Comtrol WR7802-XT Series User Manual

Industrial managed poe cellular router, 2 - gigabit poe plus ports, 2 - gigabit sfp ports
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WR7802-XT Series
Industrial Managed PoE Cellular Router
2 - Gigabit PoE Plus Ports
2 - Gigabit SFP Ports
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WR7802-XT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comtrol WR7802-XT Series

Summary of Contents for Comtrol WR7802-XT Series

  • Page 1 WR7802-XT Series Industrial Managed PoE Cellular Router 2 - Gigabit PoE Plus Ports 2 - Gigabit SFP Ports User Guide...
  • Page 2 Copyright © 2017-2018. Comtrol Corporation. All Rights Reserved. Comtrol Corporation makes no representations or warranties with regard to the contents of this document or to the suitability of the Comtrol product for any particular purpose. Specifications are subject to change without notice.

  • Page 3: Table Of Contents

    Using Configuration Files ......................... 28 Saving a Configuration File ........................28 Loading a Configuration File ........................28 Using the LED Tracker..........................29 Customizing PortVision DX ........................30 Table of Contents RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A - 1...
  • Page 4 Traffic Prioritization | DSCP-Queue Mapping Page................72 Multicast Filtering Pages .......................... 73 Multicast Filtering | IGMP Snooping Page .................... 74 Multicast Filtering | IGMP Query Page ....................75 2 - RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Table of Contents...
  • Page 5 How to Set the Device Name........................123 Set the Cellular Settings ........................124 Set the PoE Settings..........................124 Set the Switch Settings .......................... 125 Using DELETE Commands........................126 Table of Contents RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A - 3...
  • Page 6 Table of Contents 4 - RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Table of Contents...

  • Page 7: Introduction

    Introduction The RocketLinx WR7802-XT Series is an industrial grade Cellular LTE router with two PoE and two SFP fiber Ethernet ports. The WR7802-XT contains a Long Term Evolution (LTE) module with two SIM slots, which supports for up to 100M DL and 50M DL. In addition, the two Gigabit 802.3at PoE ports support up to 30W to PoE devices.

  • Page 8: R&Tte Directive 1999/5/Ec

    Determined by your SIM card settings. SIM Security None Detailed specifications for the RocketLinx WR7802-XT Series are available on the Comtrol site. R&TTE Directive 1999/5/EC The product may be operated in all European Union countries. The R&TTE (1999/5/EC) Directive requires that the apparatus bears the CE mark as conformation of compliance with the R&TTE Directive.

  • Page 9: Fcc Radiation Exposure Statement

    • Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A FCC Radiation Exposure Statement - 7...

  • Page 10: Environment And Housing

    Install over voltage protector devices on every outdoor Ethernet cable. • Protect each antenna installed outside with lightening protection devices, for example, a lightening arrester. Note that Field EMD (Lightning) DAMAGE IS NOT COVERED UNDER WARRANTY. 8 - Environment and Housing RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 11: Hardware Installation

    • WR7802-XT-X, which supports US bands Note: Both models are simply referred to as the WR7802-XT unless there is information for a specific model. You can use the following subsections to install the RocketLinx WR7802-XT Series. • Safety Precautions •...

  • Page 12: Environment And Housing Notifications

    When the system is operational with a high gain antenna, avoid standing directly in front of it. Strong RF fields are present when the transmitter is on. 10 - Environment and Housing Notifications RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 13: Insert The Sim Card

    The antennas shipped with the product are a wide- temperature design; however, they are not water- proof. If you want to install it in outdoor area, use water-proof outdoor antennas. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Insert the SIM Card - 11...

  • Page 14: Mounting An Sma-Type External Antenna

    Keep the following in mind when selecting an external antenna: • Gain: Affects the system performance. • Direction: Typical types include: Omni-Directional or Directional antenna. Check the antenna zone in its specification. 12 - Mounting an SMA-Type External Antenna RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 15: Antenna Alignment

    1. Connect the DC power inputs by inserting the positive and negative wires (12-16AWG) into the PWR+ and PWR- contacts using the following wiring drawing. Note: Tighten the wire-clamp screws to prevent the wires from coming loose. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Antenna Alignment - 13...

  • Page 16: Connect The Digital Output (Dry Relay Output)

    3. Tighten the ground screw after the ground wire is connected. Note: The WR7802-XT MUST be properly grounded. Connect the Ethernet cable, Antenna, extended antenna cable and Ground before powering on the system. 14 - Connect the Digital Output (Dry Relay Output) RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 17: Connect The Ethernet Ports

    • 1000BASE-TX: Category 5 or higher cable Note: Comtrol recommends using CAT 5E/CAT 6 cables in harsh environments. STP (Shielded Twisted Pair) cable is preferred. If the WR7802-XT is installed in a harsh environment, part of the EMS protection is based on STP cable.

  • Page 18: Connect Sfp Transceivers (Ports 3-4)

    3. Verify that the DIN rail clip is tightly attached on the track. 4. To remove the WR7802-XT from the track, reverse the steps above. 16 - Connect SFP Transceivers (Ports 3-4) RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 19: Led Descriptions

    This loads the factory default configuration values into the Depress > 7 Seconds WR7802-XT including the IP address. The Reset button is located on the front panel of the WR7802-XT below the second SFP port. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A LED Descriptions - 17...
  • Page 20 Hardware Installation 18 - Reset Button RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 21: Using Portvision Dx

    • IO-Link Master family In addition to identifying Comtrol Ethernet attached products, you can use PortVision DX to display any third-party switch and hardware that may be connected directly to those devices. All non-Comtrol products and unmanaged RocketLinx switches are treated as non-intelligent devices and have limited feature support.

  • Page 22: Portvision Dx Requirements

    Windows 10 operating systems (at the time of publication). PortVision DX requires that you connect the Comtrol Ethernet attached product to the same network segment as the Windows host system if you want to be able to scan and locate it automatically during the configuration process.

  • Page 23: Configuring The Network Settings

    Note: Depending on your operating system, you may need to click Yes to the Do you want to allow the following program to make changes to this computer? query. 2. Click the Scan button in the Toolbar. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Configuring the Network Settings - 21...
  • Page 24 3. Select the Comtrol Ethernet attached products that you want to locate and then click Scan. Note: If the Comtrol Ethernet attached product is not on the local segment and it has been programmed with an IP address, it will be necessary to manually add the Comtrol Ethernet attached product to PortVision DX.

  • Page 25: Checking The Firmware Version

    Checking the Firmware Version Checking your web interface version is easy in PortVision DX. Comtrol recommends loading the latest firmware so that you have all of the latest feature enhancements and bug fixes. 1. If the WR7802-XT is not displayed in PortVision DX, click the Scan button.
  • Page 26 Simply, click your product type and click the Software link and check the latest version against the version on the WR7802-XT. Use the next subsection for procedures to upload the firmware (web interface). 24 - Checking the Firmware Version RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 27: Uploading The Latest Firmware

    Refresh. Optionally, you can click the Refresh button in the Toolbar and that refreshes all devices in PortVision DX. 7. Verify that the version change is reflected in under the Software Version. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Uploading the Latest Firmware - 25...

  • Page 28: Uploading Firmware To Multiple Wr7802-Xt Switches

    1. If the WR7802-XT is not displayed in PortVision DX, click the Scan button. 2. Select the Comtrol Ethernet attached product type and click the Scan button. 3. Shift-click the multiple WR7802-XT switches on the Main screen that you want to update and right-click and then click Advanced | Upload Firmware.

  • Page 29: Adding A New Device In Portvision Dx

    4. Enter a friendly device name in the Device Name list box. 5. Optionally, enter the serial number in the Serial Number list box. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Adding a New Device in PortVision DX - 27...

  • Page 30: Using Configuration Files

    2. Click Yes to the warning that it will take 25 seconds per device and it may also reboot the devices. 3. Browse to the location of the configuration file, click the file name (.dc) and then Open. 4. Close the Load Configuration popup message. 28 - Using Configuration Files RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 31: Using The Led Tracker

    The WR7802-XT SYS LED will flash for five seconds. 2. If necessary, you may need to click Tracker and ON several times to catch the flashing SYS LED. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Using the LED Tracker - 29...

  • Page 32: Customizing Portvision Dx

    Accessing RocketLinx Documentation from PortVision DX You can use this procedure in PortVision DX to download open the previously downloaded documents the RocketLinx. 30 - Customizing PortVision DX RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 33: How To Download Documentation

    Note: It may take a few minutes to download, depending on your connection speed. The document opens automatically after it has downloaded. 7. Click Close if you have downloaded all of the documents that you wanted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A How to Download Documentation - 31...

  • Page 34: How To Open Previously Downloaded Documents

    Note: Optionally, you can browse to the Program Files (x86) | Comtrol | PortVision DX | Docs subdirectory and open the document. 1. If necessary, open PortVision DX | Start/Programs | Comtrol | PortVision DX | PortVision DX or use the desktop shortcut.

  • Page 35: Configuration Using The Web User Interface

    IP address for your network using PortVision DX (Configuring the Network Settings on Page 21), you need to change your computer IP address to 192.168.250.x (Network Mask: 255.255.255.0). RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System Requirements - 33...
  • Page 36 Right-click the WR7802-XT in PortVision DX and click Webpage. • Open your browser, enter the IP address of the switch, and then press Enter. For example: http:// 10.0.0.140. 34 - Web User Interface RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 37 Page 39. 4. If you have not done so, you can change the WR7802-XT IP address to meet your network environment. using the System | IP Settings page. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Web User Interface - 35...

  • Page 38: Secure Web User Interface

    2. Launch the web browser and type https://192.168.250.250 (or the IP address of the WR7802-XT).and then press Enter. 3. Expand the More Information link and then click the Go on to the webpage (not recommended) option. 36 - Secure Web User Interface RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 39 Configuration Using the Web User Interface 4. Enter the user name and the password and click OK. The default name and password are both admin. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Secure Web User Interface - 37...
  • Page 40 5. If you have not done so, you can change the WR7802-XT IP address to meet your network environment. using the System | IP Settings page. 38 - Secure Web User Interface RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 41: Diagnosing A Login Failure

    System | NAT Settings | Port Forwarding Page on Page 57 System | NAT Settings | DMZ Page on Page 58 System | NAT Settings | Advanced Page on Page 59 RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Diagnosing a Login Failure - 39...
  • Page 42 VPN | VPN Certificate Page on Page 98 VPN | IPsec Settings Page on Page 98 • Security - Port Security Page on Page 101 40 - Introduction to the Web Interface RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 43: Status Web

    Status | Network Flow Page on Page 44 • Status | ARP Table Page on Page 45 • Status | DHCP Client List Page on Page 45 RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Status Web Pages - 41...

  • Page 44: Status | Information Page

    Configuration Using the Web User Interface Status | Information Page The Information page provides current status and some basic settings for the WR7802-XT. 42 - Status | Information Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 45 0 dBm (Default value while no connection, or during a Read the Signal Signal Strength Strength error.) • -113 dBm or less (Low) • -51 dBm or greater (Excellent) • Not known or not detectable RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Status | Information Page - 43...

  • Page 46: Status | Network Flow Page

    Click this button to set a new interval time after entering a new polling Set Interval interval time. Stop Click this button to stop polling the associated clients. Refresh Click to refresh the table. 44 - Status | Network Flow Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 47: Status | Arp Table Page

    The number can be changed on the System | IP Settings page with the DHCP Server Lease Time setting. Refresh Click this button to refresh the table. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Status | ARP Table Page - 45...

  • Page 48: System Web

    The System | Basic Settings page allows you to give a name to identify an access point name. It allows maximum 15 characters and no spaces. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 46 - System Web Pages RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 49: System | Ip Settings Page

    Use the IP Settings page to configure the IP related parameters for LAN interfaces, which connects to the LAN port of your router (Access Point). RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | IP Settings Page - 47...
  • Page 50 The Neighbor connection state of the neighbor entry. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 48 - System | IP Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 51: System | Dhcp Server Page

    The DNS server address that you want the DHCP server to distribute. This is the amount of time of the assigned IP addresses. The range is 15 - Lease Time 44640 minutes. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | DHCP Server Page - 49...

  • Page 52: System | Time Settings Page

    You can enter the IP address of server that you want to set the time on Manual IP the WR7802-XT. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 50 - System | Time Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 53: System | Relay Settings Page

    Since not all carrier providers provide a fixed IP service and the dynamic IP address of Cellular interface may change often, making it difficult to remotely manage the WR7802-XT’ IP address. Optionally, you can use DDNS domain name instead fixed IP address. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | Relay Settings Page - 51...
  • Page 54 You must confirm the DDNS client password before applying the Confirm Password settings. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 52 - System | DDNS Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 55: System | Traffic Shaping Page

    55): Source port filtering from the LAN to Internet through the gateway. Src Port Filtering (Page • 55): Destination ports filtering from the LAN to Internet through the gateway. Dest Port Filtering (Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | Traffic Shaping Page - 53...

  • Page 56: System | Outbound Firewall | Src (Source) Ip Filtering Page

    Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 54 - System | Outbound Firewall | Src (Source) IP Filtering Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 57: System | Outbound Firewall | Src (Source) Port Filtering Page

    Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | Outbound Firewall | Src (Source) Port Filtering Page - 55...

  • Page 58: System | Inbound Filtering Page

    The destination port range of the above IP address. Destination port range Dest Port Range: can NOT be empty! You should set a value between 1~65535. Comment: Note for the entry. 56 - System | Inbound Filtering Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 59: System | Nat Settings Submenu

    TCP/UDP port numbers. Configure the IP address of the LAN PC. The traffic from the public port IP Address range is redirected to this IP address. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | NAT Settings Submenu - 57...

  • Page 60: System | Nat Settings | Dmz Page

    IT administrator. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 58 - System | NAT Settings | DMZ Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 61: System | Nat Settings | Advanced Page

    If Forced mode is selected, power is provided even if no Ethernet cable is plugged in. Only use Forced mode if you are attaching a device that is capable of receiving power through its Ethernet connection. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A System | NAT Settings | Advanced Page - 59...
  • Page 62 The warning level is for system warning to alert the user when the PoE Warning Level(%) system is drawing power that meets the warning level. 60 - Power over Ethernet | PoE Control Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 63 After the cycle time, the PoE router starts the PD again. This function also referred to as link partner line detection (LPLD). Delete Click Delete and Apply can delete the settings. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Power over Ethernet | PoE Control Page - 61...

  • Page 64: Power Over Ethernet | Poe Schedule Page

    Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 62 - Power over Ethernet | PoE Schedule Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 65: Power Over Ethernet | Poe Status Page

    Powering Status, PD class, Power Budget (W), Power Consumption (W), Voltage and Current of the connected device. The following screen illustrates that there is a PoE IP camera on Port 1. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Power over Ethernet | PoE Status Page - 63...

  • Page 66: Switch Configuration

    Wavelength The wave length of the SFP transceiver connected to the port. Distance The distance of the SFP transceiver connected to the port. 64 - Switch Configuration Pages RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 67: Switch Configuration | Port Control Page

    Click the Apply button to activate the settings. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Switch Configuration | Port Control Page - 65...

  • Page 68: Switch Configuration | Vlan Configuration Page

    VLAN Configuration group enables you to Add/Remove static VLAN, configure Management VLAN ID, Port PVID, Egress parameters and view VLAN table. 66 - Switch Configuration | VLAN Configuration Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 69 Delete all: Delete the all entries. Refresh: Reload the table. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Switch Configuration | VLAN Configuration Page - 67...

  • Page 70: System Configuration | Rate Control Page

    Click the Apply button to apply the configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 68 - System Configuration | Rate Control Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 71: Switch Configuration | Port Statistics Page

    Check your network cable, Network Interface Card of the connected device, the network application, or reallocate the network traffic. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Switch Configuration | Port Statistics Page - 69...

  • Page 72: Traffic Prioritization

    1 with the lowest priority at the same time. Strict priority Packets with higher priority in the queue are always processed first, as scheme long as there is no packet with a higher priority. 70 - Traffic Prioritization Pages RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 73: Traffic Prioritization | Cos-Queue Mapping Page

    CoS values 6 and 7 are mapped to physical Queue 3, the high physical queue. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Traffic Prioritization | CoS-Queue Mapping Page - 71...

  • Page 74: Traffic Prioritization | Dscp-Queue Mapping Page

    Upper Layer 3 switch or routers’ DSCP setting. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 72 - Traffic Prioritization | DSCP-Queue Mapping Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 75: Multicast Filtering

    Following web page are included in this group: • Multicast Filtering | IGMP Snooping Page on Page 74 • Multicast Filtering | IGMP Query Page on Page 75 RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Multicast Filtering Pages - 73...

  • Page 76: Multicast Filtering | Igmp Snooping Page

    Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 74 - Multicast Filtering | IGMP Snooping Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 77: Multicast Filtering | Igmp Query Page

    Apply button to apply your configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Multicast Filtering | IGMP Query Page - 75...

  • Page 78: Network Redundancy

    3 Advertise Intervals, the default is Detection Interval Configurable ping loss, the default is 5 1 second Ring Recovery Failover time 5ms and 0 restoration Time time 76 - Network Redundancy Pages RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 79: Network Redundancy | Stp Configuration Page

    Once two or more devices on the network are recognized as a root bridge, the devices renegotiates to set up a new spanning tree topology. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Network Redundancy | STP Configuration Page - 77...
  • Page 80 2 × (Forward Delay Time – 1 sec) ? Max Age Time ? 2 × (Hello Time value + 1 sec) Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 78 - Network Redundancy | STP Configuration Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 81: Network Redundancy | Stp Port Configuration Page

    LAN. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Network Redundancy | STP Port Configuration Page - 79...

  • Page 82: Network Redundancy | Stp Information Page

    BPDU sent from the root switch. Port Information: You can see Port Role, Port State, Path Cost and Port Priority of the STP ports. 80 - Network Redundancy | STP Information Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 83: Network Redundancy | Redundant Ring Configuration Page

    To enable/disable the Ring. Remember to enable the ring after you add it. Select Click the Select check box if you want to Edit or delete the selected row. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Network Redundancy | Redundant Ring Configuration Page - 81...

  • Page 84: Network Redundancy | Redundant Ring Information Page

    RM or from RM to nonRM. Ring State This number means how many times the Ring status has been Transition count transformed between Normal and Abnormal state. 82 - Network Redundancy | Redundant Ring Information Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 85: Network Redundancy | Redundant Gateway Page

    (the same as original main gateway) so for other devices, the main gateway still exists and these devices can transmit data to external network via Cellular interface of the Redundant Gateway device. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Network Redundancy | Redundant Gateway Page - 83...
  • Page 86 Master and replaces the original gateway. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 84 - Network Redundancy | Redundant Gateway Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 87: Network Redundancy | Vrrp Page

    The time unit is seconds and the default setting is 1 second. In a VRRP domain, the VRRP devices should have the same Adv. Interval as well. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Network Redundancy | VRRP Page - 85...
  • Page 88 The VRRP Backup acts as the Master before restarts the device. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 86 - Network Redundancy | VRRP Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 89: Cellular

    ISP’s Cellular data network, you may need to enter the APN settings, User Name, Password, Authentication type on the device. You can use this page to configure the parameters. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Cellular Pages - 87...
  • Page 90 30 seconds. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 88 - Cellular | Cellular Basic Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 91: Cellular | Sim Security Settings Page

    Press Apply to activate the new settings. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Cellular | SIM Security Settings Page - 89...

  • Page 92: Cellular | Mobile Manager Settings Page

    TCP port number. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 90 - Cellular | Mobile Manager Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 93: Vpn

    Use the VPN | OpenVPN Client web page to configure the OpenVPN client (VPN | OpenVPN Client Settings Page on Page 93). Note: The settings should be consistent with OpenVPN server. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A VPN Pages - 91...

  • Page 94: Vpn | Vpn Status Page

    The transmission data volume in bytes Bytes displays after the VPN client connects. Note: Click the Refresh button to update the information on the page. 92 - VPN | VPN Status Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 95: Vpn | Openvpn Client Settings Page

    Server IP (1) Enter the IP address of the remote VPN server. Server IP (2) Optionally, enter the second IP address of the remote VPN server. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A VPN | OpenVPN Client Settings Page - 93...
  • Page 96 Save an OpenVPN Client log file. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 94 - VPN | OpenVPN Client Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 97: Vpn | Openvpn Server Settings Page

    Note: Generate the key with the VPN Server or 3rd party key generation tool. 5. Enable VPN and Apply to activate. 6. Check the status. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A VPN | OpenVPN Server Settings Page - 95...
  • Page 98 Press Apply to activate settings. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 96 - VPN | OpenVPN Server Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 99: Vpn | Vpn Port Forwarding Page

    Click Select and then click Delete Selected to delete selected entries. • Click Delete All to delete all entries. • Press Refresh to update the table. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A VPN | VPN Port Forwarding Page - 97...

  • Page 100: Vpn | Vpn Certificate Page

    You can configure various parameters for these two ends using this page. The following image shows a simple example of an IPsec connection. 98 - VPN | VPN Certificate Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 101 The content of the current public key is displayed. Enable IPsec Use this check box to enable or disable the IPSec function. Configure the Connection appropriate fields below. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A VPN | IPsec Settings Page - 99...
  • Page 102 Click the Apply button to apply the configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 100 - VPN | IPsec Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 103: Security - Port Security Page

    The Port Security feature allows you to stop the MAC address learning for a specific port. After stopping MAC learning, only the MAC address listed in the Port Security List can access the switch and transmit/receive traffic. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Security - Port Security Page - 101...

  • Page 104: Management

    Page 108 • Management | Firmware Upgrade Page on Page 110 • Management | Configuration File Page on Page 111 • Management | LLDP Configuration Page on Page 112 102 - Management Pages RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 105: Management | Opcua Settings Page

    Click the Apply button to apply the configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Management | OPCUA Settings Page - 103...

  • Page 106: Management | Remote Settings Page

    Force HTTPS, E-mail Alert and PortVision DX. Event Warning Type Authentication Fail The failure of authentication event. Config Changed The configuration of this device has changed. 104 - Management | Remote Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 107 Specify the password sent with each trap to the manager. By default, it is set Trap Community to public and allows all requests. Apply Click the Apply button to apply the configuration changes. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Management | Remote Settings Page - 105...
  • Page 108 Click the Apply button to apply Apply the configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 106 - Management | Remote Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 109: Management | Smtp Settings Page

    Click the Apply button to apply the configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Management | SMTP Settings Page - 107...

  • Page 110: Management | Login Settings Page

    The username to login to this device. Password The password to login to this device. Authentication Mode Local The local account to login to this device. 108 - Management | Login Settings Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 111 Click the Apply button to apply the configuration changes. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Management | Login Settings Page - 109...

  • Page 112: Management | Firmware Upgrade Page

    After the firmware has upgraded, the router reboots automatically. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 110 - Management | Firmware Upgrade Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 113: Management | Configuration File Page

    Click the Submit button to load or save the configuration. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Management | Configuration File Page - 111...

  • Page 114: Management | Lldp Configuration Page

    Click the Refresh button to update the information in the table. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 112 - Management | LLDP Configuration Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 115: Tools Pages

    Click the Save button to download log information to your PC. Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Tools Pages - 113...

  • Page 116: Tools | Ping Watchdog Page

    Note: You must Save (Page 115) settings, if you want to maintain these settings if the WR7802-XT is rebooted. 114 - Tools | Ping Watchdog Page RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 117: Tools | Ping Page

    Use this page to logout. Press Yes to logout. Reboot Page Use this page to reboot the WR7802-XT. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Tools | Ping Page - 115...

  • Page 118: Configuration Using The Command Line Interface (Cli)

    (CLI) Overview The RocketLinx WR7802-XT Series provides a Command Line Interface (CLI) that you can access through a Telnet or SSH connection. The SSH connection can secure all the configuration commands you send to the WR7802-XT. SSH is a client/server architecture while the WR7802-XT is the SSH server. When you want to make SSH connection with the WR7802-XT, you can use PortVision DX or download an SSH client tool.

  • Page 119: Accessing The Cli Through Portvision Dx

    3. Right-click the WR7802-XT in the Device List pane (lower) and click Telnet/SSH. 4. Select either Telnet or SSH and leave the default port number. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Accessing the CLI through PortVision DX - 117...

  • Page 120: Cli Introduction

    - delete settings for one or more of these configuration settings: IPSEC settings, log list (system log), OPCUA settings, OPENVPN settings, or remote settings • exit - exits the CLI 118 - CLI Introduction RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 121 Page 123 for more information • show - shows you the current settings a configuration setting, refer to Using SHOW Commands on Page 120 for more information RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Command List - 119...

  • Page 122: Using Show Commands

    Next, we will examine how to find out more information about one of the supported commands (cellular). Type show cellular and the TAB key to see all the show cellular command lines. 120 - Using SHOW Commands RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...
  • Page 123 1. Type show Cellular A and the TAB key to complete the command, which displays the following result. 2. Type show Cellular AP and the TAB key. 3. Type show Cellular APN and the Enter key. The command responds with internet. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Using SHOW Commands - 121...
  • Page 124 1. Type show poe and the TAB key. 2. Type show poe status and press the ENTER key. 3. Type show poe port-1 and press the ENTER key. 122 - Using SHOW Commands RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 125: Using Set Commands

    Most set command lines have the same functionality as the Web GUI. How to Set the Device Name This screen shot shows how to change the device name. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Using SET Commands - 123...

  • Page 126: Set The Cellular Settings

    Port 1, the third entry shows how to set the powering mode, and the last entry verifies that the change was made. 124 - Set the Cellular Settings RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

  • Page 127: Set The Switch Settings

    This example shows how to add VLAN 2 to Ports 1 and 2 as untagged and Ports 3 and 5 as tagged. RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A Set the Switch Settings - 125...

  • Page 128: Using Delete Commands

    Configuration Using the Command Line Interface (CLI) The following example shows how to remove Port 1 from VLAN 1. Using DELETE Commands 126 - Using DELETE Commands RocketLinx WR7802-XT Series User Guide: 2000638 Rev. A...

This manual is also suitable for:

Wr7802-xt-eWr7802-xt-x

Table of Contents
