INTRODUCTION Thank you for purchasing our absorption minibar. This unit is designed to improve your living and entertaining comfort. The absorption system minibar is a compact, totally silent refrigerator that uses no compressors or fans. Originally developed for use in hotel rooms, this kind of little refrigerator is available to use in many other locations, such as cruise line, caravan, department dormitory, office, etc.
INSTALLATION It is advisable to clean the inside of the absorption refrigerator with lukewarm water using a mild detergent, and then to dry it thoroughly prior to use. The temperature in the appliance will depend on: The temperature in the room The frequency and duration of periods when the door is open.
Page 4
PROFUCT PARTS AND FEATURES Lamp (Option) Balcony feet shelf HOW TO OPERATE ABSORPTION MINIBAR 1. Insert the power plug into wall outlet. 2. To adjust the temperature turn thermostat knob inside the cabinet. Automatic Defrosting Some models are with automatic defrosting system. For most models which are with manual defrosting system, you just turn the thermostat knob to zero position until the accumulated frost melts.
REVERSING THE DOOR How to reverse the door Remove the lower hinge by loosening and removing the screws with scredriver. Carefully lower the door and remove it. Remove the two screws from the left top hinge position, take the metal part off the hinge position.
LIMITED WARRANTY As a condition to any warranty service obligation, the consumer must present this Warranty Certificate along with a copy of the original purchase invoice. THIS WARRANTY DOES NOT COVER: 1) Damage, accidental or otherwise, to the absorption refrigerator while in the possession of a consumer not caused by a defect in material or workmanship.
Page 7
DESCRIPTION Le Minibar est une petite armoire d’absorption pour hôtels, collectivités, bateaux et camping. Le Minibar est pour 220-240V/50Hz. Le Minibar consiste des piéces détachés suivantes: Lampe (Option) Balcon pieds clayette 1. Exterieur 6. Charnière inferieur 2. Absorption, Aggregat 7. Charnière superieur 3.
Page 8
DÉBALLAGE Contrôler lors du déballage du minibar que rien ne manque et que tout est en bon état. En cas de dommages constatés, en avertir immédiatement le transporteur. INSTALLATION Pour obtenir un maxium de réfrigération moyennant un minimum de consommation, il convient d'éviter de placer le minibar à...
DÉGIVRAGE - automatique CHANGEMENT DES CHARNIERES La porte peut être montée avec ouverture aussi bien à droite qu'à gauche. Pour cela il faut dévisser les trourillons de charnières et les reviser du côte opposé. EN CAS DE PANNE 1.Contrôler que le minibar est parfaitement de niveau. 2.Contrôler que l'air circule comme il faut autour du groupe frigorifique.
Page 10
CIRCUIT DIAGRAM - DIAGRAMME ÉLECTRIQUE For unit with automatic defrosting – Armoire avec dégivrage automatique ① XP ②DF ③SA ④HT ① ③SAT Temperature Control XP Power Supply ②DF Defrosting ④HT Heating Tube For unit with manual defrosting – Armoire avec dégivrage manuel ①...
