Servend MD-150 Replacement Manual

Duratran/Medallion Replacement
FIGURE 1
Knurl Screws
1
FIGURE 2
If you have any questions concerning this bulletin, please contact Manitowoc Beverage Equipment's Technical Service Department at (800) 367-4233
MD-150, MD-200, and MD-250

Tools Required

6 in 1 screw driver
1. Disconnect power to the dispenser.
2. Remove full lid or manual fill lid from unit.
3. Remove the 2 Knurl screws from top of merchandiser.
(See Figure 1)
4. Remove the merchandiser from the unit. (See Figure 2)
5. Remove the seven screws from around the outer top and
bottom edges of the merchandiser. (See Figures 3&4)
(The screws are threaded into rubber bumpers inside the
merchandiser. This will free the medallion for removal)
(See Figure 5)
6. Remove the existing medallion from the merchandiser.
(See Figure 6)
FIGURE 3
3 Bumber Screws on top of merchandiser
