7. Hanging the Display onto the Universal Plate
8. Adjustment
+10°
-10°
Maintenance
• Check that the bracket is secure and safe to use at regular intervals (at least every three months).
• Please contact your distributor if you have any questions.
Tighten the two screws by
using a proper screwdriver to
secure the adapter brackets
to the universal plate.
Adjust the display to the desired location
then tighten the knobs.
Mobile TV Stand Trolley with Shelf
200x200
300x300
PS-MTSTWS28B
400x200
400x400
600x400
INSTALLATION MANUAL
CAUTION: DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
TV
TV
DVD
DVD
CAMERA
CAMERA
70"
50kg
50kg
10kg
10kg
5kg
5kg
TV Stand
MAX
(110lbs)
(110lbs)
(22lbs)
(22lbs)
(11lbs)
(11lbs)
RATED
RATED
RATED
RATED
RATED
RATED
Advertisement
Related Manuals for PRO SIGNAL PS-MTSTWS28B
Summary of Contents for PRO SIGNAL PS-MTSTWS28B
- Page 1 CAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 200x200 Adjust the display to the desired location CAMERA CAMERA 300x300 then tighten the knobs. 70" PS-MTSTWS28B 400x200 50kg 50kg 10kg 10kg TV Stand 400x400 (110lbs) (110lbs) (22lbs)
- Page 2 NOTE: Read the entire instruction manual before you start installation and assembly. WARNING column (x ) universal plate (x1) • Do not begin the installation until you have read and understood all the instructions and warnings contained in this installation sheet. If you have any questions regarding any of the instructions or warnings, please contact your local distributor.
- Page 3 2.Installing the columns 1.Installing the Base Assembly Attach the support legs to the base Note: Each caster can be adjusted independently using the appropriate screws, washers for fine tuning. Slightly turn the nut to lower or Attach the columns to the base using the appropriate and nuts.
- Page 4 4. Installing the Camera Shelf 6. Installing the Adapter Brackets 6a. For Flat Back Screens P-G x8 P-B x2 P-A x4 -I x4 · Attach the camera shelf to the connecting plate using the screws. · Attach the assembled camera shelf to the universal plate using the appropriate screws, washers and nuts.
