- Page 1 Volkswagen T5/T6 SWB Roof Rack Fitting Guide Volkswagen T5/T6 SWB Roof Rack Fitting Guide...
- Page 2 1: Parts List Part Name Quantity Roof Rack Brackets Roof Channel Brackets 6mm Bolts 8mm Bolts 10mm Bolts Nuts Large Washers Small Washers Large Spring Washers Small Spring Washers Allen Key Please ensure that you have received all of the components listed above before fitting. If you believe there is anything missing, contact us for assistance.
- Page 3 2: Fitting the Brackets to the Roof Rack When fixing the brackets to the roof rack, place the bracket on the roof rack with the flanges facing to the outside. Fix in place with the 8mm bolts, keep it loose as you will need to adjust when putting it on the top of the vehicle.
- Page 4 3: Fitting the Brackets (on the Vehicle) First remove the pre-existing bolts along the channel on the top of the vehicle. Place the brackets along at the given points with the upright part of the brackets facing the outside of the vehicle as seen below. You can re-use the rubber washer, however new ones are provided.
- Page 5 4: Fitting the Roof Rack Place the roof rack on the top of the vehicle, be careful not to scratch the top. Line up the bracket on the roof rack over the bracket on the vehicle. You may need to adjust the bracket width and position (page 2). Fix in place using the 6mm bolts, tighten the brackets on the vehicle with the allen key provided.
- Page 6 5: Fitting the Brackets (EXTRA) When fitted in place the sturdy Steel or Aluminium Roof Rack will be ready to carry any load safely. Volkswagen T5/T6 SWB Roof Rack Fitting Guide...
- Page 7 General Care & Maintenance !IMPORTANT! We strongly advise you check the car at several intervals after the initial fitting to ensure safety. After 7 days, check and tighten any bolts and we recommend inspecting the bolts, brackets at least once every 6 months. Cleaning Information You can use most cleaning products on this roof rack.
