Summary of Contents for VESTEL 1530
- Page 2 Contents Contents Important safety instructions Important safety instructions Wall mounting the set Wall Mounting the Set Controls Connection options Remote control key funcitons Power cord connection Antenna connection AV INPUT connection Introduciton Scart connection COAXIAL connection S-VIDEO connection PC connection HDMI connection Headphone connection Turning on and off the TV...
- Page 5 1. Loosen screws on stand. 2. Loosen screws on bottom.
- Page 7 Connection Options Eject button Play button Pause button Disc window Stop button Previous button Next button DC input socket DC 12V IN HDMI INPUT Connect the HDMI output Device Connect the PC-RGB output jack of PC PC-RGB INPUT Connect the SCART output or input jack of DVD SCART Connect the S-VIDEO output jack of DVD or VCR S-VIDEO INPUT...
- Page 9 or 16:9/4:3 on Video mode.
- Page 10 Press to select sleep timer.
- Page 11 External Equipment Connections External Equipment Connections Power Cord Connection Power Cord Connection - Connect the power cord correctly as shown. STANDBY - Press the switch of your LCD to switch ON.The power indicator on the front panel lights up in green Antenna Connection Antenna Connection - Antenna or Cable Service without a Cable Box Connections...
- Page 12 AV INPUT Connection AV INPUT Connection NOTE: All cables shown are not included with the TV. - Connect the VIDEO and AUDIO output jack of the DVD or VCR to the AV IN jacks on the set with RCA cable. - Match the jacks colors: Video=yellow, Audio left=white, and Audio right=red.
- Page 13 S-VIDEO Connection S-VIDEO Connection NOTE: All cables shown are not included with the TV. - Connect the S-VIDEO output of the DVD or VCR to the S-VIDEO input on the set. The picture quality is improved compared to connecting a regular VCR to the video input. - Connect the Audio output of the DVD or VCR to the Audio TV Back input jacks on the set using the RCA cable.
- Page 14 HDMI Connection HDMI Connection - HDMI (High Definition Multimedia Interface) is the first all digital consumer electronics A/V interface that supports uncompressed standard. One jack supports both video and audio information. NOTE: All cables shown are not included with the TV. - Connect HDMI output of the DVD to the HDMI input jack on the set.
- Page 21 When using the TV for the first time, you must use AUTO SEARCH. TV will auto tune through the band, all programs found will be saved into memory automatically, press button to Auto Search. ( BG/DK/I is for Europe ) - Press to select the sound mode of channel and - Press the...
