  • Page 1 User Guide IT6000 Human Machine Interface (HMI) Data Code: 19010504...

  • Page 2: Table Of Contents

    Approvals....................2 1. Product Information ................3 1.1 Nameplate and Designation Rule ..............3 1.2 General Specification................... 4 1.3 Mounting Dimensions of the IT6000 ............6 2. Installation ..................7 2.1 Installation Environment ................7 2.2 Mounting Method ..................7 3.

  • Page 3: Approvals

    Safety Information and Precautions Disclaimer • The drawings in the manual are shown for description only and may not match the product you purchased. • The instructions are subject to change, without notice, due to product or software upgrade, specification modification as well as efforts to increase the accuracy and convenience of the manual.

  • Page 4: Product Information

    1 Product Information 1. Product Information 1.1 Nameplate and Designation Rule Human-Machine Interface (HMI) Model: IT6070E-INT Supply: 24VDC 250mA Ver.: 10205-00252 Suzhou Inovance Technology Co., Ltd. Made in China Serial No.: 014500014GB00841 -INT Mark Version Mark Display screen size International...

  • Page 5: General Specification

    1 Product Information 1.2 General Specification HMI Model IT6070T IT6070E IT6100E Hardware Specifications Display screen size 7.0" 7.0" 10.1" Resolution (mm) 800*480 800*480 1024*600 Brightness (cd/m Display color 24-bit color Backlight source Backlight service life 30000 hours Cortex A8 600 MHz Flash 128MB DRAM...
  • Page 6 1 Product Information HMI Model IT6070T IT6070E IT6100E Electrical Specifications Input voltage 24 VDC±20% Rated current 250mA 250mA 300mA Structure Specifications Housing color Metal grey Housing material ABS+PC engineering plastics Mounting hole 192 x 138 259 x 201 dimensions (mm) General Specifications Working temperature 0 °...

  • Page 7: Mounting Dimensions Of The It6000

    1 Product Information 1.3 Mounting Dimensions of the IT6000 Depth 4×M4 VESA mounting hole Screen Height Clamp holes Width Rear view Side view Cutting size (W+1) × (H+1) Recommended Product Specifications Screw Hole Size HMI Model Through-Hole VESA Physical Dimensions...

  • Page 8: Installation

    2 Installation 2. Installation 2.1 Installation Environment Ambient temperature: The HMI works stably in the temperature range of 0°C to 50°C (32°F~122°F). Using the HMI outside the temperature range may cause damage to HMI components, abnormal operation or performance deterioration. If the HMI needs to be used in specific occasions outdoors, contact your supplier.

  • Page 9: Wiring

    3 Wiring 3. Wiring 3.1 Terminal Description (5) (6) Rear view Terminal Function description Terminal Terminal Function Terminal Name Remarks Description An extra power supply 24 VDC power terminal connector is Power supply terminal supply terminal of delivered along with the the HMI HMI.

  • Page 10: Wiring Description

    3 Wiring Terminal Terminal Function Terminal Name Remarks Description Communication Only IT6***E HMIs support Ethernet port (RJ45) port with PLC or this port. One battery The battery is 3 V CR2032 is inside. It is lithium battery (lifespan: used as backup around five years with Battery cover power of the...
  • Page 11 3 Wiring 3.2.2 Connection to External Device (DB9 Female) The COM1 and COM3 communication ports are available in the DB9 female. The pin arrangement of DB9 female is described in the following table. Signal Pin Arrangement of Pin No. COM1[RS485] COM1[RS485] DB9 Female COM3[RS485]...
  • Page 12 3 Wiring Communication cables and settings (DB9 male): Inovance provides accessory communication cable (Model: IT5-H2U-CAB* Order No.: 15041140) to work with the DB9 female of the HMI. IT5-H2U-CAB* (Order No.: 15041140) Cable length: 3m Cable connector and pin DB9 male...
  • Page 13 6 7 8 9 GND (signal ground) COM2 [RS232] DB9 male (Pin-type signal plate) Communication cables and settings (DB9 female): Inovance provides accessory communication cable (Model: H2U-232-CAB Order No.: 15042148) to work with the DB9 male of the HMI. - 12 -...
  • Page 14 Signal level RS422 -RS422 transfer circuit Pin No. Signal Pin No. Signal Internal connection between the cables Inovance H1U/H2U/H3U IT5*** HMI COM2[RS232] RS422 communication port Model and port using the cable IT6***E HMI COM2[RS232] Mitsubishi FX1N/2N/3U/3G RS422 communication port •...

  • Page 15: Quick Setup

    4 Quick Setup 4. Quick Setup 4.1 Tools Requirements Hardware Tool Kit HMI (IT6000 Series, for example, IT6070T) PLC (H3U Series, for example, H3U-3232MT) USB2.0 (Type-A) to Laptop USB download cable for HMI (Inovance Part No.: IT5-USB-CAB) USB2.0 (Type-B) to HMI USB2.0 (Type-B)
  • Page 16 4 Quick Setup Laptop for firmware update & program download (Windows 7) Software Tool on Laptop InoTouch Editor (free installation, English, support Windows XP, Windows 7, Windows 8, Windows 10) AutoShop (free installation, English, support Windows XP, Windows 7, Windows 8, Windows 10) - 15 -...

  • Page 17: Wiring

    4 Quick Setup 4.2 Wiring 220VAC,50Hz Single-phase power supply 20 21 22 23 24 25 30 31 32 33 34 35 01 01 02 03 04 05 06 07 10 11 12 13 14 15 16 17 H2U-USB-CAB IT5-H2U-CAB IT5-USB-CAB 24VDC +24V power supply...

  • Page 18: Installation Of Inotouch Editor

    4 Quick Setup 4.3 Installation of InoTouch Editor Step 1: Double click Step 2: Click “Next”. - 17 -...
  • Page 19 4 Quick Setup Step 3: Click “Next”. Step 4: Click “Next”. - 18 -...
  • Page 20 4 Quick Setup Step 5: Select as below. Step 5: Wait until “Installation Complete”, and then click “Close”. - 19 -...

  • Page 21: Creating A Project

    4 Quick Setup 4.4 Creating a Project Step 1: 1. Power on HMI. 2. Double click “InoTouch Editor”. 3. Choose File > New Project from the main menu. Step 2: 1. Select items as follows. 2. Click “OK” . - 20 -...
  • Page 22 4 Quick Setup Step 3: Follow steps as follows. Step 4: Select “Bit Switch”. - 21 -...
  • Page 23 4 Quick Setup Step 5: Follow below steps. Step 6: 1. Select “Label/Attributes”. 2. Check “Use text label”. 3. Select “0”. 4. Input “RUN”. 5. Select “1”. 6. Input “RUN”. - 22 -...
  • Page 24 4 Quick Setup Step 7: Follow below steps. Step 8: Click “OK”. - 23 -...
  • Page 25 4 Quick Setup Step 9: Copy and paste the “RUN” widget, follow below steps. Step 10: 1. Select “Label/Attributes”. 2. Check “Use text label”. 3. Select “0”. 4. Input “STOP”. 5. Select “1”. 6. Input “STOP”. - 24 -...
  • Page 26 4 Quick Setup Step 11: Follow below steps. Step 12: Click “OK”. - 25 -...
  • Page 27 4 Quick Setup Step 13: Select “Bit Lamp”. Step 14: Follow below steps. - 26 -...
  • Page 28 4 Quick Setup Step 15: 1. Select “Label/Attributes”. 2. Check “Use text label”. 3. Select “0”. 4. Input “STOP”. 5. Select “1”. 6. Input “RUN”. 7. Click “OK”. - 27 -...
  • Page 29 4 Quick Setup Step 16: Select “Num Display”. Step 17: Follow below steps. - 28 -...
  • Page 30 4 Quick Setup Step 18: Select “Rectangle”. Step 19: Follow below steps. - 29 -...
  • Page 31 4 Quick Setup Step 20: Right click the rectangle and select “Bottom”. Step 21: Copy and paste the rectangle to other area. - 30 -...
  • Page 32 4 Quick Setup Step 22: Select “Text”. Step 23: Follow below steps. - 31 -...
  • Page 33 4 Quick Setup Step 24: Set other texts in the same way. Step 25: Click “Compile” to check errors. - 32 -...
  • Page 34 4 Quick Setup Step 26: Click “Off-line simulation” to check the functions, right click the screen to withdraw. - 33 -...

  • Page 35: Transferring The Project Data

    4 Quick Setup 4.5 Transferring the Project Data Step 1: Follow below steps. Step 2: Wait until download task succeeded, click “Close”. - 34 -...
  • Page 36 4 Quick Setup Step 3: 1. Power on PLC. 2. Double click “AutoShop” . 3. Click “File” and select “New Project”. Step 4: 1. Select “New Project”. 2. Input “Project Name”. 3. Select “Project Path”. 4. Select “H3U” as PLC Type. 5.
  • Page 37 4 Quick Setup Step 5: Click “Tools” and select “Communication Setting”. Step 6: 1. Select “USB”. 2. Click “TEST”. 3. Pop-up window shows “Status: Connected”, and then click “OK”. - 36 -...
  • Page 38 4 Quick Setup Step 7: Follow below steps. Step 8: Follow below steps. - 37 -...
  • Page 39 4 Quick Setup Step 9: Follow below steps. Step 10: Follow below steps. Step 11: - 38 -...
  • Page 40 4 Quick Setup Step 12: 1. Switch to “RUN”. 2. The RUN light is on. - 39 -...

  • Page 41: Using The Hmi

    4 Quick Setup 4.6 Using the HMI Step 1: Touch the RUN SWITCH, the RUNNING LAMP turns on and 6666 displays in DATA. Step 2: Touch the STOP SWITCH, the RUNNING LAMP turns off and 3333 displays in DATA. - 40 -...
  • Page 42 4 Quick Setup Tip: Set Display as below. - 41 -...

  • Page 43: System Setting

    5 System Setting 5. System Setting Way 1: When powering on the HMI, hold down any place of the screen. After the system starts up, enter the password on the "Login" interface and the "Setting" interface will appear. - 42 -...
  • Page 44 5 System Setting Way 2: Adding a Function key to the HMI interface: Click the Function key in the shortcut menu and then double click the newly-created Function key to enter property menu, and then select Display system menu. - 43 -...
  • Page 45 5 System Setting The HMI will reboot when program downloading is finished. Press "Function key" to enter the system. Enter the password (default: 111111) and the "Setting" interface as follows will appear. - 44 -...

  • Page 46: Troubleshooting

    6 Troubleshooting 6. Troubleshooting If the HMI touch screen becomes insensitive or abnormal, use the touch calibration program to calibrate it. Step 1: When powering on the HMI, hold down the screen to enter "Login" interface (the system automatically enters calibration program if the Password box is not touched within 20s) .Input the default password 111111 and the "Setting"...
  • Page 47 Touch the center of "+" cursor by using a stylus or with your finger. The "+" cursor will move according to the direction as shown in the following figure. IT6000 (Gently and accurately touch the center of "+" cursor. Repeat the ②...

  • Page 48: Revision History

    Revision History Date Version Change Description First issue. Firmware version: 10205-00252 Jan 2017 - 47 -...
  • Page 49 Suzhou lnovance Technology Co., Ltd. Address: No.16, Youxiang Road, Yuexi Town, Wuzhong District, Suzhou 215104, P.R.China http: //www.inovance.cn...
