Page 2: Introduction
Congratulations, you are the owner of a Slootsmid arable land slurry injector. This machine is produced for the modern farmer and contractor. We are convinced that you have made the right choice to buy a Slootsmid arable land slurry injector. When the machine will be used in a normal way, and maintenance is done at the right way you can use this machine for many years. -
Page 3: Table Of Contents
Index Introduction ................................................. 2 Index ..................................................2 Guarantee ................................................4 EU declaration of conformity for machinery ......................................5 Safety instructions ............................................... 6 Safety stickers ..............................................7 Assembly description ............................................8 Hitch en dose set ..............................................9 Hydraulic scheme ............................................... 11 Scheme attachments ............................................ -
Page 4: Guarantee
The guarantee includes failures which find their assignable cause in material and production failures. The guarantee limits to delivery of new spare parts under guarantee. This only on judgement of Slootsmid. The demand for guarantee declines six (6) months after delivery date. Also inexpert, wrong or insufficient maintenance or wrong repairs and changes decline the demand for guarantee. -
Page 5: Eu Declaration Of Conformity For Machinery
(Guide 2006/42/EG) appendix II B Manufacturer Slootsmid Mesttechniek B.V. Adres Korenbree 40-A, 7271 LH Borculo The Netherlands Herewith declares that, The Slootsmid arable land slurry injector type SB Serial number ____________________________ Year of manufacture ____________________________ Delivery date ____________________________ Meet the requirements of the machinery guide (Guide 2006/42/EG, last changed); appendix VII part B Accomplished in Borculo at, ___________________________* M.A.C.B. -
Page 6: Safety Instructions
8. Pay attention to your fingers when working on the cutting-rotor. 9. Damaged hydraulic lines need to be replaced immediately. 10. It is not allowed to adjust the relief valve outlet, ask your supplier or Slootsmid. 11. Do not stand on the machine while working with the machine. -
Page 7: Safety Stickers
Safety stickers The attached stickers to the machine or tanker inform a safe use and important instructions. Reed these instructions and work according the instructions. Damaged stickers need to be replaced immediately. Pay attention! Reed the manual and safety instructions before you start working with the machine. STOP. -
Page 8: Assembly Description
Assembly description Assembling the machine behind a tanker: 1. Restriction is that the tanker has a uninterrupted chassis. 2. Assemble the lifting consoles with the supports according the drawing at page 11 tot the tanker. 3. Assemble the lifting arms, top link and the lifting cylinders according the drawing at page 12. -
Page 9: Hitch En Dose Set
Hitch en dose set Information about the hitch and the dose set Grease hitch pins before use. For the SB 3M machine, two (2) hydraulic connections (tube diameter: 15 millimeter for steering) are necessary on the backside of the tanker. For the SB 4.5M, SB 5.5M and SB 6.5M machines, two (2)hydraulic connections (tube diameter 15 millimeter for steering) and two (2) hydraulic connections (tube diameter 12 millimeter for folding) are necessary on the backside of the tanker. - Page 10 Picture of the dose set Picture of the pressure reducer...
-
Page 11: Hydraulic Scheme
Hydraulic scheme Picture of the hydraulic scheme. -
Page 12: Scheme Attachments
Scheme attachments Scheme of the attachments to the tankers. -
Page 13: Scheme Hitch And Scheme Stabilization Chains
Scheme hitch and scheme stabilization chains. Hitch:... - Page 14 Stabilisation chains: Lowest Lowest connecting point connecting point tanker slurry injector...
-
Page 15: Tuning The Machine
Tuning the machine Always make sure that the machine is in horizontal position when it is in working position. -
Page 16: Working With The Machine
Working with the machine Make sure nobody is in the area around the machine when you start working with the machine Fold out the machine (from type SB 4.50) Start driving and lower the machine and keep the hydraulic flow in neutral position. When lifting the machine, put the valve handle in neutral position when the machine is lifted. -
Page 17: Maintenance
Maintenance When frequently using the machine Clean the cutting-rotor every day Check the hoses for clogging Clean the quick couplings every day Grease the pins from the folding part, the cylinders and hitch every day. Clean the machine every week, and grease all grease points Grease the cutting-rotor mechanism every week Before driving on public road always check the lighting When the machine is stored... -
Page 18: Hydraulic Sequence Valve (Optional)
Hydraulic sequence valve (optional) Functions of the hydraulic sequence valve Ball valve (lowering) Ball valve (for single working set) Sequence valve Pressure attachment for bottom pressure Relief valve outlet Manometer... -
Page 19: Failure
Find the broken coupling and replace it. Machine is lowering during transport Problem Leakage of the anti-loweringvalve through dirt Answer Clean the valve, for replacing the valve contact your supplier or Slootsmid Problem Leakage of the cylinders Answer Repair the cylinders... - Page 20 Anti- loweringvalve Machine distributes irregular or not: Problem Rotor is stuck Answer Clean rotor (pay attention to your fingers) Problem The hoses are stuck Answer clean the hoses Problem Rotor is running slow Answer Disasemble the rotor, clean the rotor, rotorhousing and engineshaft. Reassemble the rotor.
- Page 21 Inside rotordistributor Rotorsecurity...
-
Page 22: Technical Data
Technical data Type Eco and Profi SB 3.00 SB 4.50 SB 5.50 SB 6.50 Amount of tines Distance of the tines (cm) Working width (m) 2.75 4.25 5.25 6.25 Transport width (m) 2.90 2.75 2.75 2.75 Support wheels Hydraulic foldable Weight approx. -
Page 23: Contact
Contact Slootsmid Mesttechniek B.V. Korenbree 40a NL-7271 LH Borculo (Holland) Telephone: +31 (0)545-745 090 E-mail: info@slootsmid.com Internet: www.slootsmid.com...
