National Instruments AMUX-64T Installation Manual

NATIONAL
INSTRUMENTS
The Software is the Instrument
DAQ Board Accessories Rack-Mount Kit
This guide describes how to assemble the rack-mount hardware for the AMUX-64T analog
multiplexer board and the SC-205X, SC-206X, SC-207X, and BNC -208X Series signal
conditioning boards in a standard 19-in. rack-mount cabinet.

Introduction

There are four versions of the rack-mount kit—single- and double-height kits with an acrylic
plastic cover, and single- and double-height kits with a metal wraparound cover. The metal
wraparound cover kits are ideal for high-voltage applications. However, we do not recommend
the metal wraparound cover kits for use with the BNC-208X Series boards.

What You Need to Get Started

You will need the following parts from your DAQ board accessories rack-mount kit, depending
on the version you have:
Plexiglas cover kit
Item
2
4
Metal wraparound cover kit
Item
2
4
_____________________________
Product and company names are trademarks or trade names of their respective companies.
320815A-01 © Copyright 1994 National Instruments Corporation. All rights reserved.
®
®
Component
Cover, rack-mount, Plexiglas
Washer, flat, #4, nylon
Component
Cover, rack-mount, metal wraparound
Washer, flat, #4, SS
Installation Guide
Quantity
1
4
Quantity
1
4
October 1994
