π
H-6672
LASER BARCODE
SCANNER
1. Attach cord to scanner unit. (See Figure 1)
2. Connect other end to host system. (See Figure 2)
3. Scan the appropriate barcode from original
Quick Start Guide included in the box.
Figure 1
π
PAGE 1 OF 3
CHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
INSTRUCTIONS
Cable
interface port
Interface
cable
modular
connector
clip
Interface cable
modular connector
To host
Pour le français, consulter la page 3.
NOTE: Quick Start Guide has many barcode
options. Choose the option that is best for your
intended application.
Figure 2
USB port
Para Español, vea página 2.
0718 IH-6672
