OLBA TS-5000 Instruction Manual

INSTRUCTION MANUAL FOR DIGITAL
THERMOSTAT
M : TS-5000
ODEL
Nr. Code Description
1 LK1
2 SC
3 C-F
4 Lk2
5 P
6 I
7 d
8 At
The sensor is NTC 5K
T
EMPERATURE SETTING
Press the ▲ or ▼ key enter the temperature setting, press the ▲ key to increase and press the ▼ key to
decrease the temperature. Press the SET key to save the value and get out of the temperature setting. If not
touched the key within 8 seconds the temperature setting is saved automatically and also returns to measure.
O
THER SETTINGS
When press the SET key the display shows LK1. This is the lock1 function. Enter number 116 and press SET
again. Now you can change the SC and C-F function. Press SET again to leave the programming.
Press the SET key for a longer time until the display shows LK2. This is the lock2 function. Enter number 181
and press SET again. Now you can change "P" , "I" , "D" , "AT". Press SET again to leave programming.
P, I, D AT:
AND
These functions can be used for more experienced users. Auto Tune is the automatic setting system to set the
P, I and D values for the best results for your situation. The green led on the display will blink when the AT is
working. After setting the best values it will install itself the new found P,I and D values.
H
OW TO CONNECT
Connect this thermostat as on the drawing below. It is important that this product is connected by somebody
with knowledge about electricity. In case you don't have please ask a certified person!
Electronic lock (Lock 1)
Calibration
Change the ℃ and ℉
Electronic lock (Lock 2)
Proportion area
Calculus time
Differential time
Auto Tune function
(self setting)
?
Setting Information
Setting code to change setting for
0～200
SC and C-F (code 116)
-9.9～＋9.9
0～1
Setting code to change setting for
0～200
P, I , D and AT (code 181)
Manual setting for P
0～999
Manual setting for I
0～999
Manual setting for D
0～999
ON= Auto Tune Function for PID
0～1
OFF= Manual Function for PID
1
TS-5000_v01_UK with CE
English
Preset
0
0.0
℃
0
80
80
20
OFF
