- Page 1 essentia audiotoo s User Manual Rev 2.0 September 2015 Mains Multiplier 6+ Mains Multiplier 6+ Mains Multiplier 8+ Mains Multiplier 8+...
-
Page 2: Table Of Contents
Contents Introduction …………………………………..…………………… page 3 Description …………………………………..…………………… page 4 Safety precautions …………………………………..…………………… page 5 Connection s …………………………………..…………………… page 6 Specifications …………………………………..…………………… page 10 Problem solving …………………………………..…………………… page 11 Warranty …………………………………..…………………… page 11... -
Page 3: Introduction
The Essential Audio Tool’s cables, distribution boxes, filters and phase indicator make any audio set perform better. Essential Audio Tools is investing lots of time and effort to make this product as good as it can be. They are all made with use of precision CNC machining. Beautifully shaped, well-designed and manufactured from top-quality material by experts. -
Page 4: Description
Description The Mains Multiplier is not a regular multiple socket but more a work of art made on a CNC machine that shapes this form out of one piece synthetic material. Yes… synthetic! The results speak for them selves, optical as well as electrical. The type of outputs is chosen because of the high contact pressure, which is obvious when putting in or pulling out an electric plug. -
Page 5: Safety Precautions
essentia Safety precautions audiotoo s For your protection and safe operation of the unit, please read the following: Avoid water and other liquids To avoid risk of fire and electrical shock: do not expose this device to moisture. Use indoors and in dry locations only. -
Page 6: Connections
Connections Integrating your new Mains Multiplier is as easy as can be. Just connect the Mains Multiplier to your wall socket. Don’t bother about the phase of the wall socket, you don’t have to check it. The Mains Multiplier 6+ (figure 1) and the Mains Multiplier 8+ (figure 2) do have a phase indicator inside which gives the following indications: false phase... - Page 7 essentia audiotoo s Connecting the Mains Multiplier 6+ The Mains Multiplier 6+ has two outputs with each a Common Mode filter and four direct outputs, see figure 3. The direct outputs all have a 10 Amps maximum current each, the filtered outputs have a 6 Amps maximum current each.
- Page 8 Connecting the Mains Multiplier 8+ The Mains Multiplier 8+ has four outputs with each a Common Mode filter and four direct outputs, see figure 4. The direct outputs all have a 10 Amps maximum current each, the filtered outputs have a 6 Amps maximum current each. The total current of all eight outputs may not exceed 16 Amps.
- Page 9 On both the Mains Multiplier 6+ and Mains Multiplier 8+ you will find a tool which is unique for Essential Audio Tools. It is called the Ground Bridge. It consists of three terminals (one green, two black) which can be connected in two ways by a bridge.
-
Page 10: Specifications
Specifications Rated voltage 220-240 V ~ AC 50/60 Hz Protecting Phase-Neutral, Phase-Earth and Neutral-Earth Maximum voltage 250 V ~ AC Maximum peak-voltage 2500 V Maximum peak-current 4500 A Maximum peak-energy 3 x 65 Joule Response time < 25 nanoseconds Mains Multiplier 6+ Maximum continuous current per filtered socket 6 Amps Maximum continuous current per unfiltered socket... -
Page 11: Problem Solving
Warranty Essential Audio Tools products have a warranty period of two years from date of purchase. This warranty covers manufacturing defects and failures within product’s specifications. When warranty is claimed the original bill with the buyer’s name and date of purchase should be presented. - Page 12 MORE INFORMATION: WWW.ESSENTIALAUDIOTOOLS.COM Essential Audio Tools: CopyRight by Square Audio, The Netherlands, info@essentialaudiotools.com...
