electrical service; supporting both single phase or three phase installations.

  • Page 24: Ems Ethernet Connection

    B.5 EMS Ethernet connection A permanent ethernet connection is required for an internet communication from the EMS. The Ethernet wiring from the EMS must be connected to a customer supplied router (see EMS ethernet port - figure 27). A 10 meter CAT-5 patch cable (#3516) is included with this system. B.6 PV Kit Installation Procedure Note: Refer to the electrical single line diagram in Appendix A for a complete signal wiring diagram of the...

  • Page 25: Accu-Energy Acurev 1310 3 Phase Meter - Main Electrical Service

    B.7 Accu-Energy Acurev 1310 3 phase meter – Main Electrical Service CAUTION! Handle CTs with care. Always terminate the CTs at the meter inputs prior to clamping the core onto a hot wire. Note: Observe the CT direction and wiring polarity for proper operation of the system. Figure 29: Acurev 1310 main electrical service meter wiring diagram.

  • Page 26: Appendix C: Ess Configuration With Eastron Ct Type Energy Meters

    Appendix C: ESS configuration with Eastron CT type energy meters C.1 EMS kit contents Figure 31: EMS kit contents: CT typehome energy meter option. Description Din rail Din rail end stop RS485 adapter Energy meter – CT type DIN rail ground terminal block. Power adapter (EMS) # 3424 EMS USB cable (0.3m) # 3414 Energy meter communication cable (2m)

  • Page 27: Optional Pv Meter Kit Contents

    C.2 Optional PV meter kit contents Note: The PV meter kit is only required if the EMS does not integrate directly with the PV manufacturer’s communication interface. Consult your dealer at the time of order regarding the latest list of compatible PV inverters with direct software integration to the EMS.

  • Page 28: Ess System Planning And Cable Routing Identification

    Reference Title Notes 801003424 EMS USB patch cable Eguana EMS to 485 adapter 801003414 kWh meter patch cable 10 meter, shielded Cat 5, RJ-45 to pigtail 801003516 Ethernet cable 10 meter, shielded Cat 5, RJ-45 to RJ-45 Figure 33: System block diagram cable references.

  • Page 29: Ems Kit Installation Procedure

    C.4 EMS kit installation procedure The EMS kit must be installed inside the main electrical panel for #3424 metering of the home loads. The energy meter supplied as part of the EMS kit must be installed and configured according to the electrical service;...

  • Page 30: Pv Meter Kit Installation With Act Type Energy Meter

    C.6 PV meter kit installation with a CT type energy meter. Note: Refer to the electrical single line diagram in section C.3 for a complete signal wiring diagram of the EMS, ESS, and energy meter connections. #3424 The instructions below assume the EMS kit is already installed and wired.

  • Page 31: Eastron Sdm630Mv-Ct 3-Phase Meter To Main Electrical Service

    C.7 Eastron SDM630MV-CT 3-phase meter to Main Electrical Service Figure 38: Eastron CT type meter wiring diagram - main electrical service. C.8 Eastron SDM630MV-CT 1-phase / 3-phase meter to PV Inverter Figure 39: Eastron CT type meter wiring diagram - PV inverter.
  • Page 32 This page intentionally left blank...
