- Page 1 Smart Weatherproof Camera WL-ZAVWDMW-C221121-01 Product Manual Version 1.0 © 2019 Logika Limited...
- Page 2 Introduction Thank you for choosing Logika. Please take a moment to carefully read through the manual to ensure safe and proper installation and use. • Before use, the product must be properly installed as described in this manual by a qualified technician.
- Page 3 Device Layout Wiring Diagram...
-
Page 4: Specifications
Features • Communication Mode: IEEE 802.15.4 Zigbee / Wi-Fi. 1080p HD video recording. • • Pan and tilt support - 150° horizontal (via mobile app) / 85° vertical (manual adjustment). Supports motion detection. • Supports night vision. • • 2-way voice communication. Records to internal SD card and NVR. -
Page 5: Installation Steps
Installation Steps Before Hardware Installation Prior to the hardware installation, it is best to power up the camera on the bench and connect it to the Zigbee network. Doing it this way will make things easier and the settings will be remembered when the device is powered up again after the install. -
Page 6: Hardware Installation
3) If you have a Micro SD card, you can insert this at the same time. 4) Once the device has connected to the network, you can screw the back cover back on and disconnect the camera from the supply. The settings will be retained once it’s powered up again. - Page 7 Adding the Device to the Smart Home Network Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the Logika Smart Mobile App user guide which will take you through the process of adding smart devices to the system.
- Page 8 Waterproof Treatment Network Cable The camera’s network port has a waterproof design. To create a waterproof tight seal for the cable that connects to the network port, follow the procedure outlined here. 1) Cut off the network cable’s RJ45 plug and pass the cable through the waterproof cap and body.
-
Page 9: Safety Precautions
Safety Precautions • The wall that the camera is mounted on must be able to withstand more than 5 times the weight of the camera. • The camera is waterproof and conforms to the IP66 specification, but the interface to the external cable is not waterproof.
