- Page 1 OWNERS MANUAL Part: A8002, A8003, A8004, A8005, A8006 A8102, A8103, A8104, A8105, A8106 GlowStep Revolution Version 13 BY: RS 6/23/16 TECH SUPPORT (800) 246-8132...
- Page 4 Parts Inventory (Hardware in Bolt Kit) Item Image Item Description Quantity 3/8”-16 x 1” Grade 5 Hex Bolt 3/8” SS SAE Flat Washers 3/8” Lock Washers 3/8”-16 Grade 5 Hex Nuts 5/16”- 18 x 1.25” Grade 5 Hex Bolts 5/16”-18 Grade 5 Hex Nut 5/16”...
- Page 5 Parts Inventory (Hardware Preassembled) Item Image Item Description Quantity GlowStep Revolution Frame (assembled) GlowStep Assembly (assembled) 3/8”-16 x 1-3/4” Button Head Socket Cap Screw (Pre-Assembled) 3/8” SS SAE Flat Washers (Pre-Assembled) 3/8”-16 Grade 8 Nylock Hex Nut (Pre-Assembled) 3/8” x 3/4” x 3/8” Nylon Spacer...
- Page 6 Step 2 Determine the proper mounting height of the GlowStep Revolution Frame. The top of the GlowStep Revolution Frame should sit as close to the optimal mounting height as possible to allow for the most adjustability when installed. Refer to table 2.1 for the optimal mounting height as measured from the ground to the top of the GlowStep Revolution Frame when the trailer is leveled on flat ground.
- Page 7 Due to the variances in step opening and door heights, it may be necessary to deviate from the optimal mounting height. The top of the GlowStep Revolution frame should sit no lower than five inches from the threshold of the door.
- Page 8 Remove the GlowStep Revolution from the packaging. Lift one of the step release levers and pull the GlowStep assembly out from the GlowStep Revolution Frame. Remove the hardware attaching the GlowStep assembly to the pivot arms as shown in figure 3.1B, using the included Hex L-Key.
- Page 9 The GlowStep Revolution Frame can be mounted with either 3/8" hardware through the inner holes as seen in figure 4.1, or mounted with 5/16" hardware through the outer holes as seen in figure 4.2. Side brackets vary by manufacturer, and may need to be trimmed to clear the hardware protruding through the sides of the GlowStep Revolution Frame.
- Page 10 5/16” USS Flat Washers 5/16”-18 Grade 5 Hex Nuts 5/16” Lock 5/16” USS Figure 4.2 Washers Flat Washers Step 5 - Reattach GlowSteps If the GlowSteps were removed for installation, the GlowStep assembly can be reattached to the pivot arms at this time. See figure 3.1B.
- Page 11 2" by moving the GlowStep Revolution frame into the High or Low position. This is accomplished by lifting one of step release levers, and then moving the steps in or out of the GlowStep Revolution frame until the locking mechanism locks into the next position. See figure 6.1.
- Page 12 Further adjustments can be made at the All Terrain Landing Gear located at the bottom of the steps. From the middle position, the All Terrain Landing Gear can be adjusted up or down as much as 1-1/2" by changing the location of the push buttons on the side of the vertical tubes.
- Page 13 In order to prevent damage, the STEPS MUST BE FULLY COLLAPSED before being stored. Four, Five, and Six step units have a shelf at the back of the GlowStep Revolution frame, which will keep the steps from expanding when stored.
- Page 14 Handle Latch Nylon Stud Figure 6.2 1/4" x 1-3/8” Bail Pin Figure 6.3 Page9...
- Page 15 All-Terrain Landing Gear feet on the ground. If the steps need to be adjusted, begin by adjusting the upper step at the GlowStep Revolution Frame into either the High or Low position, then adjust the All Terrain Landing Gear. Once the step is in the proper position, use the 1/4"...
- Page 16 Step 7: GlowStep Revolution Hinge Tension Adjustment Your GlowStep Revolution Steps come from the factory preset to a specific torque setting. This can be adjusted to suit your personal preference for ease of use if needed. The Hinge Tension Adjustment bolts are circled in Figure 7.1.
- Page 17 9/16 wrench and one 7/32 Allen wrench. The bolt is located at the back of the GlowStep Revolution cage directly in front of the tensions spring as seen in the photos below. Adjust the...
- Page 18 With the Earth to RV design of the GlowStep Revolution there is no need to install the step against the frame of the RV but rather pull it out towards the RV’s side wall so it is flush with the outer face of the side of the RV.
- Page 19 Note- Pushing the GlowStep Revolution frame all the way back may cause the Safety pin to catch or drag along the RV’s side wall potentially damaging the painted surface of the RV over time. Page14...
- Page 20 Step 10 (optional): GlowGuide Bracket Installation When installing a Torklift GlowGuide, the GlowGuide Bracket and GlowGuide Adapter will need to be installed as shown in figure 6.1. The GlowGuide Brackets can be installed on either All Terrain Landing Gear, depending on the side the GlowGuide is installed on.
- Page 21 Step 11 (optional Accessories): GlowGuide handrail: Part no. A720 GlowGuide locks: Part no. A7509 SafeStep pet safety barrier: Part no. A7602 Dirt Destroyer shoe cleaner: Part no. A7603 Page16...
- Page 22 Warranty Information 322 Railroad Ave N, Kent, WA 98032 Torklift will require proof of purchase to register, with pictures of any defective product before issuing a replacement. Torklift will not register any product without proof of purchase, which can be faxed, scanned, emailed, or mailed to the information provided below.
- Page 23 To Fax: Send copies of the questionnaire, warranty card and receipt to 253-854-8003 To E-mail: Send copies of the questionnaire, warranty card and receipt to warranty@torklift.com To Mail: Send to Torklift International 322 Railroad Ave N, Kent, WA 98032 Page18...
- Page 24 OFFICIAL WARRANTY REGISTRATION CARD PLEASE FILL OUT THIS FORM COMPLETELY AND RETURN TO TORKLIFT WITHIN 30 DAYS OF PURCHASE ACCOMPANIED BY A COPY OF YOUR ORIGINAL RECEIPT Page19...
