IES 50
Intelligent Entry Scanner
Installation and Start Up Guide
Tidel | 2025 W. Belt Line Rd. #114 | Carrollton, TX 75006 | Tel: 972.484.3358 800.678.7577
© 2020 Tidel | sales@tidel.com | www.tidel.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IES 50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tidel IES 50

  • Page 1 IES 50 Intelligent Entry Scanner Installation and Start Up Guide Tidel | 2025 W. Belt Line Rd. #114 | Carrollton, TX 75006 | Tel: 972.484.3358 800.678.7577 © 2020 Tidel | sales@tidel.com | www.tidel.com...
  • Page 2: Table Of Contents

    IES 50 Device Activation ..........................Setting the Date and Time ..........................Access Control Integration ..........................Alarm Integration ..............................Tidel | 2025 W. Belt Line Rd. #114 | Carrollton, TX 75006 | Tel: 972.484.3358 800.678.7577 © 2020 Tidel | sales@tidel.com | www.tidel.com...
  • Page 3: Ies 50

    X (4) Pan Screws X (4) Wall Mount Anchors X (4) Wall Spacers X 2.5 mm Allen Wrench X RJ-45 Cable X Software Thumbdrive X Power Adapter X Terminal Connector X IES 50 Terminal Network Connector Power Adapter RJ-45 Connector +12vdc and Ground...
  • Page 4: Ies 50 Stand Installation

    X (4) Pan Washer Screws X Tie Wraps X Terminal Stand 1. Place the IES 50 face down in the foam packing material. 2. Connect the Power Adapter and Network cables. 3. Secure the Stand to the back of the Terminal mounting plate with the (4) Pan Washer screws 4.
  • Page 5: Wall Mount Installation

    Terminal. The Tidel IES 50 is highly sensitive - Mounting in a high traffic area may cause unwanted scanning occurrences 2. Place the wall plate in the desired location and mark the mounting holes.
  • Page 6 Screen Resolution = 1920 x 1080 Screen Orientation = Landscape Scaling = 100% NOTE: If the Tidel IES 50 application screen does not appear fitted properly within the Host PC screen (after running the Tidel IES 50 installer) the Display Properties may need to be altered.
  • Page 7: Host Pc Preparation

    Subnet Mask = 255 . 255 . 255 . 0 h. Save and exit the Host PC Settings 2. Insert the Tidel IES 50 Installer thumbdrive into the Host PC. Run the “IES 50” installer - Select YES to begin the installation process 4.
  • Page 8: Ies 50 Device Activation

    X ONLY ONE DEVICE CAN BE ACTIVATED AT A TIME Complete a single device activation before connecting another device for activation 1. Connect the network cable from the IES 50 to an available port on the PC or network line switch. 2. Plug in the IES 50 Power Adapter.
  • Page 9 9. Select “OK” at the bottom of the Terminal Search Screen a. Confirm “Add FasTer Successful” 10. Select the checkbox for the terminal being activated a. Double left-click the IES 50 IP Address to access the Settings Screen SEE NEXT PAGE...
  • Page 10 15. Confirm setting successful 16. Select the checkbox for the terminal being activated 17. Select REMOVE 18. Repeat steps 4 - 9 19. Confirm the IES 50 Terminal is listed with the correct, assigned IP Address in the left column of the Screen.
  • Page 11: Setting The Date And Time

    Setting The Date And Time  Select the Terminal  Select the SETTINGS tab 1. Select Sync 2. Enter the desired Password. 3. Select Confirm. Select CONFIRM NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 12: Access Control Integration

    Access Control Integration A terminal connector is provided in the IES-50 packaging for access control wiring A terminal connection is available for activating alarm systems, door locks, access/entry points, DVR’s, etc... Normally Open (NO) - Normally Closed (NC) Circuits The Normally Open and Normally Closed circuits are continuity sensing circuits DO NOT APPLY VOLTAGE TO THESE TERMINALS The Normally Open and Normally Closed circuits are activated...
  • Page 13: Alarm Integration

    Alarm Integration A terminal connector is provided in the IES-50 packaging for alarm integration wiring Terminal connections support Wiegand 26 or 24 (Wiegand 37 not supported currently). DO NOT APPLY VOLTAGE TO THESE TERMINALS GND + IN3 = Exit button - the NO/NC circuits will be activated GND + IN2 = Door Sensors GND + IN1 = Self Power Siren/Alarm RS485-A = Fingerprint Reader/Biometric A cable...
  • Page 14 2025 W. Belt Line Rd, #114 Carrollton TX 75006 1-800-372-7933 (phone) 972-484-1014 (fax) techserv@tidel.com...
