- Page 1 Service Manual S-6307 3 HP Automatic Euro Top Post Mount Doctor’s System with Flex Arm 900-021M Rev 5 - 1-10-20...
-
Page 2: Installation
S-6307 Installation 1. Install the chair adapter as per instructions provided with the chair adapter. 2. Place the shipping carton in the desired location. Remove the unit with arm system and unit from the shipping carton. 3. Insert the unit post into the chair adapter hub. Level, then tighten the set screws to secure the post in place. -
Page 3: Operation
S-6307 Operation 1. Turn on the master switch located on the left side of the control head. 2. The handpiece is automatically activated when the wand is pulled forward. 3. Depress the foot control to activate each handpiece. Pressure is shown on the gauge for the handpiece being used. 4. Individual handpiece pressure adjustments are located on the autoblock inside the control head. To adjust the pressure to each handpiece: a. Turn adjustment screw clockwise to decrease the handpiece pressure. -
Page 4: Troubleshooting
Troubleshooting Symptom Handpiece lacks power. Possible Causes A. Improper supply pressure from compressor (80 psi). B. Check handpiece pressure adjustment on unit. C. Air filter may be plugged. D. Pinched supply tubing. E. Defective handpiece gasket at connection with tubing. F. Defective handpiece. Symptom Water coolant does not shut off when foot control is released. Possible Causes A. Adjust air pressure to 80 psi —... - Page 5 Barb, 10-32 x 1/16” ......022-009 010-001 Automatic Handpiece Block....125-130 Tray, 9-3/4 x 13-1/4......Ferrule, 1/8”........117-007 Chasis............... 107-090 Tray Holder......... 107-047 Water Relay........123-000 Spring, Euro ........... 008-035 Euro Tray Arm........107-094 Indicator..........026-020 AUTOMATIC HANDPIECE CONTROL S-6307...
- Page 6 ITEM ITEM PART DESCRIPTION PART NUMBER ITEM PART DESCRIPTION PART NUMBER PART DESCRIPTION PART NUMBER Plug Adjustment........End Cap........... 106-329 Piston, Brake ..........106-317 106-319 Pin, Arm Housing......... Screw, 6-32 x 1/4"........001-133 U-Cup............017-204 009-030 Arm Housing......... Head Knuckle..........106-337 Brake Housing..........
- Page 7 ITEM PART DESCRIPTION PART NUMBER Flex Arm..........106-336 Thrust Washer, Small......003-038 End Cap........... 106-326 Set Screw, Half Dog......005-007 Rigid Arm..........106-360 Pivot Mount........... 106-355 Snap Ring ..........006-002 Plug Square, 3/4" ........010-042 Bronz Bushing........013-019 FLEX ARM SYSTEM WITH PNEUMATIC BRAKE, TOP POST MOUNT 106-307...
- Page 8 ITEM PART DESCRIPTION PART NUMBER Utility Center Lid......144-005 Manual Shut-off Valves....020-022 Master Shut-off Valve Kit.... 127-012 Utility Center Housing ....144-004 Utility Center Kit......010-055 Plug ,10-32......001-001 Screw, #6 x 3/4" ....001-063 Plastic Washer, 1/4"..... 003-001 Plug, 3/4"...
- Page 9 UTILITY CENTER INSTALLATION 144-018...
- Page 10 Pressure Gauge Remove Brass Knurled Cap Air — 80 psi to Replace Filter Element Water—40 psi Regulator Pressure Adjustment To Master On/Off Switch Constant Air Out Out to Foot Control Vent Hole Batch Stamp Located Here ITEM PART NUMBER PART DESCRIPTION ITEM PART DESCRIPTION PART NUMBER PART DESCRIPTION PART NUMBER ITEM 005-024...
- Page 11 Remove Brass Knurled Cap Pressure Gauge to Replace Filter Element Air — 80 psi Water—40 psi Water Out Regulator Pressure Adjustment Vent Hole Batch Stamp Located Here PART NUMBER ITEM ITEM PART DESCRIPTION PART NUMBER PART DESCRIPTION PART NUMBER PART DESCRIPTION ITEM 005-024 Stem............ 127-024 Set Screw, 1/4”-20 x 5/8” ....... Spring............
- Page 12 Water In Water Out Air In Water Relay Valve 123-000 ITEM PART DESCRIPTION PART NUMBER Cartridge Body Assembly..... 123-018 Set Screw, 4-40 x 5/8"..... 005-028 Body............ 123-013 Piston..........123-014 Diaphragm........127-031 Cap............123-012 Screw, #6 x 1/2"........ 001-267 Barb, 10-32 x 1/16"......022-009 Plastic Washer, 1/4"......
- Page 13 CAUTION When adjusting the handpiece pressure, do not over- tighten the screws. Damage may result. The automatic control block is the control center for your dental unit. Individual handpiece pressure adjustments are located on the autoblock. To adjust the pressure to each handpiece: a. Turn adjustment screw clockwise to decrease the handpiece pressure. b. Turn adjustment screw counter-clockwise to increase the handpiece pressure. Signal Air In Handpiece Pressure Adjustment ITEM PART DESCRIPTION...
- Page 14 ITEM PART DESCRIPTION PART NUMBER Ring............126-202 Cover............ 126-201 Spring..........008-005 Stem (Includes 017-012 o-ring)..126-005 Body............ 126-004 Poppet..........126-006 Spring..........008-006 O-Ring, 013........017-013 Baseplate........... 126-003 Screw, 4-40 x 1/4"......001-005 Rubber Pad........126-007 Screw, 6-32 x 1/4"......001-004 FOOT CONTROL 126-200...
- Page 15 HP 2 1/4" Blue HP 1 HP 1 1/8" Brown Water S-6300 / S-6307 Unit Head 1/8" Yellow Junction Box Circled letters indicate connection at Junction Box Utility Center 1/4" Clear - Constant Air In 1/4" Blue - Water In 1/8"...
-
Page 16: Warranty
BDS. The warranty does not cover light bulbs, electrical components and trimmed or installed tubing. BDS reserves the right to void all warranties if any product is installed by other than an authorized technician. BDS' warranty does not cover damage to any surface finish, including but not limited to, discoloration or abrasion from cleaners, disinfectants or light sources. - Page 17 Beaverstate Dental Inc. 115 S. Elliott Rd. Newberg, OR 97132 800-237-2303 503-538-8756 503-538-2845 Fax www.beaverstatedental.com...
