Rev-A-Shelf Wood Classics 4WCTM-12DM1 Installation Instructions

INSTALLATION INSTRUCTIONS
for Top Mount Pull-Out Waste Containers with
Door Mounting Brackets
For models: 4WCTM-12DM1, 4WCTM-15DM2, 4WCTM-18DM2
For Model: 4WCTM-27-4
and 4WCTM-27-4
Step 1:
Install rear bracket to
rear of slide.
Step 2:
Install front of slide to face
frame. Hole is placed
front of cabinet. Bottom of
slide should be 13
1
cabinet oor. Use #8 x
Low Pro le Truss Head Screw
Step 3:
If rear of cabinet is thin-
ner then / ", install a
1
2
/ " x 3" wide furring
1
2
strip to the back of the
cabinet cenered 14
from oor of cabinet.
1
13 / "
8
FW: I-WCTM150
Rear Mounting Bracket
presure ts over end of slide.
Rear Bumper Stop
/ " from
3
8
/ " from
8
/ "
5
8
/ "
1
4
1
14 / "
4
1
13 / "
8
Step 4:
Measure from inside
cabinet wall to inside
face frame (A) distance
should be measured
the same at rear of
cabinet (B).
Step 5:
Mount Rear Bracket.
Extend the slide rear mounting
bracket until it contacts the rear
(Furring Strip). Bottom of slide
should be 13
oor. Rear mounting bracket
should be the same distance
from the side cabinet wall at rear
of slide as it is up front. Drive mounting screw in center
horizontal slot of rear mounting bracket, tighten. Tighten
screw in front bracket.
Step 6:
Install wood unit (with slides attached) into cabinet, en-
gaging product member slides into cabinet member slides,
push unit until it locks in place.
1
14 / "
4
3
12 / "
4 Product Member
(A)
(B)
/ " from cabinet
1
8
Top View
Cabinet Member
Slides
Cabinet Member
